Meridian Link/Customer Controlled Routing Installation And Upgrade Manual page 65

The LEDs show the following conditions:
¥
PWR indicator
¥ This yellow LED is lit almost continuously when an
Run indicator
application is running, but flickers every few seconds.
¥
SCSI indicator
use. The intensity varies according to the amount of data movement.
¥ This red LED is lit continuously when a hardware
Fail indicator
failure occurs on the SBC card. It is normal for this indicator to flash
while diagnostics are being run (after power-on or during rebooting).
The switches perform the following functions:
¥
Power pushbutton
Module.
¥
ABORT button
and returns control to the debugger. Do not press this button. If you
accidentally press it, all software operations will stop and you will be in
the firmware debugger. In this case, press the red
immediately to reboot the system. Software diagnostics during system
boot will attempt to repair possible file system damage caused by the
non-standard shutdown.
¥
RESET button
a self test and then reboots. Do not press the button while an
application is running. Exit the application and prepare the system for
powering down before pressing the
the system controller, this button also generates a VME bus system
reset. The software powerdown procedure is provided in
Chapter 14, ÒSoftware installation, upgrade, and update procedures.Ó
!
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Chapter 4: Meridian Link/CCR hardware 47
This green LED is lit when power is turned on.
This yellow LED is lit almost continuously when in
This pushbutton turns power on and off the IPE
This button, when pressed, stops program execution
This button invokes a cold restart. The system performs
RESET
CAUTION
Risk of data loss
Do not press both the
the same timeÑyou risk losing device configuration
information.
button
RESET
button. If the SBC card is
and buttons at
ABORT RESET
