Config: Intf (Configure Interface); Config) Intf: Piicx = G703 - Comtech EF Data CDM-750 Installation And Operation Manual

CDM-750 Advanced High-Speed Trunking Modem
Front Panel Operation
5.2.2.1.1

CONFIG: Intf (Configure Interface)

Note: The number of available selections depends on the installed interfaces. When an optional
Plug-In Interface Card (PIIC) is installed in Interface Slot 1 or Interface Slot 2, the name of the
interface is displayed on the top line as per the example that follows:
INTF:
GBEI1=Auto
Use the ◄ ►
Available selections include the optional Plug-In Interface Card slot 1 (PIIC1) and slot 2 (PIIC2),
data ports GBE1 (J5 | DATA) and GBE2 (J6 |DATA), and the optional optical socket
(J7 | OPTICAL).

5.2.2.1.1.1 (CONFIG) INTF: PIICX = G703

PIICX: IntfType ClkSource RxBuffer Mask
NONE
Where X designates the optional G.703 interface as being installed in Plug-In Interface Card slot 1
(PIIC1) or slot 2 (PIIC2): Use the
Mask, and then press ENTER.
The active state of the PIIC G.703 interface is displayed on the bottom line. NONE indicates that,
although the PIIC is installed, it is not being used as the data interface for the modem. Otherwise,
the appropriate G.703 interface type is displayed here.
(CONFIG: INTF) PIICX
Interface Type: NONE
Use the ◄ ► arrow keys to select NONE, T3, E3 or STS1, and then press ENTER.
Note: Selecting NONE disables the interface. All other selections enable the PIIC interface for
the appropriate interface type.
In non-multistream mode, enabling a G.703 PIIC interface and selection of T3, E3 or STS1 will
fix the data rate of the modem to the appropriate speed. Symbol rate will be slaved to this fixed
data rate and will change when modulation, coding, pilots or Tx frame block size is changed.
Selection of these interfaces may not be possible if the symbol rate license or CnC license will
not support the symbol rate or data rate.
(CONFIG: INTF) PIICX
Clock Source: ExtClock TxClock
◄ ►
Use the arrow keys to select ExtClock, TxClock, or RxClock, and then press ENTER. The
lower line displays the current setting for each parameter.
PIIC1=G703
GBEI2=Auto
arrow keys to select the item to configure, and then press ENTER to continue.
◄ ►
IntfType
ClkSource
1 MHz
PIIC2=NONE
OptInst:N
arrow keys to select IntfType, ClkSource, RxBuffer, or
RxClock
TXC RXS (
