TP-Link TD-8817 Qig

Note
The product model shown in this QIG is TD-8817, as an example.
Turn off all of your network devices, including your computer and the Modem
Router. If you currently use a modem, disconnect it now - the Modem Router
will replace your current modem.
Connect your computer to the Port
labeled "LAN" on the Modem
Router with an Ethernet cable.
Connect the splitter to the wall
j ack using a telephone line, then
use the other telephone line to
directly connect it to the LINE port
on the Modem Router and the
MODEM port of the splitter, also
have the PHONE port of the
splitter connected to a telephone.
Plug the provided Power Adapter
into the Power jack on the back of
the Modem Router and the other
end to a standard electrical wall
socket.
1
