Options
Clamps
Voltage output type:
• 9660 CLAMP ON SENSOR (100 A rms rating)
• 9661 CLAMP ON SENSOR (500 A rms rating)
• 9667 FLEXIBLE CLAMP ON SENSOR (5000 A rms rating)
• 9669 CLAMP ON SENSOR (1000 A rms rating)
• 9694 CLAMP ON SENSOR (5 Arms rating)
• 9695-02 CLAMP ON SENSOR (50 Arms rating)
• 9695-03 CLAMP ON SENSOR (100 Arms rating)
• 9290 CLAMP ON ADAPTER
• 9219 CONNECTION CABLE (for 9695-02/03)
Interface
• 9440 CONNECTION CABLE
• 9441 CONNECTION CABLE
• 9612 RS-232C CABLE (for PC)
Printers
• 9442 PRINTER (with 1 roll of thermally sensitized paper sup-
• 9443-01 AC ADAPTER (for printers) for Japan
• 9443-02 AC ADAPTER (for printers) for EU
• 9443-03 AC ADAPTER (for printers) for USA
• 1196 RECORDING PAPER (25 m, 10 rolls)
Transport
• 9720-01 CARRYING CASE
case
Other
• 9626 PC Card 32 MB (32 MB compact Flash card + adapter)
• 9627 PC Card 64 MB (64 MB compact Flash card + adapter)
peripherals
• 9726 PC Card 128 MB (128 MB compact Flash card + adapter)
• 9727 PC Card 256 MB (256 MB compact Flash card + adapter)
• 9728 PC Card 512 MB (512 MB compact Flash card + adapter)
Software
• 9625 POWER MEASUREMENT SUPPORT SOFTWARE
(continuous 1000 A, up to 1500 A, CT ratio 10:1)
plied, with battery pack)
sensor are also housed in the case.)
(9720 CARRYING CASE)
(PC application software)
(for external input/output terminal)
(for D/A output, 3169-21 only)
(The voltage cables and clamp-on
