CDM-750 Advanced High-Speed Trunking Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
SNMP 255 bytes,
SSC=
System Contact characters,
SNMP 255 bytes,
SSL=
System characters,
Location
SNMP 16 bytes,
SSN=
Unit Name characters,
SNMP Trap 15 bytes,
STA=
Destination IP Numerical
Address 1
SNMP Trap 15 bytes,
STB=
Destination IP Numerical
Address 2
SNMP
STV=
Trap Version
SNMP 16bytes,
SWC=
Write characters, no
Community spaces
Time TIM= 6 bytes
Description of Arguments
Command or Query.
SNMP System Contact string.
Example: <1/SSC=Joe Net Admin.
If not configured it returns empty string: <1/SSC=
Command or Query.
SNMP System Location string
Example: <1/SSL=Upstairs back right.
If not configured it returns empty string. <1/SSL=
Command or Query.
SNMP System Name string
Example: <1/SSN=Remote1.
If not configured it returns empty string. <1/SSC=
Command or Query.
Used to set the IP address of the first SNMP Trap destination IP Address 1 where
traps will be sent where the form xxx.xxx.xxx.xxx is the IP addresss
Example: <1/STA=010.006.030.001
When not configured, returns >0001/STA=0.0.0.0
Command or Query.
Used to set the IP address of the first SNMP Trap destination IP Address 2
where traps will be sent, in the form:
xxx.xxx.xxx.xxx is the IP addresss
Example: <1/STB=010.006.030.001
When not configured, returns >0001/STB=0.0.0.0
1 byte Command or Query.
SNMP Trap Version that will be used to send traps.
1=SNMP Trap Version 1
2=SNMP Trap Version 2
Example: <1/STV=0
Command or Query.
SNMP write community string. Empty string is not allowed
Example: <1/SWC=private
Command or Query.
Time in the form hhmmss, indicating the time from midnight, where:
hh=hours (00 to 23)
mm=minutes (00 to 59)
ss=seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
SSC =
SSC!
SSL =
SSL!
SSN =
SSN!
STA =
STA!
STB =
STB!
STV =
STV!
SWC =
SWC!
TIM=
TIM?
TIM*
TIM#
D–21
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
SSC =x [1..128]
SSC?
(see Description of
Arguments)
SSL =x [1..128]
SSL?
(see Description of
Arguments)
SSN =x [1..128]
SSN?
(see Description of
Arguments)
STA=xxx.xxx.xxx.xxx
STA?
(see Description of
Arguments)
STB=xxx.xxx.xxx.xxx
STB?
(see Description of
Arguments)
STV =x
STV?
(see Description of
Arguments)
SWC =x
SWC?
(see Description of
Arguments)
TIM? TIM=hhmmss
(see Description of
Arguments)
Revision 1
MN-CDM750
