EPSON Stylus Pro 4400/4450/4800/4880/4880C

1.2.6.2 Cut Sheet

CONTAINABLE PAPER
The printer accepts following plain paper and special paper. It is not assured
feeding and print quality with any other paper except plain paper and special
paper.
Paper Size
Table 1-8. Cut Sheet Size (Containable Paper)
Paper Size Size (H x W)
B3 364 mm x 515 mm
B4 257 mm x 364 mm
A2 420 mm x 594 mm
Super A3/B 329 mm x 483 mm
(A3 +)
A3 297 mm x 420 mm
A4 210 mm x 297 mm
Thickness
0.08 ~ 1.50 mm (paper length; 279 mm ~ 610 mm)
NOTE 1: Paper should have no wrinkles, tears, or stains and
the surface should be smooth.
2: Paper should be placed with its fibrous direction same
as the feed direction. (Basically portrait orientation)
3: 0.08 ~ 1.50mm paper thicknesses are supported for
long-edge insertion.
4: A4, letter, or 8 x 10 inch papers should not be placed
in landscape orientation on rear manual feed path.
5: Auto nozzle check is not available for 8 x 10 inch or
smaller paper.
6: Front manual feed is not available for soft paper or
0.2mm or less thickness paper.
Product Description
Paper Size Size (H x W)
US-C Size 17 x 22 inch
16 x 20 inch 16 x 20 inch
300 mm x 450 mm 300 mm x 450 mm
US-B Size 11 x 17 inch
(Ledger)
11 x 14 inch 11 x 14 inch
Quarter 10 x 12 inch
Letter 8.5 x 11 inch
8 x 10 inch 8 x 10 inch
Basic Specifications
PLAIN PAPER
It is assured feeding only with following specifications.
Paper Size : Identical to Table 1-8 "Cut Sheet Size (Containable
Paper)"(p16).
Thickness : 0.08 ~ 0.11 mm
Weight : 64 ~ 130 gf/m
Type : Plain paper, Recycle paper
NOTE 1: Paper should be placed in portrait orientation.
2: Paper should have no wrinkles, tears, or stains and the surface
should be smooth.
3: It is used under normal condition (temperature 15ºC ~ 25ºC,
humidity 40% ~ 60%RH).
BORDERLESS PRINT WIDTH
Borderless print for right and left is assured with following paper width. But
following types are not recommended for borderless printing.
NOTE: 300 mm, 400 mm are supported for Europe.
Borderless Print Width
Table 1-9. Borderless Print Width
8.25"" 8.5" 10"
210mm 216mm 257mm 297mm
A4 LTR B4
NOTE 1: Mechanism clips print data out of over-printable area for
borderless print.
2: Borderless printing is not available for A2 cut sheet.
Revision C
2
12" 13" 14" 16"
329mm 355.6mm 400mm 431.8mm
x
A3 A3+ – 16" 20"
17"
US-C
16
