Comtech EF Data CDM-750 Installation And Operation Manual page 213

CDM-750 Advanced High-Speed Trunking Modem
Appendix D
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
External EFR= 1 byte,
Frequency
Reference
GBEI Flow GFC= 1 byte
Control
Initialize the IEP= N/A
Stored Events
Pointer
Current Software N/A 1 byte
Management IP IPA= 18 bytes
Address numerical
Management IPG= 15 bytes
numerical
Default
IP Gateway
Description of Arguments
Command or Query.
Sets External Frequency Reference in the form x, where:
0=Internal 10MHz (default)
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=Internal 10MHz plus output - this means that the Reference is available on
the "Ext Ref" rear connector (small rear-panel LED indicates when ON).
Example: EFR=1 (External 1MHz)
Command or Query.
Enable/disable flow control (applies to all ports) in the form x, where:
0=Disable GBEI Flow Control
1=Enable GBEI Flow Control
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored
events log.
Query only.
Active software image in the form x, where:
0=Bulk Image #1 currently active
1=Bulk Image #2 currently active
Command or Query.
Used to set the IP Address and network prefix for the 10/100 Base T Ethernet
management port, in the form aaa.bbb.ccc.ddd.yy, where permitted ranges are as
follows:
aaa: 0-223
bbb: 0-255
ccc: 0-255
ddd: 0-255
yy is the network prefix (range: 8 to 31)
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the IP Gateway Address for the Ethernet management port, in the form
aaa.bbb.ccc.ddd, where permitted ranges are as follows:
aaa: 0-223
bbb: 0-255
ccc: 0-255
ddd: 0-255, but they cannot all be zero.
Example: IPG=010.006.030.001.24
D–17
Query
Response to
(Instruction &
Command
Qualifier)
EFR= EFR? EFR=x
EFR? (see Description of
Arguments)
EFR*
EFR#
GFC=
GFC? GFC=x
GFC*
(see Description of
GFC#
Arguments)
IEP= N/A N/A
IEP#
IMG= IMG? IMG=x
IMG? (see Description of
Arguments)
IMG*
IMG#
IPA= IPA? IPA=xxx.xxx.xxx.xxx.yy
IPA? (see Description of
Arguments)
IPA*
IPA#
IPG= IPG? IPG=xxx.xxx.xxx.xxx
IPG? (see Description of
Arguments)
IPG*
IPG#
Revision 1
MN-CDM750
Response to Query
