CDM-750 Advanced High-Speed Trunking Modem
Front Panel Operation
(CONFIG) IP Config: Addresses
Ethernet IP Gateway:
192.168.001.002
The Gateway Address is the default next hop address used by the M&C to send traffic to when
the M&C is sending a datagram to an IP address outside of its subnet mask or Address/Range.
The Gateway address must be an address that is within the M&Cs subnet address/range.
To configure the unit's IP Gateway Address for the J4 | MGMT (Ethernet M&C) port: First, use
the ◄ ► arrow keys to select a digit to edit, and then use the
that digit. Press ENTER when done.
(CONFIG) IP Config: Addresses
Ethernet IP Address/Range:
192.168.001.002/24
To configure the unit's IP Address for the J4 | MGMT (Ethernet M&C) port: First, use the
arrow keys to select a digit to edit, and then use the
Press ENTER when done.

5.2.2.1.9.2 (CONFIG) IP Config: SNMP

SNMP:
Use the ◄ ► arrows keys to select Communities or Traps, and then press ENTER.
(CONFIG) IP Config: SNMP

SNMP Communities:

Use the ◄ ► arrows keys to select the Read or Write community, and then press ENTER.
(CONFIG) IP Config: SNMP
To edit the SNMP Read Community string: First, use the
alphanumeric character to edit, and then use the
Note: Only the first 20 characters on the bottom line are available.
All printable ASCII characters are available with the exception of the backslash '/'
(ASCII code 92) and tilde '~' (ASCII code 126).
Press ENTER once the string has been composed. All trailing spaces are removed from
the Read Community string upon entry.
Communities
Communities
Read Write
SNMP Read Community:
Public
Gateway
▲ ▼
Address/Range
arrow keys to edit the value of that digit.
▲ ▼
Traps
Communities
(20 chars) (
arrow keys to edit that character.
▲ ▼
5–26
Revision 1
MN-CDM750
v)
(
arrow keys to edit the value of
v)
(
( )
( )
Read
v)
◄ ► arrow keys to select the
◄ ►
