5.4 Setting on the Save/Print Items Setting Screen (SAVE, PRINT ITEMS)
5.4.3 Setting Integrated power and Demand Measure-
ment-data Output Items
Press the
Press the
NEXT
SCR
ting screen. (3169-20: SET UP 3/4, 3169-21: SET UP 3/5)
Move the cursor to "
Press the
ON
measurement data.
• Integrated power/demand measurement data includes the total
• Detailed setting cannot be performed for each piece of inte-
key to display the setting screen.
SET UP
(NEXT SCR) key to display the save/print items set-
F5
INTEG. & DEM.
(ON) key to turn ON the integrated power/demand
F2
integrated power, integrated power within interval, demand
value, and maximum demand value.
grated power/demand measurement data above.
."
81
1
2
3
4
5
6
7
8
9
10
11
