Replacing the staple cartridge in the saddle stitcher unit
4.
Open the staple case cover by pressing the area indicated in the illustration.
Hold the staple case cover by its left and right sides, and then lift it and slide it off.
5.
Lift and pull out the empty staple cartridge.
Squeeze the arrow indicated in step 4 (and its twin on the opposite side) to release the empty
staple cartridge.
6.
Insert the new staple cartridge until it clicks into place.
IMPORTANT
When replacing the staple cartridges, replace both the front and back staple cartridges.
7.
Close the staple case cover.
338
Chapter 13 - Add toner and staples
