Configuration Procedure:
Step Operation
1 Bind the IP address, MAC
address, VLAN ID and the
connected Port number of
the Host together.
2 Enable the protection for the
bound entry.
3 Specify the trusted port.
4 Enable ARP Detect feature.

12.3.2 ARP Defend

With the ARP Defend enabled, the switch can terminate receiving the ARP packets for 300
seconds when the transmission speed of the legal ARP packet on the port exceeds the defined
value so as to avoid ARP Attack flood.
Choose the menu Network Security→ARP Inspection→ARP Defend to load the following page.
Description
Required. On the IP-MAC Binding page, bind the IP
address, MAC address, VLAN ID and the connected Port
number of the Host together via Manual Binding, ARP
Scanning or DHCP Snooping.
Required. On
Binding→Binding Table page, specify a protect type for
the corresponding bound entry.
Required. On
Inspection→ARP Detect page, specify the trusted port.
The specific ports, such as up-linked port, routing port
and LAG port, should be set as Trusted Port.
Required. On
Inspection→ARP Detect page, enable the ARP Detect
feature.
Figure 12-16 ARP Defend
204
the
Network Security→IP-MAC
the
Network
the
Network
Security→ARP
Security→ARP
