Canon IMAGEPRESS C7011VPS SERIES Operation Manual page 71

Number
2
3
4
Function
Display the file name of the current job (for document printing) or cur-
rent stream (for stream printing). Furthermore, the progress of the cur-
rent job is displayed.
For document printing, the counter can display the following informa-
tion.
• Set X of Y
• Sheet X of Y or Sheet X.
X represents the current status of the print job. Y represents the total
number of sets or sheets of a print job.
When the sorting method for a job is set to By set and a set contains at
least 40 pages, then the dashboard displays the set count (Set X of Y).
When the sorting method for a job is set to By page, or when you print
stream jobs, then the dashboard only displays a sheet count.
Display the action that you must do now or soon. The colors of the ver-
tical status bar at the left-hand side match the colors of the LED on the
operator panel and the operator attention light. When the color is or-
ange or red, a message indicates the required action.
Orange means that action is required soon. How long before an up-
coming action the operator panel starts to display the message de-
pends on the defined warning time.
Red means that action is required now.
Displays a status action when you must do something now or soon re-
garding the following items.
• Printer calibration
• Finishers.
• Staple cartridges.
• Toner reservoir.
Chapter 5 - Operator panel views
The dashboard
71
