Hioki 3169-20 Instruction Manual page 166

158
11.1 Connecting the D/A Output Terminal
Connection to the D/A Output Terminal
9441 CONNECTION CABLE
D/A output connector
(D/A OUT)
Pin No.
1
2
3
4
5
6
7
8
• Pins 5 to 8 are common ground pins.
• A plastic connector is used for the connection cable. To pre-
vent damage to the connector, do not insert it into the terminal
without aligning the guide grooves, and do not pull it without
releasing the lock.
• The output resistance of the output terminal is approximately
Ω
100 . Make sure a recorder or other device to be connected
to the terminal has an input resistance of 100 k
Insert the 9441 CONNECTION CABLE into
the D/A output terminal, aligning the connec-
tor guide grooves
equipped with a lock). When removing the
connection cable, hold it by its plastic part.
Signal Name
D/A output ch1
D/A output ch2
D/A output ch3
D/A output ch4
Ground
Ground
Ground
Ground
(the connector
9441 Cable Color
Red
White
Black
Yellow
Blue
Green
Brown
Gray
Ω
or more.
is
