5.
Remove the two blue screws on the outer size change plate using a coin or something similar.
IMPORTANT
Do not loosen or remove any screw other than the two blue screws on the outer size change
plate.
6.
Lift up the outer size change plate.
7.
Align the outer size change plate with the marks for the desired paper size that you want to load.
(SRA3)
320mm
450mm
483mm
330mm
13 19
12 /
5
17 /
11
8
16
305mm
457mm
A4/A3
12 18
11 17/LTR
B5/B4
A4
R
LGL/LTR
R
Adjust the media size for the bulk media module (optional)
Chapter 7 - Media handling
123
