Enter Rf Sensor (#) Serial Number (0‐9999) - 2gig Technologies Go Control Install Manual

Sensor Equipment Codes
(0000) other
(0862) DW10‐345Thin Door/Window Contact
(0863) DW20R‐345 Recessed Door Contact
(0869) PIR1‐345 PIR with Pet Immunity
(0864) GB1‐345 Glass break detector
(0895) SMTK2‐345 GE Smoke/Heat detector (USA/Canada)
(1058) SMTK3‐345 2GIG Smoke Detector
(0872) SMKE1‐345 Smoke Detector (USA)
(0871) SMKE1‐345C Smoke Detector (Canada)
(0868) PANIC1‐345 Panic Button Remote
(0860) CO1‐345 CO Detector (USA)
(0859) CO1‐345 CO Detector (Canada)
(1026) CO3‐345 2GIG CO Detector (USA/Canada)
(0873) TAKE‐345 Takeover Module
(0637) HWD/W"5816"
(0470) HW R‐D/W "5818MNL"
(0533) HW PIR "5890"
(0530) HW PIR "5894Pi"
(0519) HW Glass Break "5853"
(0589) HW Smoke "5808W3"
(0557) HW Heat Sensor "5809"
(0624) HW Flood Sensor "5821"
(0491) HW Panic Pendant "5802MN2"
(0655) Existing Door/Window Contact
(0609) Existing Motion Detector
(0475) Existing Glass Break Detector
(0616) Existing Smoke Detector
(0692) Existing CO Detector
(0708) Existing Heat Sensor
(0556) Existing Flood/Temp Sensor
(1061) Garage01 Resolution Products Tilt Sensor
(1063) DBELL1‐345 2GIG Doorbell
Enter RF sensor (#) serial number
(0-9999)
DEFAULT: 0
This question is only displayed if
NOTE:
"(0000) other" is selected for a sensor's
equipment code.
The equipment code is a 4‐digit code that is
assigned to the model of sensor being used. If new
equipment becomes available, the new equipment
code should be entered here if the new equipment
is not listed in the Sensor Equipment Codes table
above.
• Enter the equipment code number directly on
the keypad for the RF sensor. (Enter "0" if the
new equipment code is unknown.)
Enter RF sensor (#) serial number
(7 digits)
DEFAULT: 0000000
RF sensor serial numbers can be manually entered
or learned from the sensor.
• For manual entry, enter the sensor number
that was logged for the sensor being
programmed. Use the Shift button to access
alpha characters.
• For automatic entry, press Shift, then press
Learn. The Control Panel will wait for a sensor
transmission. Trigger the sensor being
programmed and the Control Panel will beep
four times and learn the sensor's serial
number.
If the sensor being learned is already in memory,
the Control Panel will display a sensor learning
failure screen when the programming changes are
being saved.
For certain sensors with more than two loops, the
tamper switch must be used to send a signal to the
Control Panel during sensor learning. First press of
tamper switch will learn as Loop #1, the second
press of tamper switch will learn as Loop#2, the
third press of tamper switch will learn as Loop #3.
Wait 15 seconds between each press of the
tamper switch.
The programmed loop number of the sensor in the
Control Panel may need changing to suit the
operation of the device. See the Install Instructions
of the sensor for details.
Select RF sensor (#) equipment age
(0-1)
DEFAULT: New (0)
The Control Panel can be used with new or existing
RF sensors.
• If this RF sensor is new for the installation,
leave the default of new(0).
• If this RF sensor is already installed, select
existing (1).
If the RF sensor has more than one loop
NOTE:
and is being programmed into multiple
sensor numbers to support the loops, set
only one loop as "new" and the other
loops as "existing". This will prevent
incorrect inventory of the installed
sensors.
©2013 2GIG Technologies Inc. All Rights Reserved.
RF Sensor Programming Steps
31
