Canon IMAGEPRESS C7011VPS SERIES Operation Manual page 165

Setting
[Binding]
[Trimming]
Settings for the whole job
Setting
[Job name]
[Number of
sets]
[Page range]
[Separator
sheets]
Values Description
[None] Here you can define the required number of staples. Further-
more you can define where you want the staples with the
[Location] option.
The available locations for the 1 staple option:
[1 staple]
• [Top left]
• [Top right]
• [Bottom left]
• [Bottom right]
[2 staples]
The available locations for the 2 staples option:
• [Left edge]
• [Top edge]
[Saddle stitch-
• [Bottom edge]
ing]
• [Right edge]
Check the preview for the result of the selection.
[Saddle press-
ing]
[None]
Trims the long edge, top edge and bottom edge according to
the specified values. The minimum trim size is 2 mm / 0.02".
[Trim size]
Trims the prints to a selected default size, for example A4,
A5 etc. You can also define a custom size.
[Finishing size]
Values Description
Displays the job name of the print job. You can change the
job name of a print job.
Use this setting to define the number of copies. You can en-
ter a value from 1 - 65,000. The default value is 1.
Displays the pages to print. When [All] is selected, all pages
of the job will be printed. When you touch the [Page range]
button a keyboard appears. You can define the page range
you want to print.
[On] When the Separator sheets setting is enabled, a separate
sheet will be inserted automatically before each set of a job
to create a clear distinction between two sets. Separator
sheets are always empty. In the Settings Editor, you can se-
lect a media from the Media catalog to be used as separator
sheets. There you can also indicate the feed direction of the
separator sheets (long-edge feed or short-edge feed).
[Off] No separator sheet will be inserted before each set.
Description of the print job settings
Chapter 8 - Carry out print jobs 165
