CDM-750 Advanced High-Speed Trunking Modem
Front Panel Operation
5.2.2.4.5

Info: Clocks

REF = Internal + O/P
The Reference is displayed here. Press ENTER or CLEAR to return to the previous menu.
5.2.2.4.6

Info: ACM

Tx ModCod=QPSK 3/4
Rx ModCod=QPSK 3/4
This screen shows the currently ACM operating parameters (when enabled). Press ENTER or
CLEAR to return to the previous menu.
5.2.2.4.7

Info: CnC

CnC-Status:
This screen shows the current CnC operating parameters (when enabled). Press ENTER or
CLEAR to return to the previous menu.
5.2.2.4.8

Info: Misc

1:1 Redundancy Status: Online
1:1 Switch=Connected Link=Good
This screen provides the following information:
•
1:1 Redundancy Status – Offline or Online
•
1:1 Redundancy Link Status
Press ENTER or CLEAR to return to the previous menu.
5.2.2.4.9

Info: Remote

Remote-Control= Local
Interface= RS-232
This screen shows if the unit is in Local or Remote mode and provides: the details of the selected
electrical interface type; the unit's address; the baud rate. Press ENTER or CLEAR to return to
the previous menu.
Ratio:<-11 dB
RemEsNo:+21.9 dB
LocEsNo:+21.9 dB
Freq-offset:+000.0kHz
Delay: 000000us
Address= 0000
9600 baud
