Clear Binding:
Configuration Procedure:
Step Operation
1 Create Profile
2 Configure IP-Range
3 Configure Profile Binding
for ports

8.2.8 Packet Statistics

On this page you can view the MLD packets the switch received. It helps you to monitor the MLD
snooping function.
Choose the menu Multicast→MLD Snooping→Packet Statistics to load the following page.
Click the Clear Binding button to clear all profiles bound
to the port.
Description
Required. Configure
Multicast→MLD Snooping→Profile Config page.
Required. Click Edit of the specified entry in the MLD Profile
Info table on Multicast→MLD Snooping→Profile Config
page to configure the mode or IP-range of the Profile.
Optional. Configure
Multicast→MLD Snooping→Porfile Binding page.
Figure 8-21 Packet Statistics
136
the Profile ID and
Profile Binding for
mode on
ports on
