Handling the cords
• Keep in mind that, in some cases, conductors to be measured
• To avoid damaging the power cord, grasp the plug, not the cord,
• To avoid damaging the voltage cords or clamp sensor cables, do
• Avoid stepping on or pinching the cable, which could damage
• Keep the cables well away from heat sources, as bare conduc-
• When disconnecting the BNC connector, be sure to release the
• Failure to fasten the connectors properly may result is sub-spec-
Input
Maximum input voltage and maximum rated voltage
to earth
• The maximum input voltage of the product is 780 Vrms,
• The maximum rated voltage to earth of the product is 600
• The maximum rated voltage to earth of clamp sensor
may be hot.
when unplugging the cord from the power outlet.
not bend or pull near their ends.
the cable insulation.
tors could be exposed if the insulation melts.
lock before pulling off the connector. Forcibly pulling the connec-
tor without releasing the lock, or pulling on the cable, can dam-
age the connector.
ification performance or damage to the equipment.
1103 V peak. Do not measure the voltage exceeding that. It
causes the personal injury as well as damages the product.
Vrms. Do not measure the voltage to earth exceeding that.
It causes the personal injury as well as damages the prod-
uct.
depends on the type of clamp sensor used.
To avoid electric shock, refer to the instruction manual of a
clamp sensor used.
