Canon IMAGEPRESS C7011VPS SERIES Operation Manual page 133

IMPORTANT
If you have loaded a second stack of paper for fine adjustment, make sure to remove it after
adjusting the outer size change plate. Leaving the second stack of paper in the paper tray may
lead to a paper tray malfunction.
13. Remove the spacer, and store it in the back of the rear edge retainer.
14.
Align the rear edge retainer with the marks of the desired paper size.
15. When you have finished aligning the rear edge retainer with the marks for the desired paper size,
fasten the rear edge retainer to the outer size change plate with the blue screw using a coin or
something similar.
16. Make sure that the inside lifter has lowered, and load the remaining paper into the paper tray.
Adjust the outer size change plate of the bulk paper module (optional)
Chapter 7 - Media handling 133
