8.1.8 Packet Statistics

On this page you can view the multicast data traffic on each port of the switch, which facilitates you
to monitor the IGMP messages in the network.
Choose the menu Multicast→IGMP Snooping→Packet Statistics to load the following page.
Displays the LAG number which the port belongs to.
Click the ClearBinding button to clear all profiles bound to the
port.
Description
Required. Configure
Multicast→IGMP Snooping→Profile Config page.
Required. Click Edit of the specified entry in the IGMP Profile
Info table on Multicast→IGMP Snooping→Profile Config
page to configure the mode or IP-range of the Profile.
Optional. Configure
Multicast→IGPM Snooping→Porfile Binding page.
Figure 8-12 Packet Statistics
