7. Parts catalog

How to use this parts catalog

The following legend is used in the parts catalog:
Asm- Part
index number
•
Asm-index: Identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and item number 1 in the table.
•
Part number: Identifies the unique number that identifies this FRU.
•
Units/mach: Refers to the number of units actually used in the base machine or product.
•
Units/option: Refers to the number of units in a particular option. It does not include the rest of the base
machine.
•
Units/FRU: Refers to the number of units packaged together and identified by the part number.
•
NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
•
PP: (Parts Packet) in the parts description column indicates the part is contained in a parts packet.
•
Model information used in the parts catalog:
Machine type
4447-200
(US/CAN/LAD/APG)
4447-20E
(EMEA/AUS/JAPAN)
4447-200
(US/CAN/LAD/APG)
4447-20E
(EMEA/AUS/JAPAN)
Units/mach
Units/
- OR -
FRU
Units/option
Model Configuration
Pro5500t High MFP
Duplex ADF
550-sheet standard second
tray
Pro5500 High MFP
Duplex ADF
Description Removal procedure
4447-20x
