CDM-750 Advanced High-Speed Trunking Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Retrieve next 5 N/A 80 bytes
unread Stored
Events
Software Boot SBS= 1 byte
From Slot
SLC= 1 byte,
Switch Link
Configuration
SNMP Read SRC= 16 bytes,
Community characters, no
spaces
Description of Arguments
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the
remote control.
Reply format: [CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-
body, where Sub-body=ABCddmmyyhhmmss,
A is the fault/clear indicator:
F=Fault
C=Clear
I=Info
B is the fault type where:
1=Unit
2=Rx Traffic
3=Tx Traffic
4=Info (Power on/off, or log cleared)
C is Fault Code number, as in FLT? or Info Code, which may be:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
ddmmyy=date stamp.
hhmmss=time stamp.
If there are less than 5 events to be retrieved, the remaining positions are padded
with zeros. If there are no new events, the response is RNE*.
Command or Query.
Selects which bulk firmware slot to boot from in the form x, where:
0=Latest Firmware (most recent date)
1=Firmware is Slot #1
2=Firmware is Slot #2
Example: SBS=0 (Latest Firmware)
Command or Query.
Either isolates (opens) or connects the SERDES link between the Management
Ethernet port and the data Ethernet ports, in the form x, where:
0=Link Open
1=Link Connected
Command or Query.
SNMP read community string. Empty string is not allowed
Example: <1/SRC=public
D–20
Query
Response to
(Instruction &
Command
Qualifier)
N/A RNE? RNE=[CR]ABCddmmyyhhm
mss[CR]ABCddmmyyhhmm
ss[CR]ABCddmmyyhhmmss
[CR]ABCddmmyyhhmmss[C
R]ABCddmmyyhhmmss
(see Description of
Arguments)
SBS= SBS? SBS=x
SBS? (see Description of
Arguments)
SBS*
SBS#
SLC= SLC? SLC=x
SLC? (see Description of
SLC* Arguments)
SLC#
SRC = SRC =x
SRC?
SRC! (see Description of
Arguments))
Revision 1
MN-CDM750
Response to Query
