Miscellaneous Measurement Items
Voltage/Current Measurement
Measurement method
Measurement range
Range selection
Measurement accuracy
Crest factor
Active Power Measurement
Measurement range
Measurement accuracy
Power factor influence
Polarity display
Reactive Power Measurement
Measurement range
Reactive-power-meter
method
Measurement accuracy
Influence of the reactive
factor
Polarity display
True RMS type
Voltage: 150.00/300.00/600.00 V
Current:
When the 9669 (0.5 mV/A) is used
When the 9661/9695-03 (1 mV/A) is used: 5.0000/10.000/50.000/
When the 9660 (1 mV/A) is used: 5.0000/10.000/50.000/100.00 A
When the 9667 5000 A range (0.1 mV/A) is used : 5.0000 kA
When the 9667 500 A range (1 mV/A) is used
When the 9694 (10 mV/A) is used : 500.00 m/1.0000/5.0000 A
When the 9695-02 (10 mV/A) is used: 500.00 m/ 1.0000/ 5.0000/
(Selectable separately for each circuit)
Manual range (separate current range selectable for each circuit)
±
±
Voltage:
0.2%rdg.
0.1%f.s.
±
±
Current:
0.2%rdg.
0.1%f.s. + clamp-on-sensor specification
Voltage: 2 or less (for full-scale input)
Current: 4 or less (for full-scale input, 2 or less with the 500 A, 1 kA,
and 5 kA ranges)
Depends on the voltage x current range combination.
± 0.2%rdg. ± 0.1%f.s.+ clamp-on-sensor specification (power factor = 1)
±
1.0%rdg.
(45 to 66 Hz, power factor = 0.5)
For (consumption) No symbol
For (regeneration) "-"
Depends on the voltage x current range combination.
Not used: Calculate using the voltage, current, and active-power
measurements.
Used: Measure the reactive power directly using the reactive-power-
meter method.
When the reactive-power-meter method is not used
Each calculation result
When the reactive-power-meter method is used
±
±
0.2%rdg.
0.1%f.s. + clamp-on-sensor specification
(reactive factor = 1)
±
1.0% rdg. (45 Hz to 66 Hz; reactive factor = 0.5; reactive-power-
meter method used)
For lag phase (LAG: current is slower than voltage): no symbol
For lead phase (LEAD: current is faster than voltage): "-"
(Only when the reactive-power-meter method is used)
: 100.00/200.00/1.0000k A
100.00/500.00 A
10.000/ 50.000 A
±
1 dgt.
173
13
2
: 500.00 A
3
4
5
6
7
8
9
10
11
