WIRED SENSOR PROGRAMMING STEPS

Q-2 SELECT WIRED SENSOR #
(1-2)
Two hardwired loops can be used as sensors with
each Control Panel. The options for each wired
sensor are programmed with sub‐option questions.
• Begin by entering the wired sensor number or
select it using the ← or → arrows.
• After selecting the wired sensor number,
program the wired sensor details by using the
↑ and ↓ arrows to select each of the sub‐
options.
To skip wired sensor programming,
NOTE:
press Skip to jump from question Q‐2 to
question Q‐3 (RF key fob programming).
Select wired sensor (#) type
DEFAULT: Unused (00)
Each wired sensor needs to be assigned to a sensor
type.
Select the sensor type that matches the wired
sensor's func on using the ← or → arrows or enter
the sensor type number directly on the keypad.
Sensor Types
(00) unused
(01) exit/entry 1
(02) exit/entry 2
(03) perimeter
(04) interior follower
(05) day zone
(06) 24‐hour silent alarm
(07) 24‐hour audible alarm
(08) 24‐hour auxiliary alarm
(09) 24‐hour fire
(10) interior with delay
(14) 24‐hour carbon monoxide
(16) 24‐hour fire verification
(23) no response type
(24) silent burglary
Select wired sensor (#) equipment
type
DEFAULT: Varies by wired sensor type
This question is only displayed when certain sensor
types are selected.
The equipment type selection will affect the
sensor's extended reporting code.
The following sensor types require equipment type
selection:
Sensor Type Equipment Types Available
(04) interior follower (1)=motion (2)=contact
(06) 24‐hour silent (1)=contact (11)=emergency
alarm
(07) 24‐hour audible (1)=contact (11)=emergency
alarm
(08) 24‐hour auxiliary (1)=contact (6)=freeze (8)=water
(10)=termperature (11)=emergency
(10) interior with delay (1)=motion (2)=contact
(23) no response type (1)=contact (2)=motion
• Select the equipment type that matches the
sensor equipment using the ← or → arrows, or
enter the equipment type number directly on
the keypad.
This Control Panel does not provide
NOTE:
auxiliary accessory output power.
Connecting a hardwire PIR using equipment type
"motion" will require an external stand‐alone
battery backed‐up power supply for the PIR.
Select wired sensor (#) equipment
code (0-9999)
DEFAULT: (0)
The wired sensor equipment code defines the
sensor's manufacturer and type.
• Enter the 4‐digit equipment code for the
sensor.
Select wired sensor (#) equipment
age (0-1)
DEFAULT: New (0)
The Control Panel can be used with new or existing
wired sensors.
• If this wired sensor is new for the installation,
leave the default of new(0).
• If this wired sensor is already installed, select
existing (1).
