CDM-750 Advanced High-Speed Trunking Modem
Front Panel Operation
5.2.2.4.10

Info: Comp

Comp=Disabled
This screen displays the operational status for the optional K4 GZip lossless compression and
decompression as either Enabled or Disabled. Press ENTER or CLEAR to return to the
previous menu.
5.2.2.5

Select: Store/Ld (Store/Load)

Configuration #2:
No configuration exists.
The user can store up to 10 different modem configurations – 0 through 9. A location that is
available is noted on the bottom line as "No configuration exists."
First, use the ◄ ► arrow keys to navigate to the configuration location number position. Then,
use the ▲ ▼ arrow keys to select the desired location number. Finally, use the ◄ ► arrow keys
to select Load or Store, and then press ENTER when done.
As a modem configuration is stored, its time and date are recorded. This time (in military/24-hour
format) and date (in European convention of DAY-MONTH-YEAR) information is shown on
the bottom line as the location number is edited.
Store/Load: Override
Whether storing into a location or loading into the working memory from a stored location, and
an existing configuration is already stored at this location, the message "A configuration
exists." displays on the bottom line. The system requires the user to confirm the request, as
information will be permanently overwritten:
Configuration #2. Override? No (Y,N)
A configuration exists.
Use the ▲ ▼ arrow keys to select the Override choice – Y(es) or N(o) – and then press ENTER.
5.2.2.6

Select: Utility

Utilities:
LED
Use the ◄ ►
Firmware (1:N is not available and is reserved for future use), and then press ENTER
DeComp=Disabled
Set-RTC
1:1 1:N Circuit-ID
arrow keys to select Set-RTC, Display-Brightness, LED, 1:1, Circuit-ID, or
Load Store
Display-Brightness
Firmware
5–41
Revision 1
MN-CDM750
