4.2 Connection Methods
4.2 Connection Methods
4.2.1 Displaying the Wiring Diagram
Press the
Press the
SCREEN
Select "WIRING DIAGRAM" by using the cursor key.
Press the
select
(Example: 3P3W2M x 1 (three-phase, 3-wire))
key to display the measurement screen.
MEASURE
(SCREEN) key to display the selection window.
F1
F1
(select) key; the wiring diagram will appear.
