Using D/A Output
(3169-21 only)
When the D/A output function is used, measurement data such as
the voltage, current, and power is output in analog (D/A) form.
11.1 Connecting the D/A Output Terminal
To avoid electrocution, turn off the power to all devices
before pluggingor unplugging any of the D/A output connec-
tors.
• To prevent damage to the instrument, never connect or discon-
nect the connector with the power on (the D/A output is insulated
from the voltage input and current input).
• Four output channels are available. Exercise great care when
handling, as these channels are not insulated from each other.
• Use the optional 9441 connection cable.
• To prevent damage to the 3169-20/21, do not short-circuit the
output terminal or input a voltage.
