Classification
Total Value TOTAL_U1_INST[V]
TOTAL_U2_INST[V]
TOTAL_U3_INST[V]
TOTAL_I1_INST[A]_1 to TOTAL_I1_INST[A]_4
TOTAL_I2_INST[A]_1 to TOTAL_I2_INST[A]_2
TOTAL_I3_INST[A]_1 to TOTAL_I3_INST[A]_2
TOTAL_I4_INST[A]_1
TOTAL_P_INST[W]_1 to TOTAL_P_INST[W]_4
THD-F THDF_U1_INST[%]
(Selected)
THDF_U2_INST[%]
THDF_U3_INST[%]
THDF_I1_INST[%]_1 to THDF_I1_INST[%]_4
THDF_I2_INST[%]_1 to THDF_I2_INST[%]_2
THDF_I3_INST[%]_1 to THDF_I3_INST[%]_2
THDF_I4_INST[%]_1
THD-R THDR_U1_INST[%]
(Selected)
THDR_U2_INST[%]
THDR_U3_INST[%]
THDR_I1_INST[%]_1 to THDR_I1_INST[%]_4
THDR_I2_INST[%]_1 to THDR_I2_INST[%]_2
THDR_I3_INST[%]_1 to THDR_I3_INST[%]_2
THDR_I4_INST[%]_1
Data Header
• "n" represents the harmonic orders (01 to 40).
• Harmonic measurement data is added after normal measure-
ment data.
• "INST" in the header will be replaced by "AVE" for the average-
value data.
• "INST" in the header will be replaced by "MAX" for the maxi-
mum-value data.
• "INST" in the header will be replaced by "MIN" for the mini-
mum-value data.
Contents
Total voltage (U1) (1st to 40th) V
Total voltage (U2) (1st to 40th) V
Total voltage (U3) (1st to 40th) V
Total current (I1) (1st to 40th),
Circuits 1 to 4
Total current (I2) (1st to 40th),
Circuit 1-2
Total current (I3) (1st to 40th),
Circuit 1-2
Total current (I4) (1st to 40th)
Total power (1st to 40th)
Circuits 1 to 4
Voltage (U1) Total harmonic
distortion (THD-F)
Voltage (U2) Total harmonic
distortion (THD-F)
Voltage (U3) Total harmonic
distortion (THD-F)
Current (I1) Total harmonic dis-
tortion (THD-F)
Circuits 1 to 4
Current (I2) Total harmonic dis-
tortion (THD-F), Circuit 1-2
Current (I3) Total harmonic dis-
tortion (THD-F), Circuit 1-2
Current (I4) Total harmonic dis-
tortion (THD-F)
Voltage (U1) Total harmonic
distortion (THD-R)
Voltage (U2) Total harmonic
distortion (THD-R)
Voltage (U3) Total harmonic
distortion (THD-R)
Current (I1) Total harmonic dis-
tortion (THD-R)
Circuits 1 to 4
Current (I2) Total harmonic dis-
tortion (THD-R), Circuit 1-2
Current (I3) Total harmonic dis-
tortion (THD-R), Circuit 1-2
Current (I4) Total harmonic dis-
tortion (THD-R)
Unit
A
A
A
A
W
%
%
%
%
%
%
%
%
%
%
%
%
%
%
