(1) Change the Channel to be Displayed.
Every time the
CH
is changed as follows.
(2) Change the Voltage Y-Axis Magnification.
Every time the
MAG U
nification is changed as follows:
X1/2
(3) Change the Current Y-Axis Magnification.
Every time the
nification is changed as follows:
MAG I
X1/2
(CH) key is pressed, the channel to be displayed
F2
1P2W U1, I1
Circuit1 Circuit2 Circuit3 Circuit4
1P3W U1, I1
Circuit1 Circuit1 Circuit2 Circuit2
3P3W2M U1, I1
Circuit1 Circuit1 Circuit2 Circuit2
3P3W3M U1, I1
3P4W U1, I1
3P4W4I U1, I1
(MAG U) key is pressed, the voltage y-axis mag-
F3
→ → → →
X1 X2 X5 X10
(MAG I) key is pressed, the current y-axis mag-
F4
→ → → →
X1 X2 X5 X10
6.3 Displaying a Waveform
→ → →
U1, I1 U1, I1 U1, I1
→ → →
U2, I2 U1, I1 U2, I2
→ → →
U2, I2 U1, I1 U2, I2
→ →
U2, I2 U3, I3
→ →
U2, I2 U3, I3
→ → →
U2, I2 U3, I3 I4
