Canon IMAGEPRESS C7011VPS SERIES Operation Manual page 125

IMPORTANT
There are two screw holes for fastening the rear edge retainer. Make sure that the rear edge
retainer is fastened properly, aligned with the marks for the desired paper size, to prevent it from
being installed at an angle.
11.
Remove the two blue screws on the inner size change plate using a coin or something similar.
12.
Lift up the inner size change plate.
NOTE
Hot air that is blown by the fan may warm the size change plate.
13.
Align the inner size change plate with the marks for the desired paper size.
Adjust the media size for the bulk media module (optional)
Chapter 7 - Media handling 125
