External cooling system
Fig. 32
2013-02-19
CAUTION!
Risk of material damage to the circulating
pump of the external cooling unit.
The circulating pump of the external coolant
system may be damaged if it is not connected
correctly.
Therefore:
– The cooling register must be connected to the
external coolant system with a bypass.
The cooling unit is supplied with cooling liquid from the in-house
cooling system.
A control valve opens when necessary to allow coolant to flow
through the cooling register.
The inlet and outlet of the coolant circuit are each equipped with a
male hose nozzle with an outside diameter of 10 mm.
They are located on the upper left-hand side of the top of the
incubator shaker.
The cooling unit does not require a power supply.
