This is the photo of the rear cover.

Left cover removal

Warning: Do not interchange screws during reinstallation, as it may damage the machine. Always take note of
their original placement.
1.
Remove the power supply. See
2.
Remove the duplex unit. See
3.
Remove the rear cover. See
4.
Press the scanner latch handle (A) to release the ADF/scanner assembly.
5.
Open the ADF/scanner assembly.
"Power supply removal" on page
"Duplex unit removal" on page
"Rear cover removal" on page
A
4-10.
4-11.
4-25.
Repair information
4447-20x
Previous
Next
Go Back
Disassembly
Flow chart
4-26
