1.2.7.2 Borderless Print Specification

By driver's command transmission, supports the following borderless print
mode. Supports the following 3 modes.
Table 1-13. Borderless Print Specification mode
Mode
Right and left You can set only the right and left margins to zero. At this time,
borderless (default) up and down margins are set by roll paper margin setting.
4 sides borderless/1 cut You can set 4 sides margins to zero. Use the following
method for cutting.
Starting of JOB, take minimum cut length for margin and
cut while printing.
While JOB, new page has no margin, cut at image border
position in continuing print.
End of JOB, cut at the bottom of the image.
4 sides borderless/2 cut You can set 4 sides margins to zero. Use the following
method for cutting.
At the front edge page, take refresh margin length for
margin, cut while printing.
At the end of the page, cut at the bottom of the image.
To discard the remaining part of printing after cut, cut the
paper after advancing the paper to minimum cut length.
Note 1: For 4 sides borderless, after cutting, up and down size of the printing will be
smaller by approximately 2mm than the actual printing size.
2: When the roll paper cutter is OFF and page line printing is ON, print the page
line at each cutting position including front edge page.
3: In following media, if 1 cut is selected at borderless printing, it is cut as 2 cut to
prevent scraping top of paper.
• Premium Glossy Photo Paper
• Premium Semigloss Photo Paper
Note *: Recommended a borderless length for glossy paper is 60mm, for other paper
is 100mm.
Product Description
Operation
*
Basic Specifications
Borderless setting method
Table 1-14. Borderless setting
Right and left
Borderless mode
borderless
Printer operation
Driver setting Borderless print
Note Default setting
Revision C
4 sides borderless 4 sides borderless
(1 cut) (2 cut)
Borderless print Borderless print
Single cut Double cut
The upper edge The upper edge
cut is performed cut is performed
by interrupting by interrupting
print operation; print operation;
there is chance of there is chance of
color shading color shading
according to data. according to data.
By adjusting To avoid
cutter position, remaining of
there is chance of margin, cut off the
data from top and bottom
continuous page part of the paper
remaining in top by going inside of
or bottom edge of image.
the page. Therefore the
actual size will be
about 2mm
smaller than the
specified print
area.
