Sia Cp‐01 Defaults - 2gig Technologies Go Control Install Manual

Enter the Installer Code (default = 1561) to
3
display the Installer Toolbox.
Press System Configuration and begin "RF
4
Sensor Programming Steps" on page 30.
Use the installation log sheet to record
5
programmed options for the system.
6 After setting all the required programming
values for the sensors and the Control Panel,
press End, then Exit, to save the changes.
After the Control Panel restarts, press Security
7
/ Menu / Toolbox, enter the Master User Code
(default = 1111), press User Management and
setup the user's codes. Be sure to set a Duress
Code as User #8. Press Back when finished.
Press Brightness/Volume and set the levels for
8
the installation.
The volume setting does not affect the volume
9
of alarm sounds.
10 Press → to view the second toolbox screen.
Press Back Light Timeout and set the display
11
lighting timeout.
Press Set Date and Set Time and set the
12
calendar and clock. If the Cell Radio Module is
installed, the date and time sets automatically.
Press the button to return to the Home
13
Screen.
After completing all setup and programming, refer
to the User Guide for details on operating the
system. Check off the programmed options for the
system in the User Guide.
Be sure to instruct the subscriber on
NOTE:
the proper operation of the system, and
leave the User Guide at the installation
site for reference.
SIA CP-01 Defaults
Several system programmable options have the
defaults pre‐set to provide compliance with the
Security Industry Association CP‐01 Standard. All
other system settings and functions that are
required to comply with SIA CP‐01 are permanently
programmed into the Console and cannot be
changed. Refer to the table for each programmable
option that has a required SIA CP‐01 programming
default.
Programming Question SIA CP‐01 Default Range
Q‐1 Wireless Sensor Dialer Delay 30 Seconds
Q‐2 Wired Sensor Dialer Delay 30 Seconds
Q‐5 Exit Delay 60 Seconds
Q‐6 Entry Delay #1 30 Seconds
Q‐7 Entry Delay #2 45 Seconds
Q‐10 Call Waiting Disable Code No Default Code
Q‐20 Swinger Shutdown Count 2 Trips
Q‐26 Auto Stay Enabled
Q‐27 Exit Delay Restart Enabled
Q‐31 Cancel Time 5 Minutes
Q‐32 Cancel Display Enabled
Q‐35 Abort Window Dialer Delay 30 Seconds
Q‐79 Select Output Follows Internal Sounder See Q‐78 for Options
©2013 2GIG Technologies Inc. All Rights Reserved.
Programming Navigation
On or Off
On or Off
45‐120 Seconds
30‐240 Seconds
30‐240 Seconds
0‐6 Digits
1‐6 Trips
Enabled Disabled
Enabled or Disabled
6‐254 Minutes
Enabled or Disabled
15 or 45 Seconds
23
