11.2.2 Setting the Integrated Power Output Rate

Set the output rate when integrated power is output from the D/A
terminal. The output rate will be DC ±5 V with respect to the set full
scale of integrated power.
Select an integration output rate using the cursor keys.
Press the
NEXT
Press the
SCR
screen. (SET UP 5/5)
Move the cursor to "
Press the
change
Select integration output rate using the cursor key.
Press the
select
key to display the setting screen.
SET UP
(NEXT SCR) key to display the D/A output setting
F5
INTEG. OUTPUT RATE
(change) key to display the selection window.
F1
default
5V/1kWh,5V/5kWh (
5V/500kWh,5V/1MWh
(select) key.
F1
11.2 Setting D/A Output
."
),5V/10kWh,5V/50kWh,5V/100kWh,
