160 Chapter 9: Meridian Link/CCR interface cabling
Table 47
NT1R03BA 50-pin four-port cable pinout (IPE Module)
From
To
DB-50
DB-25
1
7
2
2
3
4
4
6
5
7
6
2
7
4
8
6
9
7
10
2
11
4
12
6
13
15
14
22
15
7
16
2
17
4
18
6
19
15
20
22
21
22
23
24
25
553-3202-210 Standard October 1998
Port
Signal
name
2
GND2
2
TXD2
2
RTS2
2
DSR2
4
GND4
4
TXD4
4
RTS4
4
DSR4
6
GND6
6
TXD6
6
RTS6
6
DSR6
6
TXCI6
6
RI6
8
GND8
8
TXD8
8
RTS8
8
DSR8
8
TXCI8
8
RI8
NC
NC
NC
NC
FGND
FGND
From
To
DB-50
DB-25
26
8
27
3
28
5
29
20
30
8
31
3
32
5
33
20
34
8
35
3
36
5
37
20
38
17
39
24
40
8
41
3
42
5
43
20
44
17
45
24
46
47
48
49
50
Port
Signal
name
2
DCD2
2
RXD2
2
CTS2
2
DTR2
4
DCD4
4
RXD4
4
CTS4
4
DTR4
6
DCD6
6
RXD6
6
CTS6
6
DTR6
6
RXCI6
6
TXCO6
8
DCD8
8
RXD8
8
CTS8
8
DTR8
8
RXCI8
8
TXCO8
NC
NC
NC
NC
FGND
FGND
