Replacing the staple cartridge in the stapler unit
Replacing the staple cartridge in the stapler unit
Introduction
This section describes the procedure for replacing the staple cartridge in the optional Finisher-
AJ1 or Saddle Finisher-AJ2.
IMPORTANT
Take care when handling the optional equipment that is attached to the machine. When an
optional unit's cover is opened to replace a staple cartridge, discard punch waste, or clear paper
or staple jams, prints may still be output if other optional units are operating normally, and are
not involved in the paper or staple jam removal procedure.
NOTE
We recommend that you order staple cartridges from your local authorized dealer before your
stock runs out.
Procedure
1.
Open the front cover of the finisher.
2.
Pull out the staple case from the stapler unit, holding it by its green tab.
NOTE
When the stapler unit is at the back and it is difficult to pull out the staple case, turn the dial on
the bottom left hand side to the left to move the stapler unit.
3.
Pull out the staple cartridge.
334
Chapter 13 - Add toner and staples
