5.2 Setting on the Measurement Setting Screen (MEASUREMENT)

5.2.6 Setting the VT Ratio (PT Ratio)

Press the
NEXT
Press the
SCR
screen. (3169-20: SET UP 1/4, 3169-21: SET UP 1/5)
Move the cursor to the "
Set the VT ratio by using the function keys as follows:
-
(Cursor
digit)
+
Setting range: 0.01 to 9999.99 (Default: 1.00)
This ratio is used for measurement conducted on the secondary
side of an external voltage transformer (VT) to convert the volt-
age measured to the primary voltage to be displayed.
What is VT?
VT stands for "voltage transformer." It is also referred to as "PT"
(potential transformer). VT is used in high-voltage measurement to
convert (step-down) the voltage measured to a smaller level and
supply the conversion result to an instrument.
VT ratio (voltage transformation ratio): A ratio used to convert the
secondary voltage of VT to the primary voltage.
key to display the setting screen.
SET UP
(NEXT SCR) key to display the measurement setting
F5
VT
: Moves left to next digit; Cursor
- Decrements the number.
+ Increments the number.
" digit to be changed.
: Moves right to next
