Loading and Saving Settings
and Measured Data
7.1 Types of Files
Types of Files
File
Setting file
Measurement data Automatic
file output
Manual (Not during time-
series measurement)
Waveform data file Automatic
output
Manual (Not during time-
series measurement)
Backup data file Automatic
output
Screen copy file Manual
Mode File Name
69SET00.SET to
69SET99.SET
########.SET
Standard 69MEAS00.CSV
interval to
69MEAS99.CSV
########.CSV
Short-term 69INST00.BIN to
interval 69INST99.BIN
########.BIN
69MANU00.CSV
to
69MANU99.CSV
Standard 69WAVE00.WUI
interval to
69WAVE99.WUI
########.WUI
69MANU00.WUI
to
69MANU99.WUI
Standard 69BACK00.CSV
interval to
(measurement 69BACK99.CSV

data)

Standard 69BACK00.WUI to
interval 69BACK99.WUI
(waveform
data)
Short-term 69BACK00.BIN to
interval 69BACK99.BIN
(measure-
ment data)
69BMP00.BMP to
7.1 Types of Files
7
Format Remarks
Text
Text
Binary
Text
Binary
Binary
Text Stored in the
interval memory
only
Binary
Binary
BMP
115
