INSTALLATION OUTLINE

The following outline is intended to guide the
installing alarm dealer through the complete
installation of a Go!Control system.
Use the following outline in conjunction with this
copy of the Install Guide to guide you through the
installation.
Unpack the system. Identify the system
1
components.
Plan the installation by creating an installation
2
floor plan. Determine the best centralized
location for the Control Panel. Decide on
where the sensors (either wireless or wired or
both) will be installed.
Identify an un‐switched wall outlet for
3
plugging in the power supply.
4 Install the Cell Radio Module into the Control
Panel.
If installing POTS, identify or install a U.S.O.C.
5
RJ31X telephone jack for connection of the
Control Panel's POTS Module (this is optional).
Installing the POTS Module is optional.
NOTE:
Use the mounting plate as a template to mark
6
the mounting location for the Control Panel.
Mark any drywall cutouts behind the
mounting plate required for the installation
and make the cutouts.
Attach the mounting plate to the wall using
7
three screws.
8 Install each of the system's wireless sensors. If
either of the two hardwire loops are going to
be used, install the contacts and route the
loop wire to the Control Panel's wall cutout.
Use the log in the quick programming guide to
document each sensor's ID number and
location.
Install the optional hardwired sounder, and
9
route the connection wire to the Control
Panel's wall cutout.
If used, route the telephone line from the
10
RJ31X jack to the Control Panel's wall cutout.
For convenience, use the "third hand" strap to
11
hang the Control Panel on the mounting plate.
12 Connect all wiring to the Control Panel's
terminal block.
If you install the POTS Module, plug the
13
telephone line into the Control Panel's POTS
Module.
14 Plug the backup battery connector into the
connector on the circuit board.
Swing the Control Panel up, placing the
15
bottom over the lip of the mounting bracket.
Push the top of the Control Panel into the
mounting bracket until it snaps into place,
then secure it with the retaining screw.
Plug the power supply into the un‐switched
16
wall outlet.
Program the system as described in this
17
manual and mark the check boxes in the User
Guide to indicate any custom setup to the
subscriber.
18 Test the system as described in this manual.
Instruct the subscriber on the system
19
operation and provide the User Guide to the
subscriber.
System Accessories
• Cell Radio Module
• Internal Antenna
• External In‐Wall Antenna
• External Attic Mount Antenna
• Standard Battery Pack
• Extended Battery Pack
• Replacement Power Supply
Wireless System Sensors
• Thin Door/Window Contact
• Recessed Door Contact
• Passive Infrared Motion Detector
• 4‐button Key Ring Remote
• Panic Button Remote
• Glass Break Detector
• Smoke and Heat Detector
• Wireless Touch Screen Keypad
• Wireless Keypad
• Super Switch Wireless Takeover Module
©2013 2GIG Technologies Inc. All Rights Reserved. 9
