Forbidden Router
Ports:
Note:
1. The Multicast VLAN won't take effect unless you first complete the configuration for the
corresponding VLAN owning the port on the 802.1Q VLAN page.
2. The router port should be in the multicast VLAN, otherwise the member ports cannot receive
multicast streams.
3. Configure the link type of the router port in the multicast VLAN as Tagged otherwise all the
member ports in the multicast VLAN cannot receive multicast streams.
4. Before creating a Multicast VLAN, you should enable the MLD snooping function in
Snooping Config.
5. After a multicast VLAN is created, all the MLD packets will be processed only within the
multicast VLAN.
Configuration Procedure of Multicast VLAN:
Step Operation
1 Create VLAN.
2 Enable MLD snooping
globally.
3 Enable the Multicast VLAN.

8.2.5 Querier Config

In an IPv6 multicast network that runs MLD, a Layer 3 multicast device works as an MLD querier to
send out MLD queries and manage the multicast table. But MLD is not supported by the devices in
Layer 2 network. MLD Snooping Querier can act as an MLD Router in Layer 2 network. It can help
to create and maintain multicast forwarding table on the switch with the Query messages it
generates.
Specify the forbidden router ports which is mainly used to forbid
ports becoming router ports.
Description
Required. On the VLAN →802.1Q VLAN →VLAN Config
page, click the Create button to create a VLAN. Enter the
VLAN ID and the description for the VLAN. Meanwhile,
specify its member ports.
Required. On the Multicast →MLD Snooping →Global
Config page, enable the MLD snooping function globally.
Required. On the Multicast →MLD Snooping →Multicast
page, enable the Multicast VLAN function and specify the
Multicast VLAN ID as the VLAN specified in Step 1.
131
