SYSTEM OVERVIEW

The system's 2GIG Control Panel features a color touch screen display that allows control of all system
functions and programming. The display shows both the installer and subscriber the system and installation
status. The 2GIG Control Panel provides touch menus and voice prompts that make installation,
programming, and operation easy. No other system on the market can compare with the 2GIG Control
Panel's ability to be fully operated and programmed remotely with use of a smart phone or tablet.
The system supports 48 wireless sensors of various types including 8 keyfobs, 4 keypads, 2 hard‐wire loops,
15 sensor response types, a supervised bell output, and a programmable solid‐state control output. An on‐
board digital communicator reports alarms and trouble to a Central Station receiver via the standard
telephone network and a 2‐way voice communication with the Central Station.
An internal 345 MHz narrow‐band radio receiver detects signals from wireless system sensors.
When the optional Model 2GIG‐XCVR2 900 MHz transceiver is installed, it sends and receives signals with
wireless touch screen keypads and image sensors. Touch screen keypads allow remote control of the system
through the same graphic interface design as the 2GIG Control Panel.
For enhanced operation, an optional cell radio module can be installed in the field. With the optional cell
radio module installed, the 2GIG system has wireless Central Station reporting capability. 2‐way voice
communication with the Central Station can also go "over‐the‐air" through the cell radio module.
The optional cell radio module also allows 2‐way communications with the subscriber's service provider.
Through this server, subscribers can query and control their system using a computer browser from
anywhere in the world. The service provider server can send messages, time corrections, and software
updates to the Control Panel. Special messages from the server are displayed to the subscriber on the 2GIG
Control Panel touch screen.
The Control Panel's built‐in Z‐Wave radio module allows controlling and monitoring various home
automation devices such as lighting, locks, heating, and air conditioning. The Z‐Wave radio module can also
activate Z‐Wave remote alarm sirens and strobes.
32 User Codes including a Duress Code are supported. User One is the Master User Code that can add or
delete the other 31 User Codes. The Installer Code must be unique from any other User Code and is the only
code that has access to system programming.
The front panel and
emergency icons on the display for Panic, Fire, and Emergency alarm activation (each has programmable
options and can be enabled or disabled). Pressing the
Screen.
buttons serve as controls as well as indicators. Pressing the
button changes the system display to the Home
©2013 2GIG Technologies Inc. All Rights Reserved.
button displays
5
