3.
Unlock the lever of the size change plate.
4.
Slide the outer size change plate and the inner size change plate to the left as far as they will go.
5.
Embed the location fix frame, located on the back side of the tab feeder, to the hole of the lifter.
IMPORTANT
Embed the location fix frame in the hole of the lifter properly to prevent a paper jam or the paper
tray from being damaged. Check that the tab feeder is installed properly from its hole on the top.
6.
Load approximately 10 sheets of tab paper while lifting up the tab of the paper holder.
Load tabs via the tab feeder (optional)
Chapter 7 - Media handling
141
