5.2 Setting on the Measurement Setting Screen (MEASUREMENT)

5.2.7 Setting the Current Range

Press the
NEXT
Press the
SCR
screen. (3169-20: SET UP 1/4, 3169-21: SET UP 1/5)
Move the cursor to "
changed.
-
Set the current range by using the function keys as follows:
+
Clamp-On Sensor and Current Range
The selectable current ranges vary depending on the clamp-on
sensor used. When the connection method is 3P4W4I, a current
range can be set for I4 that differs from that for I1 to I3.
key to display the setting screen.
SET UP
(NEXT SCR) key to display the measurement setting
F5
CURRENT RANGE
-
Changes to a smaller range.
+
Changes to a larger range.
9660/ 9695-03
9661
9667-5 kA (5000 A range)
9667-500 A (500 A range)
9669
9694
9695-02
" of the circuit to be
5 A, 10 A, 50 A, 100 A
5 A, 10 A, 50 A, 100 A, 500 A
5 kA
500 A
100 A, 200 A, 1 kA
0.5 A, 1 A, 5 A
0.5 A, 1 A, 5 A, 10 A, 50 A
65
1
2
3
4
5
6
7
8
9
10
11
