Go!Control Wireless Security System | Install Guide
Select RF sensor (#) loop number
(1-3)
DEFAULT: Varies with sensor model
selected
2GIG‐DW10 door/window sensors have two inputs:
an internal magnetic contact and an external
normally closed hardwired input. Either or both
sensor inputs can be used.
Some sensors are capable of three loop
TIP:
inputs.
When using both the internal magnetic contact and
the external input, the magnet contact and the
external contact need to be assigned a different
RF sensor number. Both sensor numbers will
share the same sensor serial number.
• When programming the sensor to use the
built‐in magnetic contact, set the loop number
to (2).
• When programming the sensor to use its
hardwired input, set the loop number as (1).
• When programming a 3‐loop sensor to use an
additional input, set the loop number as (3).
• When entering the sensor number for the
sensor's loop 2 or 3, the paste button can be
used to recall the last programmed sensor's
serial number. (The sensor number will be
filled in automatically if Learn is used.)
Select RF sensor (#) dialer delay
(0-1)
DEFAULT: Enabled (1)
(Required SIA CP-01 Default)
RF sensors can trigger the communicator
immediately or after a delay. The delay time is set
by the abort window dialer delay programming
question Q‐35 (the default delay is 30 seconds).
• The default (1) causes delayed dialing for this
RF sensor number.
• For immediate dialing for this RF sensor
number, select disabled (0).
This setting for CO and smoke detectors
NOTE:
is automatically set to disabled (0), and
this sub‐question is skipped for these
sensor types.
This default can be changed without
NOTE:
affecting SIA CP‐01 compliance.
32 ©2013 2GIG Technologies Inc. All Rights Reserved.
Construct RF sensor (#) voice
descriptor
DEFAULT: No default
The voice descriptors are the words the Control
Panel will announce for this RF sensor if this sensor
is programmed for voice annunciation. Up to five
words are allowed.
Press insert to place a word from the
1
vocabulary into the data entry field.
Use the ← or → arrows to scroll through the
2
words, or enter the word's 3‐digit index
number (see "System Vocabulary Table" on
page 27).
3 Press insert again for the next word. Up to five
words are allowed.
To move between words, press the Fwd and
4
Back buttons.
To remove a word, press Delete.
5
Select RF sensor (#) reports (0-1)
DEFAULT: Enabled (1)
RF sensors can be programmed to trigger a report
to the Central Station or not.
• The default (1) enables reporting for this RF
sensor number.
• To prevent reporting for this RF sensor
number, select disabled (0).
Select RF sensor (#) supervised
(0-1)
DEFAULT: Enabled (1)
When a sensor is set to supervised, the Control
Panel will expect regular timed signals from this
sensor or else a sensor supervisory trouble alert
will occur.
• The default (1) allows supervision for this RF
sensor.
• To turn off supervision for this RF sensor,
select disabled (0).
Portable sensors such as panic buttons
NOTE:
should not be set as supervised if the
sensor will be removed from the premises
at times.
