6.8.2 Adjusting the detachable counterweights

Procedure
Fig. 69
Fig. 70
2013-02-19
Installation and initial operation
NOTICE!
Tighten the 4 Allen screws crosswise and
uniformly,
8. Fit the self-aligning ball bearing and bearing sleeve on the
axle.
1. Remove the Allen screws securing the detachable
counterweights.
2. Remove the detachable weights from the counterweight.
3. Insert the cylindrical pins in the desired counterweight
positions.
4. Place the detachable counterweights in their desired positions
on the counterweight.
5. Screw in the Allen screws to secure the detachable
counterweights.
6. Hold the table with one hand and press the prop into its
holder.
Multitron Pro - Incubation Shaker
Page 95 of 185
