RS-232C Interface
The 3169-20/21 includes an RS-232C interface as standard equipment.
The instrument is connected to a PC by the interface, and is used for
automated measurement.
High-Speed D/A Output (3169-21 only)
The 3169-21 features D/A output for 4-channel, high-speed analog
output.
Compact and light weight
The compact size and light weight allows installation even in lim-
ited space, such as in a cubicle.
A choice of optional clamp-on sensors
The following clamp-on sensors are compatible with the 3169-20/21.
9660 CLAMP ON SENSOR (100 A rms rating)
9661 CLAMP ON SENSOR (500 A rms rating)
9667 FLEXIBLE CLAMP ON SENSOR (5000 A rms rating)
9669 CLAMP ON SENSOR (1000 A rms rating)
9694 CLAMP ON SENSOR (5 Arms rating)
9695-02 CLAMP ON SENOSR (50 Arms rating)
9695-03 CLAMP ON SENSOR (100 Arms rating)
15
Features
