Table of Contents

Advertisement

Quick Links

Meridian 1
Meridian Link/Customer Controlled Routing
Installation and Upgrade Guide
Publication number:
Product release:
Document status:
Date:
© 1998 Northern Telecom
All rights reserved
Printed in the United States of America
Northern Telecom reserves the right to make changes in equipment, design, or components as progress in
engineering or manufacturing may warrant.
Meridian 1, SL-1, and Nortel are trademarks of Northern Telecom. UNIX is a trademark of AT&T. Motorola is a
trademark of the Motorola Corporation. MVME products are trademarked by the Motorola Corporation.
Ethernet is a trademark of the Xerox Corporation. Reflection is a trademark of Walker Richer & Quinn, Inc.
DEC, VT220, VT320, and VT420 are trademarks of Digital Equipment Corporation. UDS is a trademark of
Motorola Incorporated.
553-3202-210
Meridian Link Release 5C/Customer Contolled Routing Release 3C
Standard 1.0
October 1998

Advertisement

Table of Contents
loading

Related Manuals for Meridian Link/Customer Controlled Routing

Summary of Contents for Meridian Link/Customer Controlled Routing

  • Page 1 Meridian 1 Meridian Link/Customer Controlled Routing Installation and Upgrade Guide Publication number: 553-3202-210 Product release: Meridian Link Release 5C/Customer Contolled Routing Release 3C Document status: Standard 1.0 Date: October 1998 © 1998 Northern Telecom All rights reserved Printed in the United States of America Northern Telecom reserves the right to make changes in equipment, design, or components as progress in engineering or manufacturing may warrant.
  • Page 2 553-3202-210 Standard October 1998...
  • Page 3 Publication history October 1998 Standard 1.0 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 4 Publication history 553-3202-210 Standard October 1998...

  • Page 5: Table Of Contents

    Contents About this guide References Chapter 1: Meridian Link/CCR Co-residency overview Keycode Ethernet LAN-based PC Module address and module name Chapter 2: Overview of Meridian Link Meridian Link application Operating system overview New with Meridian Link Release 5C Link overview AML and the Host Link (or Meridian Link) Meridian Mail Link Diagnostic tools...
  • Page 6 Contents Chapter 3: Overview of Customer Controlled Routing CCR application An example of CCR call handling Key CCR concepts Operating system New with CCR Release 3C Application Module Link Diagnostic tools System console and maintenance console CCR administration and maintenance Consoles/printers Meridian 1 Hardware overview...
  • Page 7 Chapter 5: Hardware installation overview Preparing for installation Installing an IPE Module or an Application Module Chapter 6: Site survey/installation checklist General information End user Distributor Nortel support representative Delivery information Customer site Freight company Loading equipment required Meridian 1 software checklists Requirements for Meridian Link Requirements for CCR Requirements for Meridian Mail to support Meridian Link...
  • Page 8 viii Contents Chapter 7: Unpack and inspect hardware Receiving the IPE Module and Application Module components Unpacking the IPE Module and Application Module components Chapter 8: Hardware installation procedures Installing the IPE Module Installing the Application Module Installing the power supply and disk/tape unit Checking the card option settings (Application Module) Installing an NTAK02 SDI/DCH card Installing an ESDI or MSDL card...
  • Page 9 Chapter 10: Installing peripheral devices VT220, VT320, and VT420 terminals Personal computer running Reflection 4+ Meridian Terminal Emulator (MTE 8) Dot-matrix printer switch settings LaserJet series II printer switch settings LaserJet series III printer switch settings LaserJet series IV printer switch settings DeskJet and DeskJet 500 printer switch settings Chapter 11: Peripheral device cabling interface 273 DCE and DTE connections...
  • Page 10 Contents Configure devices for status change host notification Define status message groups Assign telephones to status message groups (Meridian Link) Configure ACD DNs Configure Control DNs (CCR) Configuring a Phantom Loop Configuring a Phantom Superloop Creating a Phantom Set Configuring Dual VAS ID Traffic statistics Chapter 13: Meridian Mail configuration Meridian Mail call processing...
  • Page 11 Section 6: To upgrade Meridian Link from Release 4B to Release 5C and Co-residency Section 7: To update Meridian Link from Release 5 to Release 5C Section 8: To update Meridian Link from Release 5 to Section 9: To upgrade CCR from Release 2 to Release 3C Section 10: To update CCR from Release 3 to Release 3C 384 Section 11: To update CCR from Release 3 to Co- residency...
  • Page 12 Contents Chapter 15: Link configuration Default configuration Link 0ÑApplication Module Link Link 1ÑX.25 protocol Link 1ÑTCP/IP host link protocol Link 2ÑMeridian Mail Link Changing your configuration Procedure 12: Verifying the link status Procedure 13: Changing AML (link 0) parameters Procedure 14: Changing Meridian Link (link 1) parameters 489 Procedure 15: Changing Meridian Mail Link (link 2) parameters Procedure 16: Replacing the default configuration file...
  • Page 13 Chapter 18: Acceptance testing Meridian Link/CCR Meridian Mail Using Edit Voice to create voice segment files Recording and trimming voice segments Creating a header file Using Edit Voice for the first time Example of customer account balance query Chapter 19: Single Terminal Access Hardware and software requirements Before you begin Setting up STA...
  • Page 14 Contents 553-3202-210 Standard October 1998...

  • Page 15: About This Guide

    About this guide This document details the steps and procedures required to successfully install the hardware and software for your Meridian Link and/or Customer Controlled Routing (CCR) system. Meridian Link enables the call and voice processing capabilities of a Meridian 1 system to be integrated with a customerÕs computer-based business applications.
  • Page 16 About this guide Chapter 3: Overview of Customer Controlled Routing provides an overview of CCR, describes its concepts, and lists required hardware and software. Chapter 4: Meridian Link/CCR hardware overview of hardware components. Chapter 5: Hardware installation overview provides tables to describe the installation of an IPE Module or an Application Module.
  • Page 17 Chapter 13: Meridian Mail configuration configure the Meridian 1 to support Meridian Mail. Chapter 14: Software installation, upgrade, and update procedures This chapter describes procedures for ¥ configuring the IPE Module and the Application Module, along with start-up information ¥ upgrading the software from one release to another (for example, from Meridian Link Release 4B to Release 5C) ¥...

  • Page 18: References

    Application Module and Intelligent Peripheral Equipment Module Diagnostic and Maintenance Guide (NTP 553-3211-510) ¥ Application Module and Intelligent Peripheral Equipment Module Advanced Maintenance Guide (NTP 553-3211-512) ¥ Meridian Link/Customer Controlled Routing Engineering Guide (NTP 553-3211-520) ¥ Customer Controlled Routing User Guide (P0747008) 553-3202-210 Standard October 1998...

  • Page 19: Chapter 1: Meridian Link/Ccr

    Chapter 1: Meridian Link/CCR co-residency Co-residency overview With Meridian Link Release 5C and CCR Release 3C, you can install both Meridian Link and CCR in a single IPE Module or Application Module. You should be aware that both applications use the same CPU, RAM, and hard disk, so you cannot expect the same performance from a co-resident application as you would get from a stand alone application.
  • Page 20 Chapter 1: Meridian Link/CCR co-residency Figure 1 Meridian Link/CCR co-residency 553-3202-210 Standard October 1998 Host Link Host IPE Module Meridian Link Meridian 1...
  • Page 21 This guide provides more detailed information on both the Meridian Link and CCR applications in the following chapters: ¥ Chapter 2, ÒOverview of Meridian LinkÓ ¥ Chapter 3, ÒOverview of Customer Controlled RoutingÓ If you intend to activate both Meridian Link and CCR in an Application Module, the Application Module must have an MVME332XTS ACC card and an NT6D51AA transition card installed.

  • Page 22: Keycode

    Chapter 1: Meridian Link/CCR co-residency Keycode IPE or Application Module software may or may not be pre-loaded: ¥ If the module is shipped to the United States, Europe, or Japan, the software is likely to be already loaded. ¥ If the module is shipped to a Caribbean or Latin American location, to Canada, or to the Asia Pacific region, the software may not be loaded.

  • Page 23: Ethernet Lan-Based Pc

    Ethernet LAN-based PC Meridian Link and CCR co-residency also provides support for an Ethernet LAN-based PC. This networking service is included for all Meridian Link and CCR customers. Note: Support for an Ethernet LAN-based PC should not be confused with support for an Ethernet LAN-based host. For more information on Ethernet LAN-based host connections, refer to ÒEthernet LAN-based hostÓ...
  • Page 24 Chapter 1: Meridian Link/CCR co-residency The Ethernet LAN-based PC must ¥ be fully compatible with an IBM PC (AT or higher) ¥ have a 20-Mbyte hard disk or larger ¥ have 1 Mbyte of RAM with at least 384 Kbytes free ¥...

  • Page 25: Module Address And Module Name

    For Ethernet LAN support, Application Modules must contain: ¥ an MVME167-02 SBC card ¥ an MVME712M transition card ¥ a generic I/O panel ¥ NT7D47DA and NT7D47EA cables For more information about installing the NT7D47DA and NT7D47EA cables, refer to Procedure 28: Installing the cables for Ethernet LAN support (Application Module) in Chapter 17, ÒHardware upgrade.Ó...
  • Page 26 Chapter 1: Meridian Link/CCR co-residency The module address is a 4-byte (32-bit) address expressed as four decimal numbers separated by dots (such as 123.45.68.8). The module name can have as many as eight alphanumeric characters. See your network administrator for more information on creating a module address and a module name.

  • Page 27: Chapter 2: Overview Of Meridian Link

    Chapter 2: Overview of Meridian Link Meridian Link is an application that allows a Meridian 1 system to exchange information with a host computer so that users can integrate the capabilities of both into a business application. An order desk clerk, for example, can see information about an incoming call (for example, the callerÕs name, address, and calling history) on a computer screen while the telephone is still ringing.
  • Page 28 Chapter 2: Overview of Meridian Link Figure 2 Meridian Link hardware connections (IPE Module) Meridian IVR Meridian Link IPE Module (or AM) Host Link (X.25) Host Link (TCP/IP) Host computer Remote system console Host computer 553-3202-210 Standard October 1998 Meridian Mail Command and Status Link (CSL) Meridian Mail...
  • Page 29 Figure 3 Meridian Link hardware connections (Application Module) Meridian Mail Meridian Mail Link (MML) Host computer Meridian Link (X.25 or TCP/IP) System console Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 2: Overview of Meridian Link 11 Command and Status Link (CSL) optional...
  • Page 30 Chapter 2: Overview of Meridian Link Connecting these hardware components requires two (optionally three) signaling links: ¥ Link 0 Meridian 1 system to the IPE Module or the Application Module. ¥ Link 1 computer to the IPE Module or the Application Module. This Host Link can be implemented as a dedicated X.25 link supporting a single host computer or as a TCP/IP Ethernet LAN link supporting as many as 16 Meridian Link applications.

  • Page 31: Meridian Link Application

    Meridian Link application The Meridian Link application enables a host computer to control and monitor telephone functions, such as making a call, answering a call, tracking calls as they move through the Meridian 1 system, and conducting Interactive Voice Response (IVR) sessions with a call. To provide the required communication, Meridian Link passes messages back and forth between a host computer and the Meridian 1 system, and between a host computer and Meridian Mail system, through the Meridian...

  • Page 32: New With Meridian Link Release 5C

    Chapter 2: Overview of Meridian Link New with Meridian Link Release 5C The Meridian Link Release 5C introduces the following new features: ¥ redundant Meridian Link ¥ dual VAS ID ¥ expanded DNIS support ¥ SFN (login) message with agent ID Redundant Meridian Link Link between the Meridian 1 and the host to increase the reliability of the CTI interface.

  • Page 33: Link Overview

    SFN (login) message with agent ID message to the host application when an AST/Acquired agent logs in by manually pressing the MSB key on the ACD set or by invoking the ACD set feature through the Set Feature Invocation (Login) message. The existing SFN Login message has been enhanced to provide an optional four-digit Agent ID at the time of logging, enabling the agent to log in at different positions.

  • Page 34: Meridian Mail Link

    Chapter 2: Overview of Meridian Link Note: When setting up a redundant Meridian Link, two communication paths must be set up to two separate Meridian Link modules. This may involve two X.25 ports or two TCP/IP addresses. Meridian Mail Link The MML is an optional asynchronous link that connects the IPE Module or Application Module to a Meridian Mail system running software version MM8 (or later) with the Access Enable option.

  • Page 35: System Console And Maintenance Console

    System console and maintenance console You can use a customer-supplied console to enter OA&M commands to the IPE Module or the Application Module. The console should be an asynchronous ASCII terminal that is 100 percent compatible with ANSI and DEC VT220. You can use an IBM-compatible personal computer running Reflection 4+.

  • Page 36: Host Support Service Requirements

    Chapter 2: Overview of Meridian Link You can also use commands to do the following: ¥ back up and restore configuration and data files ¥ display how much disk space has been used up ¥ verify files ¥ delete files ¥...
  • Page 37 Ñ QPC513 Enhanced Serial Data Interface (ESDI) card (vintage G or later) Ñ NT6D80 Multi-purpose Serial Data Link (MSDL) card Ñ (Option 11 only) NTAK02AB Serial Data Interface/D-Channel Interface (SDI/DCH) card Ñ If using a redundant Meridian Link, two AML connections are required.
  • Page 38 Upgrading the MVME147 AM with an MVME167 card is not equivalent to an MVME167 AM therefore Meridian Link 5C using TCP/IP transport is not supported. ** Refer to the Meridian Link/Customer Controlled Routing Engineering Guide (NTP 553-3211-520) for details on the MVME147 CPU card. 553-3202-210 Standard October 1998...

  • Page 39: Software Overview

    Software overview The Meridian 1 must be equipped with the following release of software: ¥ X11 Release 17 or later for Meridian 1 systems using Meridian Link Release 4 ¥ X11 Release 20 or later for all Option 11 systems (X11 Release 18 will be supported in Europe) ¥...
  • Page 40 Chapter 2: Overview of Meridian Link Table 2 X11 software compatibility matrix Application Rls. 17 Meridian Link 4B Meridian Link 4B and CCR 3B Meridian Link 5 Meridian Link 5 and CCR 3B Meridian Link 5 Upissue and CCR 3B Meridian Link 5C and CCR 3C Other software options may be required depending on specific application...

  • Page 41: Host

    Host This section describes the services and software that Meridian Link requires to support the connection to the host computer. Normally these services are bundled in marketing packages that may vary by market. Meridian Link service requirements Meridian Link requires specific software services to be installed in the IPE Module or Application Module to support the host connection.

  • Page 42: Host Connection Considerations

    Chapter 2: Overview of Meridian Link Host connection considerations The link to the host computer should be installed and configured following the host manufacturerÕs recommendations. The host may establish one of the following, depending on the type of host computer: ¥...
  • Page 43 Ethernet support is automatically enabled during application installation. All NSE files will be loaded to the hard disk for configuration by the customer during installation. To configure the NSE, see Procedure 8 in Chapter 14, ÒSoftware installation, upgrade, and update procedures.Ó Note: If you do not intend to provide Ethernet LAN-based communications on your system, you should disable the support during application installation (you do this by entering the appropriate...

  • Page 44: Meridian Mail Software Requirements

    Chapter 2: Overview of Meridian Link Meridian Mail software requirements A Meridian Mail system can be connected to the IPE Module or Application Module to provide voice-processing capability to an application based on Meridian Link. The link between the IPE Module or Application Module and the Meridian Mail system is called the Meridian Mail Link (MML).

  • Page 45: Chapter 3: Overview Of Customer Controlled Routing

    Chapter 3: Overview of Customer Controlled Routing Customer Controlled Routing (CCR) is a product that enables you to control and route Automatic Call Distribution (ACD) calls entering your Meridian 1 system. For example, for an incoming ACD call, you can provide a specific recorded announcement, music, or both, before assigning the call to an agent.
  • Page 46 Chapter 3: Overview of Customer Controlled Routing Figure 4 CCR hardware connections (IPE Module) Printer Cable NT1R03BA Terminal 553-3202-210 Standard October 1998 PC using Reflection 4+ Printer Meridian 1 IPE Module installed in a Meridian 1 Cable NT1R03AA Maintenance Console...
  • Page 47 Figure 5 CCR hardware connections (Application Module) Remote Diagnostics Printer Maintenance Console Application Module installed in a Meridian 1 The key software required to make these hardware components and links work together is the CCR application, which resides in the IPE Module or the Application Module.

  • Page 48: Ccr Application

    Chapter 3: Overview of Customer Controlled Routing CCR application CCR works with the Automatic Call Distribution (ACD) feature on your Meridian 1 to give you more control over the handling of incoming calls. Each call coming through an ACD queue can be given individualized handling and treatment.

  • Page 49: Key Ccr Concepts

    ¥ For elite clients Any incoming call coming from telephone number XXX or YYY goes into the ACD queue with a higher priority (using the Calling Line Identification, or CLID, feature). ¥ Sales for all products Any incoming call to DN 1234 goes into the ACD queue for the sales group.

  • Page 50: New With Ccr Release 3C

    Chapter 3: Overview of Customer Controlled Routing New with CCR Release 3C CCR Release 3C introduces the following new features: ¥ expanded DNIS support ¥ support for 8 "Queue to" commands Expanded DNIS support With CCR Release 5C, the DNIS digits supported have been expanded from seven digits to a maximum of 31 digits.

  • Page 51: Ccr Administration And Maintenance

    An NT1R03D cable connects the customer-supplied console to the IPE Module. An NT7D61 External I/O cable or a customer-supplied 9-pin-to- 25-pin cable connects the customer-supplied console to the Application Module. Refer to Chapter 9, ÒMeridian Link/CCR interface cablingÓ for more information. If you configure the optional conshare capability available to the IPE Module or Application Module, you can access the Meridian 1 input/output programs from the CCR console.

  • Page 52: Hardware Overview

    Chapter 3: Overview of Customer Controlled Routing Meridian 1 This section provides overviews of the Meridian 1 hardware and software required for CCR. Hardware overview One of the following system types must be installed and operational: ¥ Meridian 1 system options 21, 51, 61, 71, or 81 (not all system options are supported in all markets) ¥...
  • Page 53 Option 11 systems support an SDI port on any of the following cards: Ñ the CPU/CONF card (NTAK01AB) Ñ the SDI/DCH card (NTAK02AB) Ñ the TDS/DTR card (NTAK03AB) ¥ limited-distance modems for communications facilities if the IPE Module or Application Module is greater than 15 m (50 ft) from the Meridian 1 or peripheral devices, such as terminals and printers An Application Equipment Module (AEM), if present, must be installed in one of the following configurations:...

  • Page 54: Software Overview

    Chapter 3: Overview of Customer Controlled Routing Software overview The Meridian 1 must be equipped with one of the following software releases: ¥ Customer Controlled Routing: X11 Release 17 or later (Release 20 for all Option 11 systems) or X81 ¥...
  • Page 55 Chapter 3: Overview of Customer Controlled Routing 37 ¥ Interactive Voice Response (package 218) if the Hold In Queue for IVR feature is to be used ¥ Call ID (package 247) (requires X11 Release 19 or later) The following software packages (and their prerequisites) are optional for Customer Controlled Routing: ¥...
  • Page 56 Chapter 3: Overview of Customer Controlled Routing 553-3202-210 Standard October 1998...

  • Page 57: Chapter 4: Meridian Link/Ccr Hardware

    Chapter 4: Meridian Link/CCR hardware Meridian Link and CCR hardware consists of either an IPE Module or an Application Module. This chapter describes both of these modules. Note: If you require a redundant Meridian Link, an additional Meridian Link Module (either an IPE Module or an Application Module) must be installed.
  • Page 58 Chapter 4: Meridian Link/CCR hardware Figure 6 illustrates the IPE Module occupying slots 5Ð7 of the Option 11 main cabinet. Figure 7 illustrates the IPE Module occupying slots 14Ð16 of the expansion cabinet. Figure 6 Option 11 main cabinet AC/DC Pwr Power supply 553-3202-210 Standard October 1998...
  • Page 59 Figure 7 Option 11 expansion cabinet AC/DC Pwr Power supply Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 4: Meridian Link/CCR hardware 41 Meridian 1 Meridian Link SCSI 11 12 13 14 15 16 17 18 19 20 Connector panel...

  • Page 60: Connector Panel And I/O Connectors (Option 11)

    Chapter 4: Meridian Link/CCR hardware Connector panel and I/O connectors (Option 11) Underneath each cabinet of the Option 11 is a connector panel with ten numbered connector ports. Each connector port connects to the corresponding numbered slot directly above it, inside the cabinet. Figure 8 shows the connector panel for the main cabinet, and Figure 9 shows the connector panel for the expansion cabinet.
  • Page 61 Figure 9 Option 11 connector panel (expansion cabinet) Table 6 Option 11 IPE Module connectors used (expansion cabinet) Slots occupied by IPE Module Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 4: Meridian Link/CCR hardware 43 11, 12, 13 12, 13, 14 13, 14, 15 14, 15, 16...
  • Page 62 Chapter 4: Meridian Link/CCR hardware IPE Module Options 21Ð81 In a Meridian 1 Options 21Ð81 system, the IPE Module occupies four consecutive slots on an IPE shelf (Figure 10). Power for the IPE Module comes from the shelfÕs IPE backplane and consists of +5 V and Ð48 V. Figure 10 Options 21Ð81 cabinet - - - -...

  • Page 63: Connector Panel And I/O Connectors (Options 21Ð81)

    Connector panel and I/O connectors (Options 21Ð81) The I/O connectors for the IPE Module installed in an Options 21Ð81 IPE shelf are standard, shielded, 50-pin tip-ring-type connectors on one of the I/O panels in the rear of the IPE shelf containing the module. Each panel has ten connector ports.

  • Page 64: Ipe Module Components

    Chapter 4: Meridian Link/CCR hardware IPE Module components The IPE Module (Figure 12) contains an SMM167 single board computer (SBC) card, a 240-Mbyte disk drive, a 600-Mbyte tape drive, and a CPU adapter card. Only the IPE Module as a whole is field-replaceable. SMM167 single board computer (SBC) card This card, one of the Motorola MVME167 family, consists of the following: ¥...
  • Page 65 The LEDs show the following conditions: ¥ This green LED is lit when power is turned on. PWR indicator ¥ This yellow LED is lit almost continuously when an Run indicator application is running, but flickers every few seconds. ¥ This yellow LED is lit almost continuously when in SCSI indicator use.
  • Page 66 Chapter 4: Meridian Link/CCR hardware Figure 12 IPE Module Hard disk External SCSI connector Tape drive 553-3202-210 Standard October 1998 SCSI SCSI ABORT RESET FAIL SMM167 CPU board Fits to the IPE backplane for power and I/O CPU adapter card...
  • Page 67 Tape drive (IPE Module) The tape drive is a 600-Mbyte cassette tape drive, and cannot be replaced in the field. The following tapes are supplied with the IPE Module: ¥ a 155-Mbyte tape that provides the operating system for the IPE Module ¥...

  • Page 68: Application Module

    Chapter 4: Meridian Link/CCR hardware Application Module An Application Module (AM) is a Versa Module Eurocard (VME) platform that is packaged with the Application Equipment Module (AEM) of a Meridian 1. The AEM is a modified Universal Equipment Module (UEM), and can house two separate Application Modules.
  • Page 69 Table 8 Hardware upgrade paths for Meridian Link Modules Meridian Link Module configuration MVME147 card None required. MVME712AM card Possible upgrade to No NT6D51AA card MVME167 card for Internal modem increased performance AC or DC power (see below). MVME167 card None required.
  • Page 70 Chapter 4: Meridian Link/CCR hardware Table 9 Hardware upgrade paths for CCR Modules CCR Module configuration MVME147 card None required. MVME712AM card Possible upgrade to MVME332 card MVME167 card for NT6D51AA card increased performance Internal modem (see below). AC or DC power MVME167 card None required.

  • Page 71: Aem Power

    AEM power The AEM has an NT7D54AA (for AC power) or NT7D54AB (for DC power) module power distribution unit (MPDU) on the left side (as you face the AEM). The top circuit breaker in the MPDU controls power to the left- side Application Module (closest to the MPDU).

  • Page 72: Application Module Components

    Chapter 4: Meridian Link/CCR hardware Application Module components The Application Module chassis assembly houses the following basic components (order codes for field-replaceable components are listed in Chapter 20, ÒOrderingÓ at the end of this guide): ¥ an MVME147SA-1 or an MVME167-03 single board computer (SBC) card ¥...
  • Page 73 Ñ NT7D62AC: a 240-Mbyte hard disk drive and a 155-Mbyte tape drive ¥ a six-slot VME bus backplane ¥ a power sense card ¥ a SCSI bus interface with direct memory access (DMA) ¥ an input/output (I/O) subpanel, a universal I/O panel, or a generic I/O panel CAUTION Risk of system interruption...
  • Page 74 Chapter 4: Meridian Link/CCR hardware Figure 14 Application ModuleÑfront view CCR/Co-resident Module (left side) Power supply 553-3202-210 Standard October 1998 Meridian Link Module (right side) Disk/tape unit: topÑtape drive bottomÑhard disk drive...
  • Page 75 Figure 15 Application ModuleÑrear view Meridian Link Module Transition cards Part of chassis (cannot be ordered) As shown in Figure 15, slots at the rear of the Application Module house the following cards: ¥ MVME712M (double-width), MVME712A, or MVME712AM transition card ¥...

  • Page 76: Single Board Computer Card (Application Module)

    Chapter 4: Meridian Link/CCR hardware Single board computer card (Application Module) The first VME card slot (left-hand slot) of the Application Module is occupied by the single board computer (SBC) card. One of two cards may be installed, either the MVME147 or the MVME167 card. MVME147SA-1 The MVME147 card consists of the following: ¥...
  • Page 77 There are four light-emitting diodes (LEDs) and two switches on the faceplate of the SBC card, as illustrated in Figure 16. The LEDs show the following conditions: ¥ This red LED is lit continuously when a hardware or Fail indicator software failure occurs on the SBC.
  • Page 78 Chapter 4: Meridian Link/CCR hardware The MVME712 transition card makes all serial I/O connections for the SBC card. The SBC card communicates with the transition card through the P2/J2 connector and the P2 adapter board. The SBC card connects to the VME bus through the P1/J1 connector for address and data signals.
  • Page 79 Chapter 4: Meridian Link/CCR hardware 61 Figure 16 MVME147SA-1 single board computer (SBC) card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 80 Chapter 4: Meridian Link/CCR hardware MVME167-03 This card, one of the Motorola MVME167 family, may be installed in place of the MVME147 card in new modules running Meridian Link and/or CCR. The MVME167 card consists of the following: ¥ MC68040 microprocessor operating at 25 MHz ¥...
  • Page 81 There are eight light-emitting diodes (LEDs) and two switches on the faceplate of the SBC card, as illustrated in Figure 17. The LEDs show the following conditions: ¥ This red LED is continuously lit when a hardware or Fail indicator software failure occurs on the SBC.
  • Page 82 Chapter 4: Meridian Link/CCR hardware ¥ RESET switch performs a self-test and then reboots. Do not press the switch while applications are running. Exit all applications and prepare the system for powering down before pressing the is the system controller, this switch also generates a VME bus system reset.
  • Page 83 Chapter 4: Meridian Link/CCR hardware 65 Figure 17 MVME167-03 single board computer (SBC) card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 84: Mvme333-2 X.25 Communication Controller (Xcc) Card

    Chapter 4: Meridian Link/CCR hardware MVME333-2 X.25 communication controller (XCC) card The MVME333-2 X.25 communication controller (XCC) card occupies the second card slot in the front of the Application Module. This card supports the synchronous data links to the Meridian 1. The XCC card contains the following: ¥...
  • Page 85 Chapter 4: Meridian Link/CCR hardware 67 Figure 18 MVME333-2 X.25 communication controller (XCC) card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 86: Mvme332Xt Or Mvme332Xts Asynchronous Communication Controller (Acc) Card

    Chapter 4: Meridian Link/CCR hardware MVME332XT or MVME332XTS asynchronous communication controller (ACC) card The MVME332XT or MVME332XTS asynchronous communication (ACC) card is used to provide extra terminal/printer ports. The card provides an RS-232 interface between the VME system and the asynchronous serial I/O peripheral devices like the RS-232 modems, printers, and terminals.
  • Page 87 Chapter 4: Meridian Link/CCR hardware 69 Figure 19 MVME332XTS asynchronous communication controller (ACC) card Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 88: Transition Cards

    Chapter 4: Meridian Link/CCR hardware Transition cards The MVME system serial I/O uses various transition cards to route signals to standard external connectors such as DB25, DB9, and RJ11 (teledapt). The transition cards available are the MVME712M, MVME712A, MVME712AM, MVME705B and NT6D51AA. These cards have specific capabilities and hardware configurations.
  • Page 89 Chapter 4: Meridian Link/CCR hardware 71 Figure 20 MVME712M transition card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 90 Chapter 4: Meridian Link/CCR hardware MVME712A and MVME712AM transition cards The MVME712A and MVME712AM cards provide four 9-pin connectors (asynchronous serial ports 1Ð4) and a printer port connector. Additionally, the MVME712AM card provides an RJ11 port. The MVME712AM card (shown in Figure 21) has a built-in modem and is used in countries in which that modem type is approved.
  • Page 91 Chapter 4: Meridian Link/CCR hardware 73 Figure 21 MVME712AM transition card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 92 Chapter 4: Meridian Link/CCR hardware MVME705B transition card This transition card (shown in Figure 22) provides the transceivers that convert the I/O signals from the XCC card to the RS-232 and/or RS-422 standard for serial data communications. A 64-conductor flat ribbon cable connects the transition card to the XCC card.
  • Page 93 Chapter 4: Meridian Link/CCR hardware 75 Figure 22 MVME705B transition card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 94 Chapter 4: Meridian Link/CCR hardware NT6D51AA transition card This custom transition card (shown in Figure 23) provides extra terminal/printer ports for CCR and Co-resident Modules. The card routes signals among the ACC card, the asynchronous user terminals, and the outside world. This card has no optional settings. The NT6D51AA card has a DIN 96-pin connector for a cable that goes to the J2 connector on the VME bus backplane.
  • Page 95 Chapter 4: Meridian Link/CCR hardware 77 Figure 23 NT6D51AA transition card (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 96: P2 Adapter Board

    Chapter 4: Meridian Link/CCR hardware P2 adapter board The P2 adapter board (shown in Figure 24) mounts directly behind the SBC card slot, and connects to the SBC card through the J2 connector on the VME bus backplane. The adapter board provides the following: ¥...

  • Page 97: Power Supply

    Power supply The slide-in power supply (shown in Figure 25) is available in two versions: ¥ NT7D64AA for AC-powered systems ¥ NT7D64DC for DC-powered systems The power supply converts incoming 220 V AC, or Ð48 V DC, to +5 V and ±12 V DC voltages, then distributes these voltages throughout the Application Module.

  • Page 98: Disk/Tape Unit

    Chapter 4: Meridian Link/CCR hardware Disk/tape unit The disk/tape unit (shown in Figure 26) is a slide-in assembly with both a hard disk drive and a cassette tape drive and is used for software installation and backup. A 50-conductor ribbon cable is an integral part of the disk/tape unit, extending the SCSI bus from the SBC card by the P2 adapter board.
  • Page 99 Chapter 4: Meridian Link/CCR hardware 81 Figure 26 Disk/tape unit (Application Module) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 100: Vme Bus Backplane (Application Module)

    Chapter 4: Meridian Link/CCR hardware VME bus backplane (Application Module) The six-slot VME bus backplane provides connections (at J1 and J2) for circuit cards installed in the front of the Application Module. The upper connector, J1, provides access to the VME bus for data signals. The J2 connector at the rear of the backplane provides connections for the transition cards.

  • Page 101: Input/Output Panel

    Chapter 4: Meridian Link/CCR hardware 83 Input/output panel Three versions of the I/O panel are currently used with the Application Module. Many existing installations have application-specific I/O subpanels, as shown in Figure 27. Some installations have a universal I/O panel, as shown in Figure 28. All new installations have a generic I/O panel, shown in Figure 29.

  • Page 102: Standard October

    Chapter 4: Meridian Link/CCR hardware Figure 27 I/O subpanel (Application Module) Host connection (Link 1) 553-3202-210 Standard October 1998 Meridian Link I/O subpanel ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ External Console modem port Meridian Mail connection (Link 2) Meridian 1 connection...
  • Page 103 Figure 28 Universal I/O panel (Application Module) Meridian Mail connection (Link 2) Internal modem if MVME712AM card is installed Meridian 1 SDI* (conshare) *To QSDI, DCH, or MSDL card of the Meridian 1 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 4: Meridian Link/CCR hardware 85 Serial I/O Serial I/O...
  • Page 104 Chapter 4: Meridian Link/CCR hardware Figure 29 Generic I/O panel (Application Module) Meridian Mail connection (Link 2) Meridian 1 OA&M (Conshare) 553-3202-210 Standard October 1998 CARD 5 CARD 4 CARD 3 CARD 2 CONN 3 CONN 3 CONN 3 CONN 3 CARD 5 CARD 4 CARD 3...

  • Page 105: Chapter 5: Hardware Installation Overview

    Chapter 5: Hardware installation overview Preparing for installation As soon as the IPE Module or Application Module is delivered, make sure that all deliverable items are present by checking them against the packing slips. Move the equipment to its permanent location before beginning the installation.

  • Page 106: Installing An Ipe Module Or An Application Module

    Chapter 5: Hardware installation overview Installing an IPE Module or an Application Module This section summarizes the steps required to install an IPEÊModule and an Application Module. It is important to follow the list of procedures in the order in which they appear below.
  • Page 107 IPE or Application Module software may or may not be pre-loaded: ¥ If the Module is shipped to the United States, Europe, or Japan, the software is likely to be already loaded. ¥ If the Module is shipped to a Caribbean or Latin American location, to Canada, or to the Asia Pacific region, the software may not be loaded.
  • Page 108 Chapter 5: Hardware installation overview Table 12 Installing an Application Module Go through Chapter 6, ÒSite survey/installation checklist.Ó Go through Chapter 7, ÒUnpack and inspect hardware.Ó Install an ESDI or MSDL card (if required). See Chapter 8, ÒHardware installation procedures.Ó Install the AEM (Application Equipment Module), if required.

  • Page 109: Chapter 6: Site Survey/Installation Checklist

    Chapter 6: Site survey/installation checklist The purpose of this chapter is to provide a checklist to ensure, when installing new hardware and software for Auxiliary Processors, that all hardware, software, documentation, and cable connection requirements are met to successfully complete a new installation. This document helps you find the current status of Auxiliary Processors, and list possible changes to the current status in determining what hardware, software, and documentation needs to be ordered.

  • Page 110: Distributor

    Chapter 6: Site survey/installation checklist Distributor Name: _______________________________________________________ Address: _____________________________________________________ _____________________________________________________________ Country: ______________________________________________________ Telephone number: _____________________________________________ Primary contact: _______________________________________________ Secondary contact: _____________________________________________ Nortel support representative Name: _______________________________________________________ Address: _____________________________________________________ _____________________________________________________________ Country:______________________________________________________ Telephone number: _____________________________________________ Primary contact: _______________________________________________ Secondary contact: _____________________________________________ 553-3202-210 Standard October 1998...

  • Page 111: Delivery Information

    Delivery information Provide data for authorized personnel to ensure proper delivery of new hardware, software, and documentation. Customer site Address: _____________________________________________________ _____________________________________________________________ Country:______________________________________________________ Telephone number: _____________________________________________ Primary contact: _______________________________________________ Secondary contact: _____________________________________________ Vehicle restrictions: ____________________________________________ Permit(s) required: _____________________________________________ Hours of delivery: ______________________________________________ Security clearance: _____________________________________________ Freight company Pre-delivery notification: ________________________________________...

  • Page 112: Loading Equipment Required

    Chapter 6: Site survey/installation checklist Loading equipment required Responsible party: _____________________________________________ Delivery constraints: ____________________________________________ Elevator capacity: ______________________________________________ Equipment delivery route to the equipment room: _____________________ _____________________________________________________________ Meridian 1 software checklists To check the Meridian 1 software, use the Meridian 1 Overlay program 22 (LD 22) and obtain a printout of: ¥...

  • Page 113: Requirements For Meridian Link

    Requirements for Meridian Link Chapter 2, ÒOverview of Meridian LinkÓ describes the Meridian 1 software requirements in general. To take advantage of the latest MeridianÊLink Release 5 features, X11 Release 22 must be installed. Full support for Release 5 features in international markets requires global X11 Release 22. Release 5C features require X11 Release 24.
  • Page 114 Chapter 6: Site survey/installation checklist Table 14 Meridian LinkÑOptional Meridian 1 software packages Meridian 1 software package BACD 40 (Basic Automatic Call Distribution) DNIS 98 (Dialled Number Identification Service) ACDB 41 (ACD Package B) ACD 42 (ACD Usage Reports) ACD 43 (ACD Load Management) ACDA 45 (ACD Package A) ACDD 50 (ACD MAX applications) EAR 214 (Enhanced ACD Routing)

  • Page 115: Requirements For Ccr

    Requirements for CCR Chapter 3, ÒOverview of Customer Controlled RoutingÓ describes the Meridian 1 software requirements in general. To use CCR Release 3 features, X11 Release 19 must be installed. Full support for Release 3 features in international markets requires global X11 Release 20. With CCR Release 3C, the DNIS digits supported have been expanded from seven digits to a maximum of 31 digits.
  • Page 116 Chapter 6: Site survey/installation checklist Contact your Nortel support personnel if there are any discrepancies. 553-3202-210 Standard October 1998...

  • Page 117: Requirements For Meridian Mail To Support Meridian Link

    Requirements for Meridian Mail to support Meridian Link The following information is for a Meridian Mail system working with Meridian Link. The requirements for a stand-alone Meridian Mail system may be different. ¥ Meridian 1 Generic X11 Release 17 or later ¥...

  • Page 118: Meridian Mail Hardware Checklist To Support Meridian Link

    Chapter 6: Site survey/installation checklist Meridian Mail hardware checklist to support Meridian Link Use the following checklists to check the Meridian Mail hardware. Refer to Meridian Mail System Administration (NTP 555-70XX-301) and System Administration Tools (NTP 555-7001-305) on how to obtain information about Meridian Mail current status.

  • Page 119: Ipe Module And Application Module: Meridian Link/Ccr Software

    IPE Module and Application Module: Meridian Link/CCR software Use the following checklists to check the software and documentation. IPE Module and Application Module: Meridian Link/CCR software current status Use the showid and version commands to obtain the following information: ¥ Meridian Link serial number: _________________________________ ¥...

  • Page 120: Meridian Link/Ccr Tapes And Keycode

    Chapter 6: Site survey/installation checklist Table 17 IPE Module and Application Module software options IPE Module and Application Module Service 1: OA&M Service 95: Obsolete Service 96: Obsolete Service 97: Inbound Call Management Service 98: Outbound Call Management Service 99: Enhanced Call Processing Service 100: Host Enhanced Routing Service 101: Host Enhanced Voice Processing...

  • Page 121: Documentation

    ¥ Customer Controlled Routing User Guide (P0747008) ¥ Meridian Link/Customer Controlled Routing Engineering Guide (NTP 553-3211-520) Information about the Access option of the Meridian Mail that provides the voice service interface for the Application Module can be found in the following: ¥...

  • Page 122: Hardware

    Chapter 6: Site survey/installation checklist Hardware Use the following checklists to check the hardware. Table 19 Equipment cabinets Table 20 Meridian 1 CPU compatibility CPU ROM Memory Table 21 Input/Output devices Space available for ESDI/MSDL card Space available for additional ENET card AML requirements needed Number of AML ports required: NMS requirements needed...

  • Page 123: Equipment Room Information

    Table 22 Hard disk and tape drive type Equipment Hard disk Tape drive Equipment room information To ensure that you avoid problems caused by locating equipment in the wrong place, you should obtain a floor plan that has been updated to show your new equipment.

  • Page 124: Power And Ground Considerations

    Chapter 6: Site survey/installation checklist Power and ground considerations Your moduleÕs power source is either 110 V AC or 208 V DC. In each case, refer to the following NTPs to ensure that proper power and grounding requirements are met. ¥...

  • Page 125: Equipment Cabling

    Equipment cabling The following tables provide checklists and references for checking the cabling. Input/output device cabling Measure the cable distance for the input/output devices listed in Table 24. For information on the proper cables and connections, refer to the appropriate NTP. Table 24 Input/Output devices cable distance Input/Output devices...

  • Page 126: Peripheral Device Cabling

    Chapter 6: Site survey/installation checklist Peripheral device cabling Measure the cable distance for the peripheral devices listed in Table 25. For information on the proper cables and connections, refer to the appropriate NTP. Table 25 Peripheral devices cable distance Peripheral devices Meridian Mail to A/B switchbox 553-3202-210 Standard October 1998...
  • Page 127 Chapter 6: Site survey/installation checklist 109 Table 25 Peripheral devices cable distance (continued) Peripheral devices A/B switchbox to administration terminal Application Module to administration terminal A/B switchbox to modem Ñ continued Ñ Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Options Installation Guide (NTP 555-7011-210) Options Maintenance Guide...
  • Page 128 Chapter 6: Site survey/installation checklist Table 25 Peripheral devices cable distance (continued) Peripheral devices A/B switchbox to modem (continued) Printer to administration terminal Ethernet connection 553-3202-210 Standard October 1998 Meridian Mail Modular Option EC Installation and Maintenance Guide (NTP 555-7061-250) Card Option Installation and Maintenance Guide (NTP 555-7071-210)

  • Page 129: Telephony Connections

    Telephony connections Measure the cable distance for the devices listed in Table 26. For information on the proper cables and connections, refer to the appropriate NTP. Table 26 Telephony connections cable distance Telephony devices Modem to phone jack PBX to Meridian Mail (network loop) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 6: Site survey/installation checklist 111...

  • Page 130: Equipment Room Cooling Conditions

    Chapter 6: Site survey/installation checklist Equipment room cooling conditions Use this list to note the conditions in the equipment room. ¥ Type: ____________________________________________________ ¥ Ambient temperature: _______________________________________ ¥ Humidifier/air conditioner: ___________________________________ ¥ Customer restrictions: _______________________________________ __________________________________________________________ __________________________________________________________ ¥ Notes on current environmental conditions: _______________________ __________________________________________________________ __________________________________________________________ Additional considerations...

  • Page 131: Comments And Recommendations

    Comments and recommendations _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ Note: Return to Chapter 5, ÒHardware installation overviewÓ for the next procedure. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 6: Site survey/installation checklist 113...

  • Page 133: Chapter 7: Unpack And Inspect Hardware

    Chapter 7: Unpack and inspect hardware You should use this chapter in conjunction with Chapter 5, ÒHardware installation overview,Ó which links hardware installation procedures in easily understood tables (Tables 11 and 12). This chapter provides information on receiving, unpacking, and inspecting the IPE Module and Application Module hardware components.

  • Page 134: Receiving The Ipe Module And Application Module Components

    Chapter 7: Unpack and inspect hardware ¥ Store circuit packs in a clean, dry area. ¥ When tape cartridges have been subjected to temperature extremes, allow them to stabilize to room temperature before unpacking. This prevents the accumulation of condensation on the tapes. Receiving the IPE Module and Application Module components Use the following procedure to check all items received against the order...

  • Page 135: Unpacking The Ipe Module And Application Module Components

    Unpacking the IPE Module and Application Module components After you have received and checked the IPE Module or Application Module components, use the following procedure to unpack them. The IPE Module and Application Module are carefully packaged for maximum protection against physical damage during shipment. Retain the packaging material in case any equipment needs to be returned.
  • Page 136 Chapter 7: Unpack and inspect hardware If all the hardware components appear to be in order, repack them and store them in a safe place until you are ready to install them. Return any defective items to the manufacturer with a description of the defects.

  • Page 137: Chapter 8: Hardware Installation Procedures

    Chapter 8: Hardware installation procedures You should use this chapter in conjunction with Chapter 5, ÒHardware installation overview,Ó which links hardware installation procedures in easily understood tables (Tables 11 and 12). This chapter provides information on the installation of the IPE Module (Option 11 and Options 21Ð81) and the Application Module hardware components.

  • Page 138: Installing The Ipe Module

    Chapter 8: Hardware installation procedures Installing the IPE Module The following procedure for installing the actual IPE Module is only one of a series of procedures you should perform to install an IPE Module. The series is shown in Table 11 in Chapter 5, ÒHardware installation overview.Ó Before you start the following procedure, ensure that you have ¥...
  • Page 139 Chapter 8: Hardware installation procedures 121 Table 28 Default DCE/DTE settings Port Setting Refer to Figure 30 (Part 2) for a diagram of the correct jumper settings. To change the configuration of a port after you have installed an IPE Module, you must remove the IPE Module from the Meridian 1 IPE Shelf or Option 11 cabinet.
  • Page 140 Chapter 8: Hardware installation procedures Slowly slide the module along the slots into the shelf or cabinet, making sure the latches at the top and bottom of the module are unlatched. Press the faceplate to ensure that the module is firmly in place.
  • Page 141 Figure 30 Port configuration settings (Part 1) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 142 Chapter 8: Hardware installation procedures Figure 30 Port configuration settings (Part 2) Console Modem (Use cable NT1R03HF) Conshare Meridian Mail (HEVP) Note: These are the correct jumper settings for the ports. Refer to Figure 30 (Part 1) for the locations of the port jumpers on the board.

  • Page 143: Installing The Application Module

    Installing the Application Module The following procedure for installing the Application Module is only one of a series of procedures you should perform to install an Application Module. The series is shown in Table 12 in Chapter 5, ÒHardware installation overview.Ó Ensure that you have completed steps 1 through 5 in Table 12 before you start the following procedure.
  • Page 144 Chapter 8: Hardware installation procedures Plug the power harness into the connector on the MPDU (P3 if the module is installed next to the MPDU, P4 if the module is on the other side of the AEM). Note: Make sure you connect all the cables securely. Install the power supply and the disk/tape unit (refer to ÒInstalling the power supply and disk/tape unit (Application Module)Ó...

  • Page 145: Installing The Power Supply And Disk/Tape Unit

    Installing the power supply and disk/tape unit (Application Module) The Application Module power supply and disk/tape units are packaged separately for protection during shipping. Both units should be installed in the Application Module after it has been installed in the AEM and before external equipment is cabled to the Application Module.
  • Page 146 Chapter 8: Hardware installation procedures Figure 32 Disk/tape unit Slide the disk/tape unit into the slot at the far right of the Application Module (facing the AEM). Push the unit in hard and make sure the tabs at the top and bottom of the unit lock into position.

  • Page 147: Checking The Card Option Settings (Application Module)

    Checking the card option settings (Application Module) The cards are shipped with the settings preset at the factory, and they need to be checked only if you suspect a problem, or if you need to configure the host computer port (on the MVME705B card) for DTE operation. If you want to check the settings during installation, do so before installing the Application Module.
  • Page 148 Chapter 8: Hardware installation procedures If your Application Module does not have CCR activated, the MVME332XT(S) card may not be present. If so, skip steps 1Ð3 and begin at step 4. Remove the screws at the top and bottom of the MVME332XT(S) card faceplate.
  • Page 149 Chapter 8: Hardware installation procedures 131 Table 31 MVME333-2 XCC card jumper settings Block 2 and 4, 6 and 8, 10 and 12, 13Ð14, 15Ð16, 23Ð24 none 1Ð2, 5Ð6, 7Ð8, 9Ð10 none 1Ð2, 3Ð4 5Ð6 5Ð6 none 1Ð2 Replace the MVME333-2 XCC card and replace the screws at the top and bottom of the faceplate.
  • Page 150 Chapter 8: Hardware installation procedures ¥ ¥ ¥ Remove the screws at the top and bottom of the transition card faceplates. Pull the MVME705B and MVME712 transition cards out of the Application Module as follows: ¥ ¥ Table 32 Default DCE/DTE settings for MVME705B transition card Serial Port 553-3202-210 Standard October 1998 Unplug the power harness from the connector (P3 or P4) on the...
  • Page 151 Table 33 MVME705B jumper settings and cable connections Serial port DCE mode On header K6, place jumpers over pins 3Ð4, 7Ð8, 9Ð10 Plug the I/O cable into P14 On header K5, place jumpers over pins 3Ð4, 7Ð8, 9Ð10 Plug the I/O cable into P12 ¥...
  • Page 152 Chapter 8: Hardware installation procedures Table 36 Default DCE/DTE settings for MVME712M transition card Serial Port ¥ Reconnect the ribbon cables to the transition cards as follows: ¥ ¥ Reinstall the transition cards in the Application Module. Push the cards in until the faceplates are flush with the front of the module. Install the screws at the top and bottom of the transition card faceplates.
  • Page 153 Chapter 8: Hardware installation procedures 135 Note: A connector housing surrounds the pins on the P1 and P2 connectors. Make sure you center the cable connector on the pins within the housing. ¥ Plug the power harness into the connector on the MPDU (P3 if the Application Module is installed next to the MPDU, P4 if the Application Module is on the other side of the AEM).
  • Page 154 Chapter 8: Hardware installation procedures Figure 33 MVME332XTS transition card serial port configuration 553-3202-210 Standard October 1998...
  • Page 155 Figure 34 MVME333-2 transition card serial port configuration Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 8: Hardware installation procedures 137...
  • Page 156 Chapter 8: Hardware installation procedures Figure 35 MVME705B transition card serial port configuration Connector for DTE Jumpers for DTE Connector for DCE Jumpers for DCE Connector for DTE Jumpers for DTE Connector for DCE Jumpers for DCE 553-3202-210 Standard October 1998 P12 P11...
  • Page 157 Figure 36 MVME712AM transition card configuration Console ¥ Modem power ¥ (for external modem) ¥ (to SDI, for conshare) Modem interconnect ¥ (unused) Phone hookup ¥ (unused) Printer ¥ (unused) To P2 adapter board Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 8: Hardware installation procedures 139 +5 VDC +12VDC...
  • Page 158 Chapter 8: Hardware installation procedures Figure 37 MVME712A transition card configuration Console Modem power (for external modem) MVME732 Modem board (non-component side) (to SDI, for conshare) (unused) Phone hookup (unused) Printer (unused) To P2 adapter board 553-3202-210 Standard October 1998 +5 VDC +12 VDC -12 VDC...
  • Page 159 Figure 38 MVME712M card with jumpers SP1, 3 1 14 J8J10 SP2, 4 1 14 Ethernet port (LAN-based PC and/or host computer) Printer port (not used) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 8: Hardware installation procedures 141 R1 R2 13 14 13 14...

  • Page 160: Installing An Ntak02 Sdi/Dch Card

    Chapter 8: Hardware installation procedures Installing an NTAK02 SDI/DCH card On an Option 11 system, if there is no port available on the CPU/Conf or TDS/DTR cards, you can obtain additional SDI or ESDI ports by installing an NTAK02 SDI/DCH card before the IPE Module is configured. This card provides the communication connection for the AML link from the Option 11 to the IPE Module.
  • Page 161 Table 38 NTAK02 SDI/DCH card jumper settings Port Jumper Strap for Location C to B C to B C to B C to B C to B C to B Note: For AML link, strap for DCE RS-232. For cabling, refer to ÒSDI and ESDI/MSDL cabling (Option 11 IPE Module only)Ó...
  • Page 162 Chapter 8: Hardware installation procedures Figure 39 NTAK02 SDI/DCH card jumper and switch locations 553-3202-210 Standard October 1998 Unit 0 Unit 1 Unit 1 Unit 2 Unit 3...

  • Page 163: Installing An Esdi Or Msdl Card

    Installing an ESDI or MSDL card On the Meridian 1, a QPC513 ESDI card (vintage G or later) or NT6D80 MSDL card must have an available port. If there is no ESDI/MSDL port available, install a QPC513 ESDI or NT6D80 MSDL card before the IPE Module or the Application Module is configured.
  • Page 164 Chapter 8: Hardware installation procedures Note: If the Single Terminal Access (STA) feature is present, port 0 is reserved for the STA administration terminal. Insert the card into a common equipment slot and lock it into position. ESDI card onlyÑset the faceplate switch to ENB. Table 39 NT6D80 MSDL card switch settings RS-232-D DTE or DCE*...
  • Page 165 Figure 40 NT6D80 MSDL card jumper and switch locations Card address switches Port 0 ¥ ¥ Port 1 ¥ Port 2 ¥ Port 3 Note: This figure shows switches for all ports. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 8: Hardware installation procedures 147 Configure only the port you are going to use.
  • Page 166 Chapter 8: Hardware installation procedures Table 40 (Part 1) Program socket selection Option DTE (terminal) DCE (modem) RS-232-C interface High-speed interface Set as DCE to emulate modem. Table 40 (Part 2) Switch S2ÑAddress selection Device no. 10-11 12-13 14-15 ON = synchronous mode; OFF = asynchronous mode. Asynchronous mode is not supported.
  • Page 167 Figure 41 QPC513 ESDI card jumper and switch locations Port address switch S2 Jumper Jumpers for port J1. The port is always the lower, even number. Jumpers for port J2. The port is always the higher, odd number. Note 1: Place jumper plugs in sockets as shown. This selects the DCE and RS-232 options. Note 2: This figure shows both high and low ports.
  • Page 168 Chapter 8: Hardware installation procedures 553-3202-210 Standard October 1998...

  • Page 169: Chapter 9: Meridian Link/Ccr Interface Cabling

    Chapter 9: Meridian Link/CCR interface cabling The cable requirements for the IPE Module and the Application Module are completely different. For example, the Application Module uses power harness cables, but IPE Modules receive power from the IPE backplane and have no power cabling. This chapter describes cabling required for the IPE Module and the Application Module, and also provides procedures for connecting the IPE Module and Application Module to external equipment.
  • Page 170 152 Chapter 9: Meridian Link/CCR interface cabling Figure 42 NT1R03AA and NT1R03BA IPE Module cables NT1R03AA NT1R03BA 553-3202-210 Standard October 1998 Port 7 25-pin Port 5 25-pin Port 1 25-pin Port 3 25-pin Ethernet 15-pin Port 2 25-pin Port 4 25-pin Port 6 25-pin...
  • Page 171 Table 41 IPE Module cables Part number NT1R03AA Shielded 4-port octopus cable: has a 50-pin connector for the connector (A0400295) panel or I/O panel, four 25-pin port connectors; and a 15-pin Ethernet connector; connects the I/O panel to external cables NT1R03BA Shielded 4-port octopus cable: has a 50-pin connector for the connector (A0400297)

  • Page 172: External I/O Cables

    154 Chapter 9: Meridian Link/CCR interface cabling External I/O cables Table 42 lists external I/O cables that connect ports on the IPE Module cable to an SDI port, the ESDI/MSDL port, and consoles. Table 42 Cables from the IPE Module ports to external equipment Part number NT1R03HF (A0402669) NT8D93AJ (A0357270)

  • Page 173: External I/O Cable Pinouts (Ipe Module)

    External I/O cable pinouts (IPE Module) This section provides pinouts for the following cables: ¥ NT1R03D ¥ NT1R03E ¥ NT1R03HF ¥ NT1R03AA ¥ NT1R03BA ¥ NT1R03CA ¥ NT8D82 ¥ NT8D93A ¥ NTND27AB ¥ NTAK19AA ¥ NTAK19BA Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 155...
  • Page 174 156 Chapter 9: Meridian Link/CCR interface cabling Table 43 NT1R03D cable pinouts (IPE Module) Port pin 553-3202-210 Standard October 1998 Signal equipment pin SCTE External...
  • Page 175 Chapter 9: Meridian Link/CCR interface cabling 157 Table 44 NT1R03E cable pinouts (IPE Module) Port pin Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Signal equipment pin SCTE External...
  • Page 176 158 Chapter 9: Meridian Link/CCR interface cabling Table 45 NT1R03HF cable pinouts (IPE Module) Port pin 553-3202-210 Standard October 1998 Signal equipment pin Shield External...
  • Page 177 Table 46 NT1R03AA 50-pin four-port cable pinout (IPE Module) From Port DB-50 DB-25 From Port DB-50 DB-15 Ethernet Ethernet Ethernet Ethernet FGND Note: Pins 21Ð24 and 46Ð49 of the NT1R03AA cable connect to pins 2, 3, 5, 6, 9, 10, 12, and 13 of the DB-15 Ethernet connector.
  • Page 178 160 Chapter 9: Meridian Link/CCR interface cabling Table 47 NT1R03BA 50-pin four-port cable pinout (IPE Module) From Port DB-50 DB-25 FGND 553-3202-210 Standard October 1998 Signal From name DB-50 GND2 TXD2 RTS2 DSR2 GND4 TXD4 RTS4 DSR4 GND6 TXD6 RTS6 DSR6 TXCI6 GND8...
  • Page 179 Table 48 NT1R03CA 50-pin four-port cable pinout (IPE Module) From To port Port* DB-50 DB-50 (male) (female) 1 or 2 1 or 2 1 or 2 1 or 2 3 or 4 3 or 4 3 or 4 3 or 4 5 or 6 5 or 6 5 or 6...
  • Page 180 162 Chapter 9: Meridian Link/CCR interface cabling Table 49 NT8D93A cable pinout (IPE Module) 25-pin connector 553-3202-210 Standard October 1998 Signal connector 9-pin...
  • Page 181 Chapter 9: Meridian Link/CCR interface cabling 163 Table 50 NT8D82 cable pinout (IPE Module) 25-pin connector Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide 25-pin connector ÑcontinuedÑ...
  • Page 182 164 Chapter 9: Meridian Link/CCR interface cabling Table 50 NT8D82 cable pinout (IPE Module) (continued) Table 51 NT8D93A cable pinout (IPE Module) 25-pin connector 553-3202-210 Standard October 1998 25-pin connector Ñ endÑ Signal 25-pin connector 9-pin connector...
  • Page 183 Chapter 9: Meridian Link/CCR interface cabling 165 Table 52 NTND27AB cable pinout (IPE Module) 26-pin connector Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Signal connector LTRN DB-25...
  • Page 184 166 Chapter 9: Meridian Link/CCR interface cabling Table 53 NTAK19AA cable pinout (IPE Module) Meridian 1 553-3202-210 Standard October 1998 Signal TDCD0 DSR0 RTS0 RXD0 DTR0 CTS0 TXD0 DSR1 RTS1 RXD1 TDCD1 DTR1 CTS1 TXD1 Port 0 pin Port 1 pin...
  • Page 185 Chapter 9: Meridian Link/CCR interface cabling 167 Table 54 NTAK19BA cable pinout (IPE Module) Meridian 1 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Signal DSR0 RTS0 RXD0 DTR0 DCD0 CTS0 TXD0 SCTEA1 SCTEB1 DSR1 RTS1 SCRA1 SCRB1 RXDA1 RXDB1 DTR1...
  • Page 186 168 Chapter 9: Meridian Link/CCR interface cabling Table 54 NTAK19BA cable pinout (IPE Module) (continued) Meridian 1 553-3202-210 Standard October 1998 Signal DSR2 RTS2 RXD2 DTR2 DCD2 CTS2 TXD2 SCTEA3 SCTEB3 DSR3 RTS3 SCRA3 SCRB3 RXDA3 RXDB3 DTR3 DCD3 CTS3 SCTA3 SCTB3 TXDA3...
  • Page 187 Chapter 9: Meridian Link/CCR interface cabling 169 SDI and ESDI/MSDL cabling (Option 11 IPE Module only) On an IPE Module Option 11 system, you can obtain one or two additional SDI or ESDI ports by adding an NTAK02 SDI/DCH card. The NTAK19BA cable plugs into the same port on the I/O panel as the card slot used for the SDI card.
  • Page 188 170 Chapter 9: Meridian Link/CCR interface cabling Figure 43 IPE Module Option 11 connections (Part 1) Meridian 1 Option 11 Internal NTAK01 CPU/Conf port 0 J1 (Note 1) NTAK03 Internal TDS/DTR (Note 3) port 0 port 1 553-3202-210 Standard October 1998 Method 1 A0368901 Note 4...
  • Page 189 Figure 43 IPE Module Option 11 connections (Part 2) Meridian 1 Option 11 NTAK02 Internal SDI/DCH port 0 port 1 port 2 port 3 J2-9 (Note 1) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 171 Method 3 port 0 port 2...
  • Page 190 172 Chapter 9: Meridian Link/CCR interface cabling Meridian Mail cabling (IPE Module) The Meridian Link application can have voice-processing capability by connecting the IPE Module to a Meridian Mail system through a link called the Meridian Mail Link (MML). The MML connects to the IPE Module at port 4. The MML connects to the Meridian Mail system at a data port of Meridian Mail via an NT1R03HF 25-pin male to a 25-pin male cable (10 ft.) with a null modem adapter.
  • Page 191 Chapter 9: Meridian Link/CCR interface cabling 173 ESDI/MSDL cabling (Options 21Ð81 IPE Module) As shown in Figure 45, port 5 of the NT1R03AA cable connects to the NT6D80 MSDL card through an NTND27AB cable and, if additional length is needed, through an NT1R03D extension cable. For pinouts of the NT1R03AA, NT8D82, NT1R03D, and NTND27 cables, refer to ÒExternal I/O cable pinoutsÓ...
  • Page 192 174 Chapter 9: Meridian Link/CCR interface cabling SDI Paddle Board cabling (Options 21Ð81 IPE Module only) Port 3 of the NT1R03AA cable connects to the NT8D41 SDI Paddle Board through an NT8D93A cable and, if additional length is needed, through an NT1R03D extension cable.
  • Page 193 Figure 45 I/O cabling to Meridian 1 (SDI and MSDL) (Options 21Ð81 IPE Module) Part of IPE shelf I/O panel NT1R03AA Meridian 1 SDI card NT8D82 (see Note) NT8D82 QPC513 ESDI card NTND27AB NT6D80 MSDL card Note: Use the NT8D82 cable with all SDI cards except the NT8D41 SDI Paddle Board.
  • Page 194 176 Chapter 9: Meridian Link/CCR interface cabling Figure 46 I/O cabling to Meridian 1 (SDI and ESDI) (Options 21Ð81 IPE Module) Part of IPE shelf I/O panel NT1R03AA Meridian 1 SDI card NT8D82 (see Note) NT8D82 QPC513 ESDI card NTND27AB NT6D80 MSDL card Note:...

  • Page 195: Cabling The Option 11 Ipe Module To External Equipment

    Chapter 9: Meridian Link/CCR interface cabling 177 Cabling the Option 11 IPE Module to external equipment The following procedure to cable the Option 11 IPE Module to external equipment is only one of a series of procedures to install an IPE Module. The series is shown in Table 11 in Chapter 5, ÒHardware installation overview.Ó...
  • Page 196 178 Chapter 9: Meridian Link/CCR interface cabling Figure 47 Option 11 system IPE Module connections Meridian 1 cabinet Module Note 3 Connector panel NT1R03CA (extension cable) NT1R03AA (octopus cable) NT1R03CA (extension cable) NT1R03BA (octopus cable) Note 1: For SDI and ESDI cabling, refer to ÒSDI and ESDI/MSDL cabling (Option 11 IPE Module only).Ó...
  • Page 197 Figure 48 Option 11 main cabinet connector panel Ensure that the power for the IPE Module is turned off. Connect NT1R03CA extension cables to the NT1R03AA and NT1R03BA octopus cables using the 50-pin connectors. Using these cables allows the front panel of the Option 11 to be closed without interference from dangling cables.
  • Page 198 180 Chapter 9: Meridian Link/CCR interface cabling Table 56 Option 11 IPE ModuleÑNT1R03AA/NT1R03CA cable connections (main cabinet) Table 57 Option 11 IPE ModuleÑNT1R03AA/NT1R03CA cable connections (expansion cabinet) Slots occupied by the 553-3202-210 Standard October 1998 Slots occupied by the IPE Module 2, 3, 4 3, 4, 5 4, 5, 6...
  • Page 199 Chapter 9: Meridian Link/CCR interface cabling 181 Connect the NT1R03CA extension cable that is connected to the NT1R03BA octopus cable to the appropriate connector as shown in Tables 58 and 59. For example, if the IPE module is located in slots 2, 3, and 4, connect the extension cable to connector J2.
  • Page 200 182 Chapter 9: Meridian Link/CCR interface cabling Connect the ports of octopus cable NT1R03AA to external equipment as described in Table 60 and shown in Figure 47. For example, connect port 1 of the NT1R03AA octopus cable to the console using a customer-supplied cable. Table 60 Option 11 IPE Module external connections (NT1R03AA cable) NT1R03AA...
  • Page 201 Chapter 9: Meridian Link/CCR interface cabling 183 Table 61 Option 11 IPE Module external connections (NT1R03BA cable) NT1R03BA External equipment port external modem Meridian Mail Link X.25 Host Link terminal/printer Table 62 Console cable pinout (NT1R03D) Meridian 1 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide External cable or reference NT1R03HF (for pinout, see ÒExternal I/O cable pinouts.Ó...
  • Page 202 184 Chapter 9: Meridian Link/CCR interface cabling Table 63 X.25 Host Link cable pinout IPE Module Note: Return to Chapter 5, ÒHardware installation overviewÓ for the next procedure. 553-3202-210 Standard October 1998 Signal TXCI Host Connection +12v TRXC or open...

  • Page 203: Backplane Cable Rerouting For Options 21Ð81 Ce/Pe And Ipe Backplanes

    Backplane cable rerouting for Options 21Ð81 CE/PE and IPE backplanes In a standard configuration, an IPE Module can be placed in any four adjoining peripheral slots on an Options 21Ð81 CE/PE or IPE shelf. This is possible when the slots are fully cabled to accommodate 24 tip and ring pairs per slot.
  • Page 204 186 Chapter 9: Meridian Link/CCR interface cabling has three 20-pin connectors (only 16 pins are used) labelled 1, 2, and 3, and referred to as X-1, X-2, and X-3, in which X represents the I/O panel connector port. For example, the backplane cable connected to I/O panel connector port A has three connectors referred to as A-1, A-2, and A-3.

  • Page 205: Backplane Cable Rerouting For The Nt8D11 Ce/Pe Module Backplane

    Backplane cable rerouting for the NT8D11 CE/PE Module backplane In the standard seven-cable configuration for the NT8D11 CE/PE backplane (Figure 49), cables from connector ports D, G, and L are not used. Those cables are used in the ten-cable fully expanded configuration. Figure 49 NT8D11 backplane cable designations (standard configuration) Peripheral equipment slots...
  • Page 206 188 Chapter 9: Meridian Link/CCR interface cabling Table 64 lists cable connections before cable expansion. Figure 49 shows the backplane slots before cable expansion. Table 64 NT8D11 cable connections (standard configuration) I/O panel connector Note: Connector ports D, G, and L are not used in this configuration. 553-3202-210 Standard October 1998 Backplane cable port...
  • Page 207 Chapter 9: Meridian Link/CCR interface cabling 189 Cabling for the first four PE slots can be expanded using one NT8D81AA cable/filter assembly. Cabling for all of the PE slots can be expanded using three NT8D81AA cable/filter assemblies. If you do not have additional NT8D81AA cable/filter assemblies available, you can reroute the existing cables to accommodate the Meridian Link/CCR IPE Module in certain PE slots.
  • Page 208 190 Chapter 9: Meridian Link/CCR interface cabling Move cable end H-3 from slot position L8-1 to slot position L7-3. Remove cable K from the backplane and connect cable ends K-1, K-2, and K-3 to slot positions L8-1, L8-2, and L8-3. Add cable L to the I/O panel by connecting cable ends L-1, L-2, and L-3 to slot positions L9-1, L9-2, and L9-3.
  • Page 209 Table 65 NT8D11 cable connections (fully expanded configuration) (continued) I/O panel connector G (new cable) L (new cable) Figure 50 NT8D11 backplane cable designations (fully expanded configuration) Peripheral equipment slots L9 L8 L7 L6 L5 L4 L3 L2 L1 L0 C9 C8 C7 C6 C5 C4 C3 C2 C1 C0 Shroud row Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 191...
  • Page 210 192 Chapter 9: Meridian Link/CCR interface cabling NT8D11 backplane cable reroutingÑto accommodate the IPE Module in PE slots 0Ð3 With the cables located as shown in Table 64, use the following procedure to reroute the backplane cables. Note that an IPE Module located in slots 0Ð3 uses I/O connector ports A and D.
  • Page 211 Chapter 9: Meridian Link/CCR interface cabling 193 Table 66 lists cable connections for a rerouted IPE shelf. Figure 51 shows the backplane slots in a rerouted IPE shelf. Table 66 NT8D11 cable connections (rerouted for slots 0Ð3) I/O panel connector Backplane cable port Note: Connector ports C, G, and L are not used in this configuration.
  • Page 212 194 Chapter 9: Meridian Link/CCR interface cabling Figure 51 NT8D11 backplane cable designations (rerouted for slots 0Ð3) Peripheral equipment slots L9 L8 L7 L6 L5 L4 L3 L2 L1 L0 C9 C8 C7 C6 C5 C4 C3 C2 C1 C0 Shroud Row 553-3202-210 Standard October 1998 Common equipment slots...

  • Page 213: Backplane Cable Rerouting For Nt8D37 Ipe Module

    Backplane cable rerouting for NT8D37 IPE Module In the standard 12-cable configuration for the backplane in the NT8D37 IPE Module, cables D, H, N, and U are not used. Those cables are used in the 16-cable fully expanded configuration. Note: Backplane slots 0, 4, 8, and 12 (for cables A, E, K, and R) are already fully cabled for 24 pairs, so no change is required for those slots.
  • Page 214 196 Chapter 9: Meridian Link/CCR interface cabling Table 67 NT8D37 cable connections (standard configuration) (continued) I/O panel connector Note: Connector ports D, H, N, and V are not used in this configuration. 553-3202-210 Standard October 1998 Backplane cable port connector L--1 Ñ...
  • Page 215 Figure 52 NT8D37 backplane cable designations (standard configuration) Segment 3 L16 L15 L14 L13 L12 Shroud Row Cabling for each segment can be expanded using one NT8D81AA cable/filter assembly. Cabling for the entire backplane can be expanded using four NT8D81AA cable/filter assemblies. If you do not have additional NT8D81AA cable/filter assemblies available, you can reroute the existing cables to accommodate the Meridian Link/CCR IPE Module in specific PE slots.
  • Page 216 198 Chapter 9: Meridian Link/CCR interface cabling NT8D37 backplane cable expansionÑsegment 0 With the cables located as shown in Table 67: Leave cable A as is in slot position L0. Move cable end B-3 from slot position L2-1 to slot position L1-3. Remove cable C from the backplane and connect cable ends C-1, C-2 and C-3 to slot positions L2-1, L2-2, and L2-3.
  • Page 217 Chapter 9: Meridian Link/CCR interface cabling 199 NT8D37 backplane cable expansionÑsegment 3 Leave cable R in slot position L12. Move cable end S-3 from slot position L14-1 to slot position L13-3. Remove cable T from the backplane and connect cable ends T-1, T-2, and T-3 to slot positions L14-1, L14-2, and L14-3.
  • Page 218 200 Chapter 9: Meridian Link/CCR interface cabling Table 68 NT8D37 cable connections (fully expanded configuration) I/O panel connector D (new cable) 553-3202-210 Standard October 1998 Backplane cable port connector ÑcontinuedÑ Backplane slot location L0-1 L0-2 L0-3 L1-1 L1-2 L1-3 L2-1 L2-2 L2-3 L3-1...
  • Page 219 Chapter 9: Meridian Link/CCR interface cabling 201 Table 68 NT8D37 cable connections (fully expanded configuration) (continued) I/O panel connector port H (new cable) N (new cable) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Backplane cable Backplane slot connector L--1 ÑcontinuedÑ...
  • Page 220 202 Chapter 9: Meridian Link/CCR interface cabling Table 68 NT8D37 cable connections (fully expanded configuration) (continued) I/O panel connector U (new cable) Figure 53 NT8D37 backplane cable designations (fully expanded configuration) Segment 3 L16 L15 L14 L13 L12 Shroud Row 553-3202-210 Standard October 1998 Backplane cable port...
  • Page 221 Chapter 9: Meridian Link/CCR interface cabling 203 NT8D37 backplane cable rerouting for segment 0Ñto accommodate the IPE Module in PE slots 0Ð3 With the cables located as shown in Table 67: Leave cable A in slot position L0. Remove cable C from the backplane and connect cable ends C-1, C-2, and C-3 to slot position L3-1, L3-2, and L3-3.
  • Page 222 204 Chapter 9: Meridian Link/CCR interface cabling Table 69 lists cable connections for an IPE shelf with segment 0 rerouted. Figure 54 shows the backplane slots in that IPE shelf. Table 69 NT8D37 cable connections (segment 0 has been rerouted) I/O panel connector 553-3202-210 Standard October 1998 Backplane cable...
  • Page 223 Chapter 9: Meridian Link/CCR interface cabling 205 Table 69 NT8D37 cable connections (segment 0 has been rerouted) (continued) I/O panel connector port Note: Connector ports C, H, N, and U are not used in this configuration. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Backplane cable Backplane slot connector...
  • Page 224 206 Chapter 9: Meridian Link/CCR interface cabling Figure 54 NT8D11 backplane cable designations (segment 0 has been rerouted) Segment 3 L16 L15 L14 L13 L12 Shroud Row NT8D37 backplane cable rerouting for segment 1Ñto accommodate the IPE Module in PE slots 4Ð7 Leave cable E as is in slot position L4.
  • Page 225 Chapter 9: Meridian Link/CCR interface cabling 207 NT8D37 backplane cable rerouting for segment 2Ñto accommodate the IPE Module in PE slots 8Ð11 With the cables located as shown in Table 67: Leave cable K as is in slot position L8. Remove cable M from the backplane and connect cable ends M-1, M-2, and M-3 to slot positions L11-1, L11-2, and L11-3.
  • Page 226 208 Chapter 9: Meridian Link/CCR interface cabling NT8D37 backplane cable rerouting for segment 3Ñto accommodate the IPE Module in PE slots 12Ð15 With the cables located as shown in Table 67: Leave cable R as is in slot position L12. Remove cable T from the backplane and connect cable ends T-1, T-2, and T-3 to slot positions L15-1, L15-2, and L15-3.

  • Page 227: Cabling The Options 21Ð81 Ipe Module To External Equipment

    Cabling the Options 21Ð81 IPE Module to external equipment The following procedure to cable an Options 21Ð81 IPE Module to external equipment is only one of a series of procedures to install an IPE Module. The series is shown in Table 11 in Chapter 5, ÒHardware installation overview.Ó...
  • Page 228 210 Chapter 9: Meridian Link/CCR interface cabling Figure 55 Options 21Ð81 system IPE Module connections Part of IPE Shelf I/O panel See Note 3 NT1R03AA (octopus cable) NT1R03BA (octopus cable) Note 1: For SDI cabling, refer to ÒSDI cabling (Options 21Ð81 IPE Module).Ó Note 2: For ESDI cabling, refer to ÒESDI/MSDL cabling (Options 21Ð81 IPE Module).Ó...
  • Page 229 Use the following procedure to cable to external equipment. Figure 56 IPE shelf I/O panels (Options 21Ð81) Left I/O panel Ensure that the power for the IPE Module is turned off. Connect the NT1R03AA and NT1R03BA octopus cables to the I/O panel;...
  • Page 230 212 Chapter 9: Meridian Link/CCR interface cabling Table 70 Option 21 CE/PE cabinet connectors Slots occupied by the IPE Module Table 71 Options 51Ð81 IPE cabinet connectors Slots occupied by the 553-3202-210 Standard October 1998 Connect NT1R03AA to connector port 0Ð3 1Ð4 2Ð5...
  • Page 231 Chapter 9: Meridian Link/CCR interface cabling 213 Connect the ports of cable NT1R03AA to external equipment, as described in Table 72 and shown in Figure 55. For example, connect port 1 of the NT1R03AA cable to the console, using a customer- supplied cable.
  • Page 232 214 Chapter 9: Meridian Link/CCR interface cabling Table 73 Options 21Ð81 IPE Module external connections (NT1R03BA cable) NT1R03BA port Table 74 Console cable pinout (NT1R03D) Meridian 1 553-3202-210 Standard October 1998 External equipment external modem Meridian Mail Link X.25 Host Link terminal Signal LRTN...
  • Page 233 Chapter 9: Meridian Link/CCR interface cabling 215 Table 75 X.25 Host Link cable pinout IPE Module Signal Note: Return to Chapter 5, ÒHardware installation overviewÓ for the next procedure. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Host Connection +12 V TXCI TRXC or open...

  • Page 234: Application Module Cabling

    216 Chapter 9: Meridian Link/CCR interface cabling Application Module cabling Two types of cables interconnect Application Module components. These include ¥ power harness cables ¥ I/O cables Power cables Power to the AEM is fed to the MPDU. Power harnesses conduct power from the MPDU to the power supply in the Application Module.
  • Page 235 Table 76 Power harness cables (Application Module) Part number NT7D52AA (A0372656) NT7D55AA (AC) (A0372722) NT7D55AB (DC) (A0372723) NT7D55AD (AC/DC) (A0372725) NT7D55AE (A0372726) NT7D55AF (A0372727) NT7D55AG (A0372728) NT7D55AJ (A0372904) NT7D55AK (AC) (A0372905) NT7D55AL (DC) (A0372906) NT7D55BM (AC/DC) (A0372907) NT7D55BG (A0375140) NT8D40AM (AC) (A0350327) NT7D11AE (DC) (A0364644) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 217...
  • Page 236 218 Chapter 9: Meridian Link/CCR interface cabling Figure 57 Power harness wiring diagram (Application Module) Module-to-module power harness MPDU to power NT8D40AM (AC) supply harness NT7D11AE (DC) NT7D55AD (AC/DC) MPDU power harness NT7D55AA (AC) NT7D55AB (DC) Power monitor ¥ ¥ MPDU ¥...

  • Page 237: Input/Output Cables

    Input/output cables The Application Module has two types of I/O cable. These include ¥ internal cables that connect circuit cards to disk and tape drives within the Application Module ¥ external cables that connect the Application Module to the Meridian 1, the system console, and application terminals (if applicable) Internal I/O cables Internal cables interconnect components that are not connected through the...
  • Page 238 220 Chapter 9: Meridian Link/CCR interface cabling Figure 58 Internal I/O cabling (Application Module) NT7D52AA Power monitor cable I/O panel NT7D1802 Power monitor ¥ ¥ NT7D1901 Power sense card P1 P1 NT7D95AA (to system monitor) P2 adapter board Power MVME147/167 supply SBC card Front of Application Module...
  • Page 239 External I/O cables (Application Module) Tables 78, 79, and 80 list external I/O cables that connect ports on the transition cards to connectors on either the I/O subpanel or the universal I/O panel. Table 78 lists external I/O cables that connect the I/O panel connectors to an SDI port, the ESDI/MSDL port, the main distribution frame (MDF), and consoles.
  • Page 240 222 Chapter 9: Meridian Link/CCR interface cabling Table 79 Cables from transition cards to the universal I/O panel (Application Module) Part number Length NT7D46AA 35 cm (A0372653) (14 in.) (MVME712A/AM) NT7D48AA 35 cm (A0372655) (14 in.) (replaced by NT7D95AA on 22 cm newer systems) (9 in.)
  • Page 241 Table 80 Cables from transition cards to generic I/O panel (Application Module) Part number Length NT7D47DA 35 cm (14 in.) NT7D58CA 35 cm (A0403488) (14 in.) NT7D79BA 35 cm (A0403432) (14 in.) NT7D95AA 22 cm (9 in.) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 223 Cable description and application 15-pin cable: connects the Ethernet port of the MVME712M...
  • Page 242 224 Chapter 9: Meridian Link/CCR interface cabling Table 81 Cables to external equipment (Application Module) Part number NT7D46AB (A0373932) NT7D46AD (A0373933) NT7D46AF (A0373934) NT7D46AL (A0373935) NT7D46AT (A0373936) NT7D46AV (A0373937) NT7D47EA NT7D58AB (A0373938) NT7D58AD (A0373939) NT7D58AF (A0373940) NT7D58AL (A0373941) NT7D58AT (A0373942) NT7D58AV (A0373943 NT7D61AB (A0374031) NT7D61AD (A0374070)
  • Page 243 Table 81 Cables to external equipment (Application Module) (continued) Part number NT7D61AB (A0374031) NT7D61AD (A0374070) NT7D61AF (A0374071) NT7D61AL (A0374072) NT7D61AT (A0374073) NT7D61AV (A0374074) NT7D71BA (A0394776) (MVME712AM) NT8D82AC NT8D82AD NTND27AB Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 225 Length Cable description and application 0.6 m (2 ft.)
  • Page 244 226 Chapter 9: Meridian Link/CCR interface cabling Table 81 Cables to external equipment (Application Module) (continued) Part number NTND82AA NT7D58BB NT8D93AJ (A0357270) NT8D93AW (A0357271) NT8D96AE NTAK19AA (A0372718) NTAK19BA (A0372719) NT1R03DB (A0402335) NT1R03DC (A0402336) NT1R03DF (A0402337) NT1R03DP (A0402338) NT1R03DV (A0402339) NT1R03EB (A0402330) NT1R03EC (A0402331) NT1R03EF (A0402332) NT1R03EP (A0402333)

  • Page 245: Cabling The Application Module To External Equipment

    Cabling the Application Module to external equipment The following procedure to cable the Application Module to external equipment is only one of a series of procedures to install an Application Module. The series is shown in Table 12 in Chapter 5, ÒHardware installation overview.Ó...
  • Page 246 228 Chapter 9: Meridian Link/CCR interface cabling If you are using an MVME712AM transition card, skip this step. To connect an external modem to the Application Module, connect a 9-pin to 25-pin null modem cable from the Application Module connector ¥...
  • Page 247 Chapter 9: Meridian Link/CCR interface cabling 229 To connect the MSDL port to the Meridian 1 I/O panel, connect an NTND27 cable (if DCE) or an NTND26 (if DTE) cable from the MSDL port to ¥ J2 on the I/O subpanel ¥...
  • Page 248 230 Chapter 9: Meridian Link/CCR interface cabling For the X.25 host link, connect a customer-supplied cable from the Application Module connector: ¥ ¥ ¥ to the host computer. For more information, refer to ÒHost computer cabling (Application Module)Ó in this chapter. To connect the terminals and/or printers to the Application Module, connect an RS-232 cable to one of the three connectors on the VME multi-port cables that are connected to one of the following:...
  • Page 249 Figure 59 I/O subpanel connectors (Meridian Link) Host connection (Link 1) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 231 Meridian Link I/O subpanel ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥ ¥...
  • Page 250 232 Chapter 9: Meridian Link/CCR interface cabling Figure 60 I/O subpanel connectors (CCR) Meridian 1 connection (Link 0) To terminals and/or printers (NT8D96AE octopus cable) External modem SDI port Console 553-3202-210 Standard October 1998 ¥ ¥ ¥ ¥ ¥ ¥ ¥...
  • Page 251 Figure 61 Universal I/O panel (Meridian Link and co-residency) Meridian Mail connection (Link 2) Internal modem if MVME712AM card is installed Meridian 1 SDI* (conshare) *To QSDI, DCH, or MSDL card of the Meridian 1 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 233 Serial I/O Serial I/O...
  • Page 252 234 Chapter 9: Meridian Link/CCR interface cabling Figure 62 Universal I/O panel (CCR) Meridian 1 SDI (conshare) 553-3202-210 Standard October 1998 Serial I/O Serial I/O Serial I/O Serial I/O 23 - 24 31 - 32 15 - 16 7 - 8 Serial I/O Serial I/O Serial I/O...
  • Page 253 Figure 63 Generic I/O panel (Meridian Link and co-residency) Meridian Mail connection (Link 2) Meridian 1 OA&M (Conshare) Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 235 CARD 5 CARD 4 CARD 3 CARD 2 CONN 3 CONN 3...

  • Page 254: External Modem

    236 Chapter 9: Meridian Link/CCR interface cabling Figure 64 Generic I/O panel (CCR) Meridian 1 (Conshare) 553-3202-210 Standard October 1998 CARD 5 CARD 4 CARD 3 CARD 2 CONN 3 CONN 3 CONN 3 CONN 3 CARD 5 CARD 4 CARD 3 CARD 2 CONN 2...
  • Page 255 Figure 65 Application Module MVME712A and MVME705B I/O cablingÑ/O subpanel (Meridian Link) Application Module MVME712A Transition card SP1, Console SP2, TTY Teledapt MVME705B Transition card DB25 DB25 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 237 (INTERNAL CABLING) I/O subpanel NT7D79AA...
  • Page 256 238 Chapter 9: Meridian Link/CCR interface cabling Figure 66 Application Module MVME712AM and MVME705B I/O cablingÑI/O subpanel (Meridian Link) Application Module MVME712AM Transition card SP1, Console SP2, TTY RJ11 Teledapt MVME705B Transition card DB25 DB25 553-3202-210 Standard October 1998 (INTERNAL CABLING) I/O subpanel NT7D79AA NT7D46AA...
  • Page 257 Figure 67 Application Module MVME712A, MVME705B, NT6D51AA cablingÑI/O subpanel (CCR) Application Module MVME712A Transition card SP1, Console SP2, TTY Undefined port Teledapt Printer Not used with AM MVME705B Transition card DB25 DB25 NT6D51AA Transition card DB25 DB25 DB25 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 239 (INTERNAL CABLING) I/O sub-panel...
  • Page 258 240 Chapter 9: Meridian Link/CCR interface cabling Figure 68 Application Module MVME712AM, MVME705B, NT6D51AA cablingÑI/O subpanel (CCR) Application Module MVME712AM Transition card SP1, Console SP2, TTY Undefined port RJ11 Teledapt Printer Not used with AM MVME705B Transition card DB25 DB25 NT6D51AA Transition card DB25 DB25...
  • Page 259 Figure 69 Application Module external I/O cabling to and from universal I/O panel (Meridian Link) Application Module MVME712A Transition card SP1, Console SP2, TTY MVME705B Transition card DB25 DB25 DB25 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 241 (INTERNAL CABLING) Universal I/O panel...
  • Page 260 242 Chapter 9: Meridian Link/CCR interface cabling Figure 70 Application Module external I/O cabling to and from universal I/O panel (CCR) Application Module (INTERNAL CABLING) MVME712A/AM Transition card NT7D79AA SP1, Console NT7D46AA SP2, TTY (MVME712A) NT7D46AA Undefined port RJ11 NT7D60AA Teledapt (MVME712AM) Printer...
  • Page 261 Figure 71 Application Module external cabling to and from generic I/O panel (Meridian Link) Application Module (INTERNAL CABLING) MVME712M Transition card NT7D79BA NT7D79BA NT7D79BA NT7D58CA SCSI A0379673 SCSI Terminator NT7D47DA* Ethernet MVME705B Transition card NT7D95AA NT7D95AA NT7D95AA * Not shipped with the Application Module. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 9: Meridian Link/CCR interface cabling 243 Generic I/O panel...
  • Page 262 244 Chapter 9: Meridian Link/CCR interface cabling Figure 72 Application Module external cabling to and from generic I/O panel (CCR) Application Module (INTERNAL CABLING) MVME712M Transition card NT7D79BA NT7D79BA NT7D79BA NT7D58CA NT7D47DA* Ethernet SCSI A0379673 SCSI Terminator MVME705B Transition card NT7D95AA NT7D95AA NT7D95AA...
  • Page 263 Figure 73 I/O cabling to Meridian 1 (SDI and ESDI) (Application Module) Application Module MVME712 transition card DB25** (NT7D46AA*) NT7D79BA MVME705B DB25 transition card NT7D48AA (NT7D95AA on newer systems) Meridian 1 SDI card NT8D82* (see Note) NT8D82 QPC513 ESDI card NTND27 NT6D80 MSDL card...
  • Page 264 246 Chapter 9: Meridian Link/CCR interface cabling Figure 74 I/O cabling to Meridian 1 (SDI and MSDL) (Application Module) Application Module MVME712 transition card DB25** (NT7D46AA*) NT7D79BA MVME705B DB25 transition card NT7D48AA (NT7D95AA on newer systems) Meridian 1 SDI card NT8D82* (see Note) NT8D82...
  • Page 265 Chapter 9: Meridian Link/CCR interface cabling 247 ESDI/MSDL cabling (Application Module) As shown in Figure 73, the QPC513 ESDI card in the Meridian 1 connects to the I/O panel in the MeridianÊ1 through an NT8D82 RS-232 straight- through cable. As shown in Figure 74, the NT6D80 MSDL card connects to the Meridian 1 I/O panel using an NTND27 SCSI II cable.
  • Page 266 248 Chapter 9: Meridian Link/CCR interface cabling System console cabling (Application Module) As shown in Figures 65Ð74, the system console connects to the MVME712 transition card at ¥ J7 on the I/O subpanel ¥ SYS CONS port on the universal I/O panel ¥...
  • Page 267 Chapter 9: Meridian Link/CCR interface cabling 249 Host computer cabling (Application Module) X.25 cabling: As shown in Figures 65Ð74, a customer-supplied cable connects ¥ J3 on the I/O subpanel ¥ Host on the universal I/O panel ¥ card 2 conn 2 on the generic I/O panel to the host computer.
  • Page 268 250 Chapter 9: Meridian Link/CCR interface cabling SDI cabling (Application Module) As shown in Figures 73 and 74, SDI cards (other than the NT8D41 SDI Paddle Board) connect to the I/O panel in the Meridian 1 through an NT8D82 RS-232 straight-through cable. From the Meridian 1 I/O panel or SDI card on the Meridian 1 I/O panel or SDI card on the Meridian 1, an NT7D61 cable (see Table 81 for lengths and specific codes) connects to the Application Module at...
  • Page 269 Chapter 9: Meridian Link/CCR interface cabling 251 SDI Paddle Board cabling (Application Module) The NT8D41 SDI Paddle Board connects to the I/O panel in the Meridian 1 through an NT8D84AA cable (see Table 88). From the Meridian 1 I/O panel or SDI Paddle Board on the Meridian 1, an NT7D46 cable (see Table 81 for lengths and specific codes) connects to the Application Module at ¥...
  • Page 270 252 Chapter 9: Meridian Link/CCR interface cabling Table 88 Pinout of SDI Paddle Board J1 connector Pin Number Table 89 Pinout of SDI Paddle Board J2 connector Pin Number 553-3202-210 Standard October 1998 Signal DTR1 DSR1 RTS1 CTS1 Signal DTR2 DSR1 RTS2 CTS2...
  • Page 271 Chapter 9: Meridian Link/CCR interface cabling 253 Internal modem cabling (MVME712AM card only) The NT7D71BA cable connects the 9-pin connector at either port J9 on the I/O subpanel or the INT MODEM port on the universal I/O panel to the 4-pin connector on the MDF.
  • Page 272 254 Chapter 9: Meridian Link/CCR interface cabling Meridian Mail cabling (Application Module) The Meridian Link application can have voice-processing capability by connecting the Application Module to a Meridian Mail system through a link called the Meridian Mail Link (MML). The MML (Figure 75) connects to the Application Module at MVME712 serial port SP4.
  • Page 273 Chapter 9: Meridian Link/CCR interface cabling 255 Meridian Mail Modular Option EC provides data port connections via a utility card. The interface is provided by an NT6P0109 5-port RS-232 or an NT6P0110 4-port RS-232 break-out cable. Each port on these cables has a null modem arrangement, therefore a straight-through cable will be needed to provide a null arrangement interface required by Meridian Link.

  • Page 274: Installing Ethernet Lan Support

    256 Chapter 9: Meridian Link/CCR interface cabling Power up the Application Module. Define the Meridian Mail Link parameters using Procedure 15 in Chapter 15, ÒLink configurationÓ in this guide. Note: Return to Chapter 5, ÒHardware installation overviewÓ for the next procedure. For more information on Meridian Mail, refer to Chapter 13, ÒMeridian Mail configuration.Ó...
  • Page 275 Before you install Ethernet LAN support on your IPE Module or Application Module, you must ensure that you have the following customer- supplied equipment installed (see Figure 76): ¥ an Ethernet backbone cable that connects all nodes together (a LAN-attached PC and a LAN-attached host computer are examples of nodes) ¥...
  • Page 276 258 Chapter 9: Meridian Link/CCR interface cabling To set up an Ethernet connection, use the following procedure: Ensure that an Ethernet drop cable is connected to the IPE Module or Application Module. Refer to Table 92 for the connection. Table 92 Ethernet connections to IPE Module and Application Module Module Application...
  • Page 277 Chapter 9: Meridian Link/CCR interface cabling 259 At step 21 of Procedure 8, type the module address of the IPE Module or Application Module and press [Return]. There are specific requirements for the address. For more information, consult your network administrator. If you are activating support for an Ethernet LAN-based PC, continue with steps 11-13.
  • Page 278 260 Chapter 9: Meridian Link/CCR interface cabling Table 93 NT7D47DA cable pinout Table 94 NT7D47EA cable pinout 553-3202-210 Standard October 1998 P1 end P1 end P2 end P2 end...

  • Page 279: Chapter 10: Installing Peripheral Devices

    Chapter 10: Installing peripheral devices You should use this chapter in conjunction with Chapter 5, ÒHardware installation overview,Ó which links hardware installation procedures in easily understood tables (Tables 11 and 12). The following procedures describe how to set up the video display terminals supported by the Meridian Link and CCR applications.
  • Page 280 262 Chapter 10: Installing peripheral devices The setup procedure is the same for all three terminals and is as follows: Turn on the terminal. Press the [Set-Up] key to enter setup mode. The current setup values are displayed on a series of screens. Using the following procedures, change the values on each screen to match the values in the appropriate table.
  • Page 281 Table 95 VT220 Setup values Set-Up Directory On Line Display Set-Up 80 Columns Interpret Controls No Auto Wrap Jump Scroll General Set-Up VT200 Mode, 8 Bit Controls User Defined Keys Unlocked User Features Unlocked Multinational Communications Set-Up Transmit=9600 Receive=Transmit Xoff at 128 8 bits, No Parity Printer Set-Up Set up according to your printer requirements (if any).
  • Page 282 264 Chapter 10: Installing peripheral devices Table 96 VT320 Setup values Set-Up Directory On Line Display Set-Up 80 Columns Interpret Controls No Auto Wrap Jump Scroll General Set-Up VT300 Mode, 8 Bit Controls VT220 ID User Defined Keys Unlocked User Features Unlocked Application Keypad Communications Set-Up Transmit=9600...
  • Page 283 Table 97 VT420 Setup values Global Set-Up On Line Sessions on Comm1 CRT Saver Display Set-Up 80 Columns Interpret Controls No Auto Wrap Jump Scroll Dark Screen Cursor Block Cursor Style General Set-Up VT400 Mode, 8 Bit Controls User Defined Keys Unlocked User Features Unlocked 8-bit Characters Application Keypad...

  • Page 284: Personal Computer Running Reflection 4

    266 Chapter 10: Installing peripheral devices Personal computer running Reflection 4+ Reflection 4+ is a customer-supplied communications software package that runs on a personal computer, which can then be used as a terminal for accessing the Meridian Link and CCR applications. To use Reflection 4+ on a PC, you must first download a configuration file.

  • Page 285: Meridian Terminal Emulator (Mte 8)

    If you need to quit Reflection 4+ (after logging out of the system), press [Alt]+[Ctrl]+[m] to see the Reflection 4+ menu bar. Press <F8> twice. To use the configuration file at any time, go to the appropriate directory, type r4 meridian.cfg, and press [Enter]. Meridian Terminal Emulator (MTE 8) Meridian Terminal Emulator Release 8 allows you to connect to your CCR application from your PC using Microsoft Windows NT or Windows 95.

  • Page 286: Dot-Matrix Printer Switch Settings

    268 Chapter 10: Installing peripheral devices Dot-matrix printer switch settings The HP Rugged Writer is a dot-matrix printer. This printer can be configured in HP PCL mode, which provides ISO Latin-1 international support as well as higher-quality graphics, or in Epson mode, which provides faster printing of reports.

  • Page 287: Laserjet Series Ii Printer Switch Settings

    LaserJet series II printer switch settings Use the [Menu] key on the front panel to check and set the options. Press the Menu key to access the first group of settings. Hold the [Menu] key down for about five seconds (the printer is offline) to access the second group of settings.

  • Page 288: Laserjet Series Iii Printer Switch Settings

    270 Chapter 10: Installing peripheral devices LaserJet series III printer switch settings Use the [Menu] key on the front panel to check and set the options. Press the [Menu] key to access the first group of settings. Hold the [Menu] key down for about five seconds (the printer is offline) to access the second group of settings.

  • Page 289: Laserjet Series Iv Printer Switch Settings

    LaserJet series IV printer switch settings Use the [Menu] key on the front panel to check and set the options. Press the [Menu] key to access the first group of settings. Hold the [Menu] key down for about five seconds (the printer is offline) to access the second group of settings.

  • Page 290: Deskjet And Deskjet 500 Printer Switch Settings

    272 Chapter 10: Installing peripheral devices DeskJet and DeskJet 500 printer switch settings The DeskJet and DeskJet 500 are inkjet printers. Figure 78 shows each printerÕs correct switch settings for use with CCR (the arrows point in the direction you should move the switch handle). Figure 78 DeskJet and DeskJet 500 printer switch settings BANK A...

  • Page 291: Chapter 11: Peripheral Device Cabling Interface

    Chapter 11: Peripheral device cabling interface You should use this chapter in conjunction with Chapter 5, ÒHardware installation overview,Ó which links hardware installation procedures in easily understood tables (Tables 11 and 12). This chapter provides information pertaining to special installing and configuration requirements.
  • Page 292 Chapter 11: Peripheral device cabling interface ¥ using a null-modem cable A null-modem cable (a special cable, or a cable with an adapter) crosses certain RS-232 data signals so that a DTE-to-DTE or DCE-to-DCE connection behaves like a standard DCE-to-DTE connection. A null-modem cable is shown in Figure 80. Note that null-modem cables and connectors are commonly used in asynchronous connections (to terminals or modems, for example) but cannot always be used in synchronous connections (to the Host or AML).
  • Page 293 Chapter 11: Peripheral device cabling interface 275 Figure 80 Null modem RS-232 cable Note 1: This cable applies equally to a configuration with a DCE device at each end. Note 2: Pins 15 and 17 are used for some configurations. The ports on the IPE Module can be configured as DCE or DTE using connectors on the CPU adapter card.

  • Page 294: Using An A/B Switchbox To Share System Consoles

    Chapter 11: Peripheral device cabling interface Using an A/B switchbox to share system consoles You can use a single terminal as a system console for more than one application if you use an A/B switchbox. Follow the installation procedure below to install the NT3M50AD (A0345353) and similar A/B switchboxes. Note: Using an A/B switchbox to switch a console from one module (either an IPE Module or an Application Module) to another may cause system error messages to be lost.

  • Page 295: Using The A/B Switchbox To Switch Applications

    Using the A/B switchbox to switch applications Log out of any administration, maintenance, or application function on the system console. The ÒConsole Login:Ó prompt appears. Use the switch at the front of the A/B switchbox to select the other application. Press [Return] to see the ÒConsole Login:Ó...

  • Page 296: Modems

    Chapter 11: Peripheral device cabling interface Modems Modems are used to connect peripheral devices (terminals and printers) to the IPE Module or the Application Module over long distances. Modems are always DCE. Limited-distance modem If a peripheral device is to be installed more than 15 m (50 ft) away from the IPE Module or the Application Module, you will need to use a self- powered limited-distance modem.

  • Page 297: Usrobotics Sportster Modem

    USRobotics Sportster modem The USRobotics Sportster (14.4) modem allows you to extend the distance between the IPE Module or the Application Module and any connected peripheral equipment. The switch settings are shown in the following table. Table 102 USRobotics Sportster switch settings Switch setting Note: When dialing up the system, you may need to send several <BREAK>...

  • Page 298: Gandalf Lds 120E Limited-Distance Modem

    Chapter 11: Peripheral device cabling interface Gandalf LDS 120E limited-distance modem The Gandalf LDS 120E limited-distance modem allows you to extend the distance between the IPE Module or the Application Module and any connected peripheral up to a nominal distance of 8 km (5 miles). Figure 81 illustrates the hardware configuration required to use the Gandalf LDS 120E modem.
  • Page 299 Chapter 11: Peripheral device cabling interface 281 Figure 81 Hardware configuration using a Gandalf LDS 120E limited-distance modem multi-port cable ¥ DB25 straight cable Null modem adapter Gandalf LDS 120E Twisted pairs Figure 82 Gandalf LDS 120E limited-distance modemÑjumper option settings TERM PHASE Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...

  • Page 300: Dial-Up Modem

    Chapter 11: Peripheral device cabling interface Dial-up modem If you want to dial up to ports on the IPE Module or the Application Module, you can use any one of five modems: Universal Data Systems (UDS) 2440 A/D modem, EC224 A/D modem, Ven-Tel 2400 baud modem, Ven-Tel 2400 Plus II baud modem, and Ven-Tel 9600 plus baud modem.
  • Page 301 Chapter 11: Peripheral device cabling interface 283 Configuring the UDS 2440 modem for remote diagnostics There are two ways to configure the UDS 2440 modem for remote diagnostics: one procedure uses the modemÕs front panel buttons, while the alternative procedure allows for configuration via a workstation. Both procedures are outlined below.
  • Page 302 Chapter 11: Peripheral device cabling interface Table 103 UDS 2440 modem configuration (front panel buttons) Prompt OFFLINE DIAL? TEST AUTO ANS? DATA OPTS? OPTIONS? RESET? LOADING (appears for one second) RESET? FACTORY? FACTORY 0? LOADING (appears for one second) FACTORY? SPKR OPTS? TELE OPTS? PIN OPTS?
  • Page 303 Chapter 11: Peripheral device cabling interface 285 Table 103 UDS 2440 modem configuration (front panel buttons) (continued) Prompt OFFLINE? DIAL? TEST? AUTO ANS? AUTO ANS E? RINGS? RING = 001? AUTO ANS? DATA OPTS? OPTIONS? RESET? FACTORY? SPKR OPTS? TELE OPTS PIN OPTS? DTR OPTS? DTR OPTS 0?
  • Page 304 Chapter 11: Peripheral device cabling interface Table 103 UDS 2440 modem configuration (front panel buttons) (continued) Prompt DSR OPTS? CD OPTS? CD FORCED? lo at disc cd normal CD OPTS? CTS OPTS? P 21 OPTS? P 23 OPTS? P 25 OPTS? PIN OPTS? MSG OPTS? SECURITY?
  • Page 305 Chapter 11: Peripheral device cabling interface 287 Connect the modem directly to the IPE Module or Application Module, as described in Chapter 9, ÒMeridian Link/CCR interface cabling.Ó If the modem installation is successful, the LED labelled ÒTRÓ on the front panel of the modem lights up. The following procedure explains how to configure the UDS 2440 modem using a workstation.
  • Page 306 Chapter 11: Peripheral device cabling interface Figure 84 Universal Data Systems (UDS) EC224A/D modemÑswitch locations and settings Left Figure 85 Ven-Tel 2400 modemÑopening the modem Figure 86 Ven-Tel 2400 modem SW2 switch settings 553-3202-210 Standard October 1998 Switch 1 Switch 2 Switch 3 Front Modem Computer Board...
  • Page 307 Chapter 11: Peripheral device cabling interface 289 Figure 87 Ven-Tel 2400 modemÑswitch locations ¥ ¥ ¥ ¥ Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide ¥ ¥ SW1 Power switch RS232/EIA socket SW2 switch (red) ¥ Power cable socket Line out Line in The Reset button...
  • Page 308 Chapter 11: Peripheral device cabling interface Figure 88 Ven-Tel 2400 Plus II modemÑopening the modem Bottom Grooves Figure 89 Ven-Tel 2400 Plus II modem switch settings The indicators on the front panel of the Ven-Tel 2400 and 2400 Plus II modems are labelled.
  • Page 309 Chapter 11: Peripheral device cabling interface 291 Figure 90 Ven-Tel 2400 Plus II modemÑswitch locations ¥ ¥ ¥ ¥ Figure 91 Ven-Tel 9600 Plus modemÑopening the modem Modem Computer Board Bottom ¥ Grooves Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide ¥...
  • Page 310 Chapter 11: Peripheral device cabling interface Figure 92 Ven-Tel 9600 Plus modemÑswitch locations and settings Figure 93 Dial-up modemÑVen-Tel 9600 Plus modem SW2 switch settings 553-3202-210 Standard October 1998 ¥ ¥ ¥ ¥ ¥ ¥ ¥ Power switch RS-232/EIA socket SW2 switch (red) ¥...

  • Page 311: Chapter 12: Meridian 1 Configuration

    Chapter 12: Meridian 1 configuration for Meridian Link/CCR You should use this chapter in conjunction with Chapter 5, ÒHardware installation overview,Ó which links hardware installation procedures in easily understood tables (Tables 11 and 12). This chapter shows how to use various software programs to configure the Meridian 1 to support Meridian Link and CCR.
  • Page 312 294 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 105 presents some of these conventions. Table 105 Standard notation for X11 software administration Notation Explanation Text string loop Network loop number (0Ð159) l s c u Loop, shelf, card, unit for a terminal number (TN) <cr>...

  • Page 313: Configuration Overview

    Configuration overview Install or upgrade the Meridian 1 to the appropriate software release (see Chapter 2, ÒOverview of Meridian LinkÓ or Chapter 3, ÒOverview of Customer Controlled RoutingÓ). To upgrade an existing system, refer to Software Conversion Procedures (NTP 553-2001-320). Summary of Meridian 1 configuration Define the ESDI/MSDL, STA, and SDI ports in the Configuration Record (LD 17).

  • Page 314: Configuring The Vsid, Hsid, And Aml Prompts

    296 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configuring the VSID, HSID, and AML prompts When you are configuring the Meridian 1, you will encounter the VSID, HSID, and AML prompts in LD17, LD15 and LD23. If you are adding Meridian Link or CCR to an IPE Module or an Application Module to create a co-resident system, you should understand what these prompts mean to avoid confusion.
  • Page 315 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 297 ¥ A Meridian 1 with two modules (two Application Modules, or two IPE Modules, or one of each), one module with Meridian Link but not CCR activated, one module with CCR but not Meridian Link activated: Ñ...
  • Page 316 298 Chapter 12: Meridian 1 configuration for Meridian Link/CCR ¥ A Meridian 1 with a single IPE Module or Application Module active and a redundant Meridian Link (another IPE Module or Application Module on warm standby mode): Ñ VSID prompt (LD17) Enter a value to define the VAS ID to be Ñ...

  • Page 317: Configure Esdi Port (X11 Release 17)

    Configure ESDI port (X11 Release 17) The IPE Module or Application Module is connected to the Meridian 1 through a port on a QPC513 ESDI card (vintage G or later) or an NTAK02 SDI/DCH card (Option 11, IPE Module only). The port must have the AML identified (VSID 0Ð15).
  • Page 318 300 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 106 LD 17ÑConfigure ESDI port (Options 21Ð81) (continued) Prompt DUPX CLOK IADR RADR LCTL LTHR USER ADAN VSID DLOP 553-3202-210 Standard October 1998 Response Comment FULL Full duplex mode 19200 19,200 bps baud rate (19.2 kbps).
  • Page 319 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 301 Table 106 LD 17ÑConfigure ESDI port (Options 21Ð81) (continued) Prompt Response SECU INTL MCNT CONF <cr> VSID <cr> <cr> CSQI (20)Ð255 CSQO (20)Ð255 ¥ ¥ ¥ Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment ESDI port number for this AML.

  • Page 320: Enable Esdi Port (X81 Phase 7 Or X11 Release 17)

    302 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Enable ESDI port (X81 phase 7 or X11 Release 17) Commands in LD 48 require a port or link parameter, which is indicated in the prompts as xx. Substitute the appropriate port or link number when using the prompts listed below.
  • Page 321 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 303 Table 107 LD 48ÑLink Diagnostic (continued) Command Comment DIS MSGI/MSGO Disable message input/output monitoring (xx=link, xx yy yy=priority) FLSH Disable monitor and trash buffers STAT MON Get status of message monitoring ENL PACI/PACO Enable packet input/output monitoring (xx=link) DIS PACI/PACO...
  • Page 322 304 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 107 LD 48ÑLink Diagnostic (continued) Command DSXT MSGI/MSGO xx ENIT MSGI/MSGO xx <l> <s> <c> <u> DSIT MSGI/MSGO xx SLFT ESDI xx STAT CMS xx STAT ESDI xx Note: These are not recommended for systems with heavy traffic. 553-3202-210 Standard October 1998 Comment Disable exclusive TN message monitoring on link...

  • Page 323: Configure Esdi Or Msdl Port (X11 Release 18 Or Later)

    Configure ESDI or MSDL port (X11 Release 18 or later) The IPE Module or the Application Module is connected to the Meridian 1 through a port on a QPC513 ESDI card (vintage G or later), NTAK02 SDI/DCH card (Option 11, IPE Module only), or NT6D80 MSDL card. The port must have the Application Module Link (AML) identified (VSID 0Ð15).
  • Page 324 306 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 108 LD 17ÑConfigure ESDI or MSDL port (Option 11) (continued) Prompt LCTL LTHR ADAN PARM CEQU OVLY VSID DLOP 553-3202-210 Standard October 1998 Response Comment Modify link control parameters Layer 2 retransmission timer in units of 0.5 seconds Layer 2 acknowledge timer in units of 0.5 seconds...
  • Page 325 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 307 Table 108 LD 17ÑConfigure ESDI or MSDL port (Option 11) (continued) Prompt Response 0Ð15 SECU INTL <cr> MCNT <cr> CONF <cr> VSID <cr> <cr> ATRN <cr> ALARM <cr> ¥ ¥ ¥ CHG, END Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment...

  • Page 326: Option 21Ð81 Esdi Or Msdl Configuration

    308 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Option 21Ð81 ESDI or MSDL configuration Table 109 LD 17ÑConfigure ESDI or MSDL port (Options 21Ð81) Prompt TYPE ADAN CTYP DNUM PORT PARM CLOK IADR 553-3202-210 Standard October 1998 Response Comment Create or change information in the database Configuration record data block...
  • Page 327 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 309 Table 109 LD 17ÑConfigure ESDI or MSDL port (Options 21Ð81) (continued) Prompt Response RADR LCTL LTHR RXMT* 1Ð(5)Ð20 CRC* 1Ð(10)Ð20 ORUR* 1Ð(5)Ð255 Unless there are exceptional reasons to use other values, use the default values for the four out-of-service parameters: RXMT 5, CRC 10, ORUR 5, and ABOR 5.
  • Page 328 310 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 109 LD 17ÑConfigure ESDI or MSDL port (Options 21Ð81) (continued) Prompt ABOR* ADAN VSID SECU INTL MCNT CONF VSID CSQI Unless there are exceptional reasons to use other values, use the default values for the four out-of-service parameters: RXMT 5, CRC 10, ORUR 5, and ABOR 5.
  • Page 329 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 311 Table 109 LD 17ÑConfigure ESDI or MSDL port (Options 21Ð81) (continued) Prompt Response CSQO (20)Ð255 ¥ ¥ ¥ CHG, END Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment Maximum call registers for AML output queues Set CSQI and CSQO equal to the...

  • Page 330: Enable Esdi Or Msdl Port (X11 Release 18 Or Later)

    312 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Enable ESDI or MSDL port (X11 Release 18 or later) Commands in LD 48 require a port or link parameter, which is indicated in the prompts as xx. Substitute the appropriate port or link number when using the prompts listed below.
  • Page 331 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 313 Table 110 LD 48ÑLink Diagnostic (continued) Command Comment FLSH Disable monitor and trash buffers STAT MON Get status of message monitoring ENL PACI/PACO Enable packet input/output monitoring (xx=link) DIS PACI/PACO xx Disable packet input/output monitoring (xx=link) ENXM Enable message input/output monitoring...
  • Page 332 314 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 110 LD 48ÑLink Diagnostic (continued) Command ENIT MSGI/MSGO xx <l> <s> <c> <u> DSIT MSGI/MSGO xx DIS AML xx aaa EST AML xx RLS AML xx STAT AML STAT AML xx SLFT AML xx SWCH AML i j MAP AML xx...

  • Page 333: Configure Sdi Port For Conshare (X11 Release 17)

    Configure SDI port for conshare (X11 Release 17) The SDI port is used for the optional console sharing feature, which allows the IPE Module or the Application Module console to access Meridian 1 administration and maintenance programs. Port settings on the card should reflect TTY mode at 2400 baud.
  • Page 334 316 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 111 LD 17ÑConfigure SDI port (X11 Release 17) (continued) Prompt MSCL ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment <cr> Press [Return] until the REQ prompt appears CHG, END Either change more configuration data or exit the overlay, saving changes to the configuration record...

  • Page 335: Configure Sdi Port For Conshare (X11 Release 18 Or Later)

    Configure SDI port for conshare (X11 Release 18 or later) The SDI port is used for the optional console sharing feature, which allows the IPE Module or the Application Module console to access Meridian 1 administration and maintenance programs. Port settings on the card should reflect TTY mode at 2400 baud.

  • Page 336: Enable Sdi Port

    318 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Enable SDI port Some commands in LD 37 require a port number, indicated in the prompts as x. Substitute the appropriate port number in the prompts listed below. Table 113 LD 37ÑInput/output diagnostic Command DIS TTY x ENL TTY x...

  • Page 337: Configuring Dnis To Use Auto-Terminating Trunks

    Configuring DNIS to use auto-terminating trunks Dialed Number Identification Service (DNIS) is an optional feature that provides the last digits of the dialed number. DNIS is defined by responding to specific prompts in LD 15, LD 16, and LD 14. This section describes how you can configure DNIS to use auto-terminating trunks.

  • Page 338: Ld 16Ñroute Data Block

    320 Chapter 12: Meridian 1 configuration for Meridian Link/CCR LD 16ÑRoute data block LD 16 defines the route (Table 115). The routes used for DNIS must auto- terminate. All incoming calls on a DNIS route, regardless of the number dialed, will terminate on a pre-specified DN. This DN is defined for each trunk in LD 14 (Table 116).
  • Page 339 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 321 Table 115 LD 16ÑTrunk route administration (continued) Prompt Response DNIS NDGT 1-(4)-31 ICOG ACOD xxxx ¥ ¥ ¥ Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment ACD-Dialed Number Identification Service (DNIS) route.

  • Page 340: Ld 14Ñtrunk Data Block

    322 Chapter 12: Meridian 1 configuration for Meridian Link/CCR LD 14ÑTrunk data block The pre-specified DN (auto-terminate DN) where all incoming calls on a DNIS route auto-terminate is defined in this program. Note: The ATDN must be defined prior to configuration. Table 116 LD 14ÑConfigure auto-terminating DN Prompt...
  • Page 341 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 323 Table 116 LD 14ÑConfigure auto-terminating DN Prompt Response SUPN (NO), YES TKID ¥ ¥ ¥ Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment Answer and disconnect supervision required Trunk identifier Press [Return] until the REQ prompt appears...

  • Page 342: Configuring Dnis To Use Incoming Digit Conversion

    324 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configuring DNIS to use Incoming Digit Conversion The Incoming Digit Conversion (IDC) feature can optionally be used to provide routing by DNIS number as an alternative to using auto-terminating trunks (see ÒConfiguring DNIS to use auto-terminating trunksÓ earlier in this chapter).
  • Page 343 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 325 In order for DNIS to be used on Incoming Digit Conversion trunks, the trunk route must be configured to allow DNIS and IDC (Incoming Digit Conversion). Table 118 LD 16ÑTrunk route administration Prompt Response NEW, CHG...
  • Page 344 326 Chapter 12: Meridian 1 configuration for Meridian Link/CCR X11 Release 23 allows 7 full digits of DNIS information to be sent across the link. X22 Release 24 supports up to a 31-digit DNIS. Both DNIS and ACD DN ranges can be expressed explicitly or implicitly. For example: ¥...
  • Page 345 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 327 Table 119 LD 49ÑDefining IDC translation tables (continued) Prompt Response 2000 8900 2001 8900 2003 8989 2004 ¥ ¥ ¥ 2010 8907 IDGT <cr> Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment When the starting DNIS number (for example, 2000) is prompted, enter the ACD...
  • Page 346 328 Chapter 12: Meridian 1 configuration for Meridian Link/CCR If, in a block of DNIS numbers, all numbers start with the same two or three digits, and if all numbers are to be translated to the same ACD DN, the program does not need translation entries for all numbers in the block.
  • Page 347 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 329 If the last digits of the DNIS number and the ACD DN are identical, the program allows a simpler definition. Table 121 LD 49ÑPartial digit conversion Prompt Response TYPE ¥ ¥ ¥...

  • Page 348: Configure Devices For Status Change Host Notification

    330 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configure devices for status change host notification An optional feature, Unsolicited Status Events are provided in status change messages, allowing 12 types of unsolicited status events to be sent to a host application.
  • Page 349 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 331 Note: The Unringing event is available only with X11 Release 19 and later software. X11 International Phase 7 software offers only four status change events. ¥ Transfer completed to notifies the application when a DN has completed a transfer to another DN.
  • Page 350 332 Chapter 12: Meridian 1 configuration for Meridian Link/CCR initiate a conference, the application receives a StatusChange hold message. ¥ Retrieve also known as Restore, notifies the application when the set that had invoked Hold retrieves the original call and becomes active again.

  • Page 351: Define Status Message Groups

    Chapter 12: Meridian 1 configuration for Meridian Link/CCR 333 Define status message groups Use LD 15 to define the status message groups. Table 122 LD 15ÑDefine status message groups Prompt Response TYPE AML_DATA or CUST 0Ð99 ¥ ¥ VSID 0Ð15 Examples are GRP2 1 2 3 6...
  • Page 352 334 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 122 LD 15ÑDefine status message groups (continued) Prompt ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment Default values are in group 0 and group 1: Group 0 = sends no messages Group 1 = sends all messages Groups 0 and 1 may be used in LD 10 and LD 11 in response to the IAPG...

  • Page 353: Assign Telephones To Status Message Groups (Meridian Link)

    Chapter 12: Meridian 1 configuration for Meridian Link/CCR 335 Assign telephones to status message groups (Meridian Link) Automatic Call Distribution (ACD) or non-ACD telephones can be assigned to status message groups if they are configured as AST (associated set). Define ACD groups and agents To configure an ACD group that uses Meridian Link, type yes at the ISAP prompt (and the AST prompt, for X81 software and X11 International Phase 7 software prior to Release 17).
  • Page 354 336 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 123 LD 23ÑBuild ACD groups (continued) Prompt ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment Press [Return] until the REQ prompt appears NEW, Either build another ACD group or exit the CHG, END overlay, saving changes Ñ...
  • Page 355 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 337 Define ACD telephones as AST After defining ACD groups, configure ACD agent telephones designated as AST for those groups; in LD 10 for single-line telephones and LD 11 for multi-line telephones. Table 124 LD 10ÑDefine single-line ACD telephones as AST Prompt...
  • Page 356 338 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 124 LD 10ÑDefine single-line ACD telephones as AST (continued) Prompt AACD ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment (1)Ð48 Priority level for ACD agent Associated set for ACD agent (X11 Release 17 or later software) ACD xxxx yyyy ACD feature allowed, where...
  • Page 357 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 339 Table 125 LD 11ÑDefine multi-line ACD telephones as AST Prompt Response TYPE l s c u CUST 0Ð99 1Ð7 ¥ ¥ ¥ 00 07 IAPG (0)Ð15* ¥ ¥ ¥ *Groups 10 through 15 are only available in X11 Release 17 or later software.
  • Page 358 340 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 125 LD 11ÑDefine multi-line ACD telephones as AST (continued) Prompt KEY 0 KEY 1 KEY 2 KEY 3 KEY 4 KEY 7 KEY 9 ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment ACD XXXXXXX...
  • Page 359 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 341 Define non-ACD telephones as AST To configure a DN as an AST telephone, make changes to telephone data in LD 10 for single-line telephones or LD 11 for multi-line telephones. Table 126 LD 10ÑDefine single-line telephones as AST Prompt Response...
  • Page 360 342 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 127 LD 11ÑDefine multi-line telephones as AST Prompt TYPE CDEN CUST ¥ ¥ IAPG ¥ ¥ ¥ *Groups 10 through 15 are only available in X11 Release 17 or later software.
  • Page 361 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 343 Table 127 LD 11ÑDefine multi-line telephones as AST (continued) Prompt Response KEY 0 SCR XXXX KEY 1 KEY 2 KEY 9 ¥ ¥ ¥ NEW, END Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Comment XXXX = AST DN Transfer...

  • Page 362: Configure Acd Dns

    344 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configure ACD DNs Two types of ACD DNs are described here: the default ACD DN and the ACD DN that handles IVR calls. See the X11 Input/Output Guide (NTP 553-3001-400) for information on configuring regular ACD DNs. Note: ACD DNs must be created on the Meridian 1 before variables can be created for them.
  • Page 363 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 345 Note: Systems with two modules (two Application Modules, two IPE Modules, or one of each), with Meridian Link activated in one and CCR activated in the other, will require two AMLs and hence two VAS IDs.

  • Page 364: Configure Control Dns (Ccr)

    346 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configure Control DNs (CCR) A Control DN (CDN) is a specialized ACD queue that has no agents. One CDN is required for each CCR script. A CDN in controlled mode offers control of calls to applications. A CDN when not in controlled mode is essentially the same as a CDN used in Enhanced ACD Routing (EAR), so the CDN/EAR parameters should be programmed in the same way other EAR CDNs are programmed at that site.
  • Page 365 Chapter 12: Meridian 1 configuration for Meridian Link/CCR 347 Table 130 LD 23ÑDefine CDNs (continued) Prompt Response FROA YES, (NO) MURT 0Ð511 DFDN nnnn CEIL 0Ð(2047) OVFL (NO), YES TDNS (NO), YES RPRT (YES), NO CNTL VSID 0Ð15 HSID 0Ð15 CWTH 0Ð(1)Ð2047 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide...
  • Page 366 348 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 130 LD 23ÑDefine CDNs (continued) Prompt BYTH OVTH ACNT 553-3202-210 Standard October 1998 Response Comment (0)Ð2047 Busy Threshold indicates the number of calls waiting in a controlled CDN before a monitoring supervisor or agentÕs DWC key would begin flashing to indicate that the CDN was busy.

  • Page 367: Configuring A Phantom Loop

    Configuring a Phantom Loop A phantom loop is configured the same way as a normal loop with the exception of a ÒCÓ preceeding the loop number. It is important that a physical loop card be installed. A phantom DN can then be configured as part of a specific device group.

  • Page 368: Configuring A Phantom Superloop

    350 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Configuring a Phantom Superloop A phantom superloop is configured the same way as a normal loop with the exception of a ÒCÓ preceeding the loop number. Table 132 LD 97ÑConfiguring a Phantom Superloop Prompt TYPE SUPL...

  • Page 369: Creating A Phantom Set

    Creating a Phantom Set After configuring the phantom loop, an AST Meridian 1 proprietary set can be designated to a specific device group which can be controlled by applications. Therefore, when an application wants to originate a call on behalf of an idle TN, it can use a phantom TN. This idle TN is an AST Meridian 1 proprietary set which is defined on a phantom loop.
  • Page 370 352 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Table 133 LD 10ÑCreating a Phantom Set (continued) Prompt CUST ¥ ¥ ¥ ¥ ¥ ¥ IAPG ITNA DGRP ¥ ¥ ¥ 553-3202-210 Standard October 1998 Response Comment 0-99 Customer number Press [Return] until the CLS prompt appears.

  • Page 371: Configuring Dual Vas Id

    Configuring Dual VAS ID Overlay 23 is modified to prompt for ISAP and VASID for Meridian Link even if the DN type is Meridian Mail ACD-DN. To configure an ACD-DN as Meridian Mail DN, type YES in response to prompts MWC, IMS, CMS, IMA and IVMS.

  • Page 372: Traffic Statistics

    354 Chapter 12: Meridian 1 configuration for Meridian Link/CCR Traffic statistics LD 2 is used to set and schedule traffic statistics for the Application Module Link (AML). A count is kept (in traffic report 8) of all incoming and outgoing messages, and these counts can be scheduled to print periodically. For more details on traffic, see Traffic Measurement (NTP 553-2001-450).

  • Page 373: Chapter 13: Meridian Mail Configuration

    Chapter 13: Meridian Mail configuration Host Enhanced Voice Processing (HEVP) provides basic voice-processing capabilities, via a Meridian Mail voice port, to applications based on Meridian Link. The HEVP feature (Meridian Link Service 101) requires dedicated Meridian Mail voice channels for use by Meridian Link-based applications.
  • Page 374 356 Chapter 13: Meridian Mail configuration This chapter provides ¥ a brief overview of how the Meridian 1 system, the Meridian Mail system, and the Meridian Link-based application configuration parameters are used as Meridian Mail calls are routed to the application ¥...

  • Page 375: Meridian Mail Call Processing

    Meridian Mail call processing Figure 94 shows the relationship between the Meridian 1 and Meridian Mail DNs and voice channels. The Meridian Link-based application separately acquires each channel, identifying it by its channel class. The Meridian Mail system messages also identify calls by the channel class. Figure 94 Meridian Mail call processing Meridian 1...

  • Page 376: Configuring Meridian 1 For Meridian Mail

    358 Chapter 13: Meridian Mail configuration Configuring Meridian 1 for Meridian Mail To configure the Meridian 1 for Meridian Mail, perform the following tasks: Create a Meridian Mail ACD queue in Overlay 23. Create virtual agents in Overlay 11, assigning them to the Meridian Mail queue.
  • Page 377 Table 136 LD 23ÑCreating an ACD queue for voice channels (continued) Prompt Response IVMS 0Ð15 VSID MAXP ALOG SDNB <cr> BSCW <cr> RGAI <cr> ¥ ¥ ¥ FCTH <cr> CRQS <cr> Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 13: Meridian Mail configuration Comment Link ID of the CSL to Meridian Mail (defined...

  • Page 378: Defining Virtual Agent Dns For Voice Channels

    360 Chapter 13: Meridian Mail configuration Defining virtual agent DNs for voice channels For each voice channel to be used by a Meridian Link-based application, you must create a virtual ACD agent and assign it to the Meridian Mail ACD queue. By being defined with Voice Messaging Allowed (VMA) class of service, each ACD agent functions as a Meridian Mail queue.
  • Page 379 Table 137 LD 11ÑDefining virtual agent DNs for voice channels Prompt Response TYPE l s c u CDEN <cr> xxxxx CUST <cr> TGAR <cr> <cr> NCOS <cr> RNPG <cr> <cr> XLST <cr> HUNT <cr> Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 13: Meridian Mail configuration Comment Create a new ACD agent...
  • Page 380 362 Chapter 13: Meridian Mail configuration Table 137 LD 11ÑDefining virtual agent DNs for voice channels (continued) Prompt SPID IAPG LANG 553-3202-210 Standard October 1998 Response Comment <cr> <cr> <cr> <cr> <cr> <cr> <cr> 0 ACD Identifies set as agent a Meridian Mail queue xxxxxxx yyyy Key 0 must be the ACD DN position ID of the virtual agent (as for any ACD agent), where...

  • Page 381: Configuring Meridian Mail For Host Enhanced Voice Processing (Hevp)

    Table 137 LD 11ÑDefining virtual agent DNs for voice channels (continued) Prompt Configuring Meridian Mail for Host Enhanced Voice Processing (HEVP) To configure the Meridian Mail system for the Host Enhanced Voice Processing (HEVP) feature of Meridian Link, perform the following tasks: Add the Meridian Mail ACD DN for HEVP applications to the Meridian Mail VSDN Table.
  • Page 382 364 Chapter 13: Meridian Mail configuration When adding an ACD DN for Meridian Link-based HEVP applications in the VSDN Table, observe the following: ¥ The service class must be ACC. ¥ A class number must be entered, but actual linkage between channel class and channel is made in the Channel Allocation Table (CAT), not in the VSDN Table.
  • Page 383 Table 138 Example of Meridian Mail Voice Service DN (VSDN) Table 4567 4568 7650 VM = service type Voice Messaging MS = service type Voice Menu ACC = service type Meridian 1 Access Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 13: Meridian Mail configuration Service Class...

  • Page 384: Defining Voice Channels In The Channel Allocation Table (Cat)

    366 Chapter 13: Meridian Mail configuration Defining voice channels in the Channel Allocation Table (CAT) The Channel Allocation Table (CAT) contains entries for each Meridian Mail voice channel. As shown in Table 139, the CAT stores the following voice channel attributes: ¥...
  • Page 385 Table 139 Example of Meridian Mail Channel Allocation Table (CAT) Channel Routing Link Location Address Location 01-5-1 10-1-2-3 01-1-02 01-5-2 10-1-2-4 01-1-02 01-5-3 10-1-2-5 01-1-02 01-5-4 10-1-2-6 01-1-02 Procedure to add channels to Meridian Mail Log in to Meridian Mail Administration. ¥...

  • Page 386: Defining A New Mailbox For The Application

    368 Chapter 13: Meridian Mail configuration Set the Service to ACC. Set the Channel class to an unused class number. Class numbers should start with 1 and be used in sequence, because the application must use the class numbers both to obtain access to the voice port and to identify activity on it.
  • Page 387 Figure 95 Meridian Mail Add Local Voice User screen User Administration Add Local Voice User Mailbox Number: *Location Prefix: Last Name: First Name: Department: Extension DNs: Revert DN: User Model: Personal Verification Recorded (Voice): Fill in the mailbox number and put descriptive comments in the First Name and Last Name fields.
  • Page 388 370 Chapter 13: Meridian Mail configuration 553-3202-210 Standard October 1998...

  • Page 389: Chapter 14: Software Installation, Upgrade, And Update Procedures

    Chapter 14: Software installation, upgrade, and update procedures This chapter describes how to ¥ initially configure a new IPE Module or the Application Module Note: If a redundant Meridian Link is required, a second module must be installed and configured separately. ¥...
  • Page 390 372 Chapter 14: Software installation, upgrade, and update procedures The keycode is provided as part of the software package and is tailored to your siteÕs requirements. The keycode consists of five groups of four hexadecimal characters. You will have received the following tapes with your IPE Module or Application Module: ¥...
  • Page 391 Chapter 14: Software installation, upgrade, and update procedures 373 Table 140 Software installation and upgrade paths From Meridian Link Meridian Link Release 2 Release 5C Meridian Link Co-residency Release 2 (Meridian Link 5C and CCR 3C) Meridian Link Meridian Link Release 3 Release 5C Meridian Link...
  • Page 392 374 Chapter 14: Software installation, upgrade, and update procedures Table 140 Software upgrade paths (continued) From Upissue of Meridian Link Meridian Link Release 5C Release 5 Upissue of Co-residency Meridian Link (Meridian Link 5C Release 5 and CCR 3C) Release 2 Release 3C Co-residency Release 2...

  • Page 393: To Configure The Software After Installing A New Ipe Module Or Application Module

    Chapter 14: Software installation, upgrade, and update procedures 375 To configure the software after installing a new IPE Module or Application Module The UNIX and application software are loaded onto the hard disk at the factory. Tapes containing the same software are shipped with your module as a backup.

  • Page 394: Section 1: To Upgrade Meridian Link From Release 2 To Release 5C Or Co-Residency Using A Release 2 Backup Tape

    376 Chapter 14: Software installation, upgrade, and update procedures Section 1: To upgrade Meridian Link from Release 2 to Release 5C or Co-residency using a Release 2 backup tape If you already have Meridian Link Release 2 and want to upgrade to Meridian Link Release 5C or Co-residency ¥...

  • Page 395: Section 2: To Upgrade Meridian Link From Release 3 To Release 5C Or Co-Residency Using A Release 3 Backup Tape

    Chapter 14: Software installation, upgrade, and update procedures 377 Section 2: To upgrade Meridian Link from Release 3 to Release 5C or Co-residency using a Release 3 backup tape If you already have Meridian Link Release 3 and want to upgrade to Meridian Link Release 5C or Co-residency: ¥...

  • Page 396: Section 3: To Upgrade Meridian Link From Release 4 To Release 5C

    378 Chapter 14: Software installation, upgrade, and update procedures Section 3: To upgrade Meridian Link from Release 4 to Release 5C If you have Meridian Link Release 4 and want to update to Release 5C, you must install the operating system, install the application, and then enter a keycode to activate it.

  • Page 397: Section 4: To Upgrade Meridian Link From Release 4 To

    Chapter 14: Software installation, upgrade, and update procedures 379 Section 4: To upgrade Meridian Link from Release 4 to Co-residency If you have Meridian Link Release 4 and want to upgrade to co-residency, you must install the operating system and install all applications.

  • Page 398: Section 5: To Upgrade Meridian Link From Release 4B To Release 5C

    380 Chapter 14: Software installation, upgrade, and update procedures Section 5: To upgrade Meridian Link from Release 4B to Release 5C If you have Meridian Link Release 4 and want to update to Release 5C, you must install the operating system tape, install the application, and then enter a keycode to activate it.

  • Page 399: Release 5C And Co-Residency

    Chapter 14: Software installation, upgrade, and update procedures 381 Section 6: To upgrade Meridian Link from Release 4B to Release 5C and Co-residency If you have Meridian Link Release 4B and want to upgrade to Release 5C and co-residency, you must install the operating system, then applications. Then you must enter a keycode to activate CCR and Meridian Link.

  • Page 400: Section 7: To Update Meridian Link From Release 5 To Release 5C

    382 Chapter 14: Software installation, upgrade, and update procedures Section 7: To update Meridian Link from Release 5 to Release 5C When you update Meridian Link from Release 5 to Release 5C, the release or issue of the BOS changes. ¥...

  • Page 401: Section 9: To Upgrade Ccr From Release 2 To Release 3C Or

    Chapter 14: Software installation, upgrade, and update procedures 383 Section 9: To upgrade CCR from Release 2 to Release 3C or Co-residency using a Release 2 backup tape If you already have CCR Release 2 and want to upgrade to CCR Release 3C or co-residency, do the following ¥...

  • Page 402: Section 10: To Update Ccr From Release 3 To Release 3C

    384 Chapter 14: Software installation, upgrade, and update procedures Section 10: To update CCR from Release 3 to Release 3C If you already have CCR Release 3 and want to update to Release 3C, you must install the application and then enter a keycode to activate it. To do this, ¥...

  • Page 403: Section 12: To Update Ccr Release 3B To Release 3C

    Chapter 14: Software installation, upgrade, and update procedures 385 Section 12: To update CCR Release 3B to Release 3C When you update CCR from Release 3B to Release 3C, the release or issue of the BOS changes. ¥ Perform Procedure 2: Start the update process. ¥...

  • Page 404: Section 15: Activating Or De-Activating A Meridian Link Or Ccr Feature

    386 Chapter 14: Software installation, upgrade, and update procedures If the release or issue of BOS changes, ¥ Perform Procedure 2: Start the update process. ¥ Depending on the type of SBC card installed, perform one of the following: Ñ Procedure 5: Load the operating system tape on an Application Ñ...
  • Page 405 Chapter 14: Software installation, upgrade, and update procedures 387 ¥ Depending on the type of SBC card installed, perform one of the following: Ñ Procedure 5: Load the operating system tape on an Application Module with an MVME147 card Ñ Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card ¥...

  • Page 406: Procedure 1: Application Configuration And Start-Up

    388 Chapter 14: Software installation, upgrade, and update procedures Procedure 1: Application configuration and start-up Set the Application Module circuit breaker or the IPE Module power pushbutton to ON (if it is not already on). Wait for the system to boot UNIX from the hard disk. If the ÒConsole Login:Ó...
  • Page 407 Chapter 14: Software installation, upgrade, and update procedures 389 Procedure 1: Application configuration and start-up (continued) Note: If you make a mistake while typing your Meridian ID or keycode, do not try to backspace and correct the error. Instead, continue until step 15, where you will be able to type n, press [Return] and return to step 6.
  • Page 408 390 Chapter 14: Software installation, upgrade, and update procedures Procedure 1: Application configuration and start-up (continued) Figure 101 Keycode prompt 4 Keycode group 4 (or Q or q to quit): You are prompted for the fourth group of keycode characters. Type the fourth group and press [Return].
  • Page 409 Chapter 14: Software installation, upgrade, and update procedures 391 Procedure 1: Application configuration and start-up (continued) Figure 104 IP address prompt Meridian Link using a TCP/IP connection. If you would like a default gateway IP address configured or changed, please enter the IP address in internet dot notation (e.g.
  • Page 410 392 Chapter 14: Software installation, upgrade, and update procedures Procedure 1: Application configuration and start-up (continued) The system lists the application or applications installed. Note: Figure 106 only shows applications that have been selected; they are actually enabled when the system reboots at the end of this procedure.
  • Page 411 Chapter 14: Software installation, upgrade, and update procedures 393 Procedure 1: Application configuration and start-up (continued) Figure 108 Ethernet connection prompt Installing NSE R3V7.1. Please wait. Is your module connected to the Ethernet (y/n) ? You are asked whether your Application Module or IPE Module is connected to Ethernet (Figure 108).
  • Page 412 394 Chapter 14: Software installation, upgrade, and update procedures Procedure 1: Application configuration and start-up (continued) Figure 109 Software install messages Configuring your system for NSE. Please wait. /usr/src/uts/m68k/sysgen/sysgen -l /usr/src/uts/m68k/sysgen LIBDIR=../cf SYS= CFLAGS= -O L -DSTREAMS -DBRIDGE CPU=m68k CC=/bin/pcc/cc "DASHO=-O"...
  • Page 413 Chapter 14: Software installation, upgrade, and update procedures 395 Procedure 1: Application configuration and start-up (continued) Figure 111 Module address prompt Enter the MODULE ADDRESS to be added to the tcpip transport provider database (?, or module address): You are prompted for the address of the Application Module or IPE Module (Figure 142).
  • Page 414 396 Chapter 14: Software installation, upgrade, and update procedures Procedure 1: Application configuration and start-up (continued) You are prompted to reboot the system (Figure 144). Type y and press [Return]. The appearance of the ÒConsole Login:Ó prompt indicates that the new package is now installed.

  • Page 415: Procedure 2: Start The Update Process

    Chapter 14: Software installation, upgrade, and update procedures 397 Procedure 2: Start the update process This procedure describes how to begin the update process. If you intend to back up your configuration files and data files, ensure that you have a blank write-enabled tape available before you start this procedure.
  • Page 416 398 Chapter 14: Software installation, upgrade, and update procedures Procedure 2: Start the update process (continued) Figure 117 Tape insertion message screen Insert the removable medium for the package you want to install into the ctape drive. Press <RETURN> when ready. At this point the system is ready to be updated from a tape.

  • Page 417: Procedure 3: Load Application Software From Tape

    Chapter 14: Software installation, upgrade, and update procedures 399 Procedure 3: Load application software from tape This procedure describes how to insert the tape cartridge and load the application software. The procedure assumes you have just performed Procedure 2 to start the update process. CAUTION Risk of accidental overwriting of data on tape The application tape cartridge must be write-protected...
  • Page 418 400 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) Insert the tape (marked Tape 2 of 2) into the tape drive as shown in Figure 119. Ensure that the tape drive latch (if present) is fully closed after the tape is inside.
  • Page 419 Chapter 14: Software installation, upgrade, and update procedures 401 Procedure 3: Load application software from tape (continued) Do not attempt to press a keyboard key until the tape active indicator light goes from on to off and stays off. The tape drive can enter a nonoperational state if operations are attempted before the drive is completely ready.
  • Page 420 402 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) Figure 121 Meridian 1 ID prompt Please enter the Meridian 1 ID of this site: (or Q or q to quit) You are prompted to enter your Meridian 1 ID (Figure 121). Type your ID and press [Return].
  • Page 421 Chapter 14: Software installation, upgrade, and update procedures 403 Procedure 3: Load application software from tape (continued) Figure 124 Keycode prompt 3 Keycode group 3 (or Q or q to quit): You are prompted for the third group of keycode characters (Figure 124).
  • Page 422 404 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) If you are activating the Meridian Link application, you are prompted to enter the Meridian Link protocol. If you are using the X.25 protocol, type x, press [Return], then go to step 13.
  • Page 423 Chapter 14: Software installation, upgrade, and update procedures 405 Procedure 3: Load application software from tape (continued) Figure 130 List verification prompt Saving default subnet mask: The following applications are configured: Meridian Link Large CCR The following packages are configured: Ethernet NSE software is enabled.
  • Page 424 406 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) If you did not purchase CCR but you have enabled NSE, go to step 16. For more information about Ethernet connections, refer to ÒInstalling Ethernet LAN supportÓ...
  • Page 425 Chapter 14: Software installation, upgrade, and update procedures 407 Procedure 3: Load application software from tape (continued) If you are connected to Ethernet but do not plan to use it in the near future, you may choose to type n and press [Return]. Disabling Ethernet support increases the processing power available to your application(s).
  • Page 426 408 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) Figure 134 Module name prompt ADD MODULE NAME AND ADDRESS TO TCPIP TRANSPORT PROVIDER DATABASE If you are not sure how to answer any prompt, type Ò?Ó for HELP. Your moduleÕs system is currently the default name.
  • Page 427 Chapter 14: Software installation, upgrade, and update procedures 409 Procedure 3: Load application software from tape (continued) You are asked whether you want to reenter the module name or address (Figure 136). If you have not made a mistake, type n and press [Return]. Go to step 19.
  • Page 428 410 Chapter 14: Software installation, upgrade, and update procedures Procedure 3: Load application software from tape (continued) Figure 139 Reboot messages 2 Copyright Motorola Inc. 1988 - 1992, All Rights Reserved M4120 Debugger/Diagnostics Release Version 1.1 - 09/30/92 (IR01) COLD Start Local Memory Found =01000000 (&16777216) MPU Clock Speed =25Mhz Autoboot in progress...

  • Page 429: Procedure 4: Power Down The Ipe Module Or The Application Module

    Chapter 14: Software installation, upgrade, and update procedures 411 Procedure 4: Power down the IPE Module or the Application Module At the ÒConsole Login:Ó prompt, type maint and press [Return]. At the ÒpasswordÓ prompt, type maint and press [Return]. At the ÒmaintÓ prompt, type powerdown and press [Return] Figure 140 Powerdown notification message screen 1 maint>...
  • Page 430 412 Chapter 14: Software installation, upgrade, and update procedures Procedure 4: Power down the IPE Module or the Application Module (continued) If software users are logged in, a list appears. Whether a list appears or not, you are prompted to start an express powerdown. If no list appears, or if you do not wish to alert all logged-in users, type y and press [Return].

  • Page 431: Procedure 5: Load The Operating System Tape On An Application Module With An Mvme147 Card

    Chapter 14: Software installation, upgrade, and update procedures 413 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card This procedure assumes that you have backed up all files and have powered down the Application Module (Procedure 4). Do not press the [Backspace] or [Delete] key when the operating system is not installed, or you may drop out of the procedure into a previous menu or out of the installation procedure altogether.
  • Page 432 414 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Type h immediately, before the next prompt appears. (You have about five seconds to do this.) Write down the firmware release listed on the second message line.
  • Page 433 Chapter 14: Software installation, upgrade, and update procedures 415 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 146 Disk/tape controller list after aligning LUNs Disk Controllers Available Type Address # dev VME147 $FFFE4000 SCSI Addr = 0 - FUJITSU...
  • Page 434 416 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 148 SCSI bus reset prompts Reset Local SCSI Bus (Y, N) Automatic reset of known SCSI Buses on RESET (Y, N) = Y? < Cold/Warm Reset flag (C, W) = C? Execute Soft Reset (Y, N) When the Ò147-Diag>Ó...
  • Page 435 Chapter 14: Software installation, upgrade, and update procedures 417 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 151 Environment prompts for firmware revision 2.42 Bug or System environment [B,S] = S? Execute/Bypass System Memory Sizing [E,B] = B? Execute/Bypass SST Memory test [E,B] = B? Set VME Chip:...

  • Page 436: Tape Drive

    418 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 152 Insert tape into the tape drive Arrow points in BOS installation tape Tape Notch points down Figure 153...
  • Page 437 Chapter 14: Software installation, upgrade, and update procedures 419 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) When the tape indicator goes off, type 2 and press [Return]. You are prompted to enter the alternate boot device. Type 4, and press [Return].
  • Page 438 420 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) During the installation or start-up of BOS, different characters than usual represent the character delete, line delete, and interrupt functions. During these operations, ¥...
  • Page 439 Chapter 14: Software installation, upgrade, and update procedures 421 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Type 1 and press [Return] to install the software. The BOS installation procedure begins. Figure 156 BOS installation, phase 1 BOS INSTALLATION PROCEDURE Phase 1.
  • Page 440 422 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 158 Disk drive selection list The MVME147 CPU Processor/SCSI Controller may be used to install the BOS product on the following disk drive types.
  • Page 441 Chapter 14: Software installation, upgrade, and update procedures 423 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Type the number corresponding to your disk drive, and press [Return]. The system response is ÒSelected the XXXX disk type,Ó where XXXX represents the disk type selected.
  • Page 442 424 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) You are prompted to enter the user file system slice number. Press [Return] to use the default slice number (2). Phase 2 of the BOS installation begins, and the slice table appears.
  • Page 443 Chapter 14: Software installation, upgrade, and update procedures 425 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 164 Disk-slicing table for 180-Mbyte disk drive slice offset sl size fs size fsname 60000 60000 60648...
  • Page 444 426 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) You are prompted to indicate whether you wish to install online problem descriptions. Nortel does not use these descriptions. Type n and press [Return] to indicate no.
  • Page 445 Chapter 14: Software installation, upgrade, and update procedures 427 Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Note: Phases 3 and 4 may take from 30 to 90 minutes to complete. Figure 170 BOS installation, phases 3 and 4 ***>...
  • Page 446 428 Chapter 14: Software installation, upgrade, and update procedures Procedure 5: Load the operating system tape on an Application Module with an MVME147 card (continued) Figure 171 BOS installation, completion Re-enter new password: ***> Unmounting all mounted file systems ***> Synchronizing the installation disk You must RESET the system and allow it to autoboot from the hard disk Remove the BOS tape from the drive.

  • Page 447: Module Or An Application Module With An Mvme167 Card

    Chapter 14: Software installation, upgrade, and update procedures 429 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card If you have just installed a new MVME167 card in an Application Module and you are installing the software for the first time, you need to do steps 2Ð6.
  • Page 448 430 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) At the Ò4120-Diag>Ó or Ò4120-Bug>Ó prompt, type env and press [Return]. The environment prompts appear.
  • Page 449 Chapter 14: Software installation, upgrade, and update procedures 431 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Note: If you changed or reentered any values in Figure 173, you will see two additional prompts, to which you should respond as shown in the following figure.
  • Page 450 432 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 175 Environment prompts (MVME167 card) Bug or System environment [B/S] = S? Field Service Menu Enable [Y/N] = Y? Remote Start Method Switch [G/M/B/N] = B? Probe System for Supported I/O Controllers [Y/N] = Y?
  • Page 451 Chapter 14: Software installation, upgrade, and update procedures 433 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Note: If the Ò167-Diag>Ó, Ò4120-Diag>Ó or Ò4120-Bug>Ó prompt appears, type menu and press [Return]. Figure 177 Start-up interrupt menu 1) Continue System Startup...
  • Page 452 434 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 178 Insert tape into the tape drive Arrow points in BOS installation tape Tape Notch...
  • Page 453 Chapter 14: Software installation, upgrade, and update procedures 435 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Type 2 and press [Return]. Figure 179 Alternate boot device prompt Alternate Boot Device (Controller,Drive,File): Change it (Y/N)? You are prompted to change the alternate boot device.
  • Page 454 436 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 183 Continue start-up prompt Continue System Start Up (Y/N)? You are prompted to continue start-up. Type y and press [Return]. Note: It is normal for the Fail indicator on the SBC card to flash while diagnostics are being run (after power-on or during rebooting).
  • Page 455 Chapter 14: Software installation, upgrade, and update procedures 437 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Write down the vendor and description of the disk drive installed in SCSI address 00.

  • Page 456: Install The Software

    438 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 185 BOS software management menu 1 install 2 upgrade ---> Enter a number, a name, the initial part of name, or ? or <number>? for HELP, q to QUIT: At the software management menu, type 1 and press [Return] to install the software.
  • Page 457 Chapter 14: Software installation, upgrade, and update procedures 439 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 187 Disk drive number prompt Selected MVME167 controller number 0. This is the only controller number for the MVME167 controller supported by the BOS product.
  • Page 458 440 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Note: If your drive does not appear in Figure 184, but another drive of the same size is listed, use the option number for the listed drive.
  • Page 459 Chapter 14: Software installation, upgrade, and update procedures 441 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 190 Same disk drive prompt The usr file system is often on the same disk drive as the root file system, but not always.
  • Page 460 442 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 192 Disk-slicing table for 104-Mbyte disk drive Phase 2. Configure Root And Usr File-Systems And Swap Area Check the following slicing information for the root file systemÕs disk drive;...
  • Page 461 Chapter 14: Software installation, upgrade, and update procedures 443 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 194 Disk-slicing table for 180-Mbyte disk drive Phase 2. Configure Root And Usr File-Systems And Swap Area Check the following slicing information for the root file systemÕs disk drive;...
  • Page 462 444 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 196 Install OLMP prompt ---> Install On-line Manual Pages Object Package (OLMP)? (y, n, ?, q) [n]: You are prompted to indicate whether you wish to install online manual pages.
  • Page 463 Chapter 14: Software installation, upgrade, and update procedures 445 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 199 Software installation summary Selected to run mkcomply to verify correct installation. Check the information below.
  • Page 464 446 Chapter 14: Software installation, upgrade, and update procedures Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 200 BOS installation, phases 3 and 4 ***> Checking tape in drive Phase 3.
  • Page 465 Chapter 14: Software installation, upgrade, and update procedures 447 Procedure 6: Load the operating system tape on an IPE Module or an Application Module with an MVME167 card (continued) Figure 201 BOS installation, completion ***> Unmounting all mounted file systems ***>...

  • Page 466: Procedure 7: Reboot And Go Through Setup

    448 Chapter 14: Software installation, upgrade, and update procedures Procedure 7: Reboot and go through setup If you have just installed the operating system tape, ensure that you perform the following procedure before you load the application tape. Note: If you are upgrading Meridian Link to co-residency and your Application Module needs an MVME332 ACC card, ensure that you have installed the ACC card before starting this procedure (refer to Procedure 29: Installing MVME332XT or MVME332XTS ACC card,...
  • Page 467 Chapter 14: Software installation, upgrade, and update procedures 449 Procedure 7: Reboot and go through setup (continued) The autoboot process then starts. Autoboot messages for the IPE Module or MVME167 card are shown in Figures 204 and 205. Messages for the MVME147 card are similar. A series of test messages appear on one line across the screen for approximately ten minutes, then the system start-up messages appear.
  • Page 468 450 Chapter 14: Software installation, upgrade, and update procedures Procedure 7: Reboot and go through setup (continued) Figure 205 System autoboot messages 2 This machine has not been used as a customer machine yet. follow are from checking the built-in file systems for damage that might have occurred during shipment.
  • Page 469 Chapter 14: Software installation, upgrade, and update procedures 451 Procedure 7: Reboot and go through setup (continued) At the Ò#Ó prompt, type portconfig -m and press [Return]. The following messages appear on your screen. Figure 206 Portconfig warning THIS WILL REMOVE EXISTING tty NODES IN CREATE NEW ONES BASED ON THE DRIVERS CONFIGURED INTO THE MOST RECENTLY BUILT KERNEL IN HARDWARE CONFIGURATION.
  • Page 470 452 Chapter 14: Software installation, upgrade, and update procedures Procedure 7: Reboot and go through setup (continued) Figure 207 Portconfig messages ----------------------------------------------- Found a vme332xt driver entry in /usr/src/uts/m68k/cf/master (major # 34) Found a configured board (board 0) Removing existing /dev/tty entries for module 1 rm -f /dev/tty1[0123456789] Making tty entries for board 0 Ports appear on backpanel module 1/dev:...
  • Page 471 Chapter 14: Software installation, upgrade, and update procedures 453 Procedure 7: Reboot and go through setup (continued) At the Ò#Ó prompt, type setup and press [Return]. The setup procedure begins. Figure 208 Time zone prompt The first step is to set the timezone, date, and time of the system clock.
  • Page 472 454 Chapter 14: Software installation, upgrade, and update procedures Procedure 7: Reboot and go through setup (continued) At the ÒEnter zone number:Ó prompt, type the number corresponding to your time zone and press [Return]. If your time zone is not listed in time zones 1Ð12, type 13 and press [Return].
  • Page 473 Chapter 14: Software installation, upgrade, and update procedures 455 Procedure 7: Reboot and go through setup (continued) You are prompted to change the date and time. If you do not wish to change the date and time, type n, press [Return], and proceed to step 17.
  • Page 474 456 Chapter 14: Software installation, upgrade, and update procedures Procedure 7: Reboot and go through setup (continued) When prompted, type the minutes and press [Return]. Figure 218 Date and time set prompt Date and time will be set to: You are prompted to confirm the date and time. Type y and press [Return].
  • Page 475 Chapter 14: Software installation, upgrade, and update procedures 457 Procedure 7: Reboot and go through setup (continued) Figure 221 Administrative passwords prompt Do you want to give passwords to administrative logins? [y, n, ?, q] You are prompted to give passwords to administrative logins. Type q and press [Return].

  • Page 476: Procedure 8: Load The Application Software From Tape

    458 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape Before loading the application tape (labelled Tape 2 of 2), ensure that you reboot and go through setup as described in Procedure 7. This procedure assumes you are at the ÒConsole Login:Ó...
  • Page 477 Chapter 14: Software installation, upgrade, and update procedures 459 Procedure 8: Load the application software from tape (continued) Figure 226 Software management menu SOFTWARE MANAGEMENT 1 installpkg install new software package onto built-in disk 2 listpkg list packages already installed 3 removepkg remove previously installed package from built-in disk Enter a number, a name, the initial part of a name, or...
  • Page 478 460 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) Figure 229 Insert tape into the tape drive Arrow points in Application tape Tape Notch points down 553-3202-210 Standard October 1998 IPE Module drive side This Eject...
  • Page 479 Chapter 14: Software installation, upgrade, and update procedures 461 Procedure 8: Load the application software from tape (continued) WARNING Risk of system interruption Do not attempt to press a keyboard key until the tape active indicator light goes from on to off and stays off. The tape drive can enter a nonoperational state if operations are attempted before the drive is completely ready.
  • Page 480 462 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) Figure 231 Meridian 1 ID prompt Please enter the Meridian 1 ID of this site: (or Q or q to quit) The system prompts you for the Meridian 1 ID. Type your ID and press [Return].
  • Page 481 Chapter 14: Software installation, upgrade, and update procedures 463 Procedure 8: Load the application software from tape (continued) You are prompted for the second group of keycode characters. Type the second group and press [Return]. Figure 234 Keycode prompt 3 Keycode group 3 (or Q or q to quit): You are prompted for the third group of keycode characters.
  • Page 482 464 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) If you are activating the Meridian Link application, you are prompted to enter the Meridian Link protocol. If you are using the X.25 protocol, type x, press [Return], then go to step 19.
  • Page 483 Chapter 14: Software installation, upgrade, and update procedures 465 Procedure 8: Load the application software from tape (continued) Figure 240 List verification prompt Saving default subnet mask: The following applications are configured: Meridian Link Large CCR The following packages are configured: Ethernet NSE software is enabled.
  • Page 484 466 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) If you have purchased CCR, go to step 20. Figure 241 CCR customer number prompt Please enter the CCR customer number (0-99): You are prompted to enter your CCR customer number (Figure 241).
  • Page 485 Chapter 14: Software installation, upgrade, and update procedures 467 Procedure 8: Load the application software from tape (continued) If you disable Ethernet support, you must perform a complete reinstallation of the base operating system and application(s) before you can reenable Ethernet support. Note: A two-minute pause occurs at this point before the following messages shown in Figure 243 appear.
  • Page 486 468 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) Figure 244 Module name prompt ADD MODULE NAME AND ADDRESS TO TCPIP TRANSPORT PROVIDER DATABASE If you are not sure how to answer any prompt, type "?" for HELP. Enter the MODULE NAME to be added to the tcpip transport provider database [?, or module name]: You are prompted for the name of the Application Module or...
  • Page 487 Chapter 14: Software installation, upgrade, and update procedures 469 Procedure 8: Load the application software from tape (continued) You are asked whether you want to reenter the module name or address (Figure 246). If you have not made a mistake, type n and press [Return]. If you want to reenter the module name and address, type y and press [Return];...
  • Page 488 470 Chapter 14: Software installation, upgrade, and update procedures Procedure 8: Load the application software from tape (continued) Figure 249 Reboot messages 2 Copyright Motorola Inc. 1988 - 1992, All Rights Reserved M4120 Debugger/Diagnostics Release Version 1.1 - 09/30/92 (IR01) COLD Start Local Memory Found =01000000 (&16777216) MPU Clock Speed =25Mhz...

  • Page 489: Procedure 9: Restore Configuration Files And Data Files From The Backup Tape

    Chapter 14: Software installation, upgrade, and update procedures 471 Procedure 9: Restore configuration files and data files from the backup tape At the ÒConsole Login:Ó prompt, type maint and press [Return]. You are prompted for a password. Type the password and press [Return].
  • Page 490 472 Chapter 14: Software installation, upgrade, and update procedures Procedure 9: Restore configuration files and data files from the backup tape (continued) Figure 252 Rstdata messages screen 1 Stopping application(s) 02/02/94 16:00:27 Notifying Meridian Link of Shutdown... 02/02/94 16:00:37 Stopping Meridian Link application Release Communication Resources...
  • Page 491 Chapter 14: Software installation, upgrade, and update procedures 473 Procedure 9: Restore configuration files and data files from the backup tape (continued) Figure 254 Rstdata messages screen 2 Files will be restored to: /usr/maint/files/AMprofile /usr/maint/files/AutoStart /usr/maint/files/IncrDY /usr/maint/files/IncrTM /usr/maint/files/Port /usr/maint/files/Prefs /usr/maint/files/Speed /usr/maint/conf/hdlchlnk.dataf /usr/maint/conf/hdlcmlnk.dataf /usr/maint/conf/lh.config...
  • Page 492 474 Chapter 14: Software installation, upgrade, and update procedures Procedure 9: Restore configuration files and data files from the backup tape (continued) Figure 255 Rstdata messages screen 3 Starting restore Restore successful Configuration changed, restarting link processes. If, in step 6, you stopped any applications, you are prompted to restart them.

  • Page 493: Procedure 10: Verify The Installation

    Chapter 14: Software installation, upgrade, and update procedures 475 Procedure 10: Verify the installation This procedure assumes that you have ¥ loaded the operating system (using Procedure 5 or 6) ¥ rebooted the operating system (using Procedure 7) ¥ loaded the application tape (using Procedure 8) ¥...

  • Page 494: Procedure 11: Back Up Configuration Files And Data Files

    476 Chapter 14: Software installation, upgrade, and update procedures Procedure 11: Back up configuration files and data files At the ÒConsole Login:Ó prompt, type maint (if you are not already logged in) and press [Return]. The default password is maint. Insert the backup tape into the drive.
  • Page 495 Chapter 14: Software installation, upgrade, and update procedures 477 Procedure 11: Back up configuration files and data files (continued) Figure 258 Backdata messages 2 Starting backup usr/maint/files/AMprofile /usr/maint/files/AutoStart /usr/maint/files/IncrDY /usr/maint/files/IncrTM /usr/maint/files/Port /usr/maint/files/Prefs /usr/maint/files/Speed Backup successful maint> At the Òmaint>Ó prompt, type exit and press [Return] to log out of maint.
  • Page 496 478 Chapter 14: Software installation, upgrade, and update procedures 553-3202-210 Standard October 1998...

  • Page 497: Chapter 15: Link Configuration

    Chapter 15: Link configuration This chapter describes the initial configuration procedures for the links used by the applications, and refers to the procedures in Chapter 14, ÒSoftware installation, upgrade, and update proceduresÓ earlier in this guide. Note: The redundancy feature does not affect link configurations as described in this chapter.

  • Page 498: Link 1Ñx.25 Protocol

    480 Chapter 15: Link configuration Link 1ÑX.25 protocol (Meridian Link) Link 1 is defined as the host link using the X.25 protocol if services 97, 98, 100, or 101 are equipped with the following characteristics (which are described in more detail later in this chapter): Protocol: X25 Machine ID: x25dest Delay: 0...

  • Page 499: Link 1Ñtcp/Ip Host Link Protocol

    Link 1ÑTCP/IP host link protocol (Meridian Link) Link 1 is defined as the host link using the TCP/IP protocol if service 95 is equipped, with the following characteristics (which are described in more detail later in this chapter): Protocol: LAN Machine ID: Lanlink Delay: 0 Port: 3000...

  • Page 500: Changing Your Configuration

    482 Chapter 15: Link configuration Changing your configuration Use the following procedures (as your requirements dictate) to verify or reconfigure application software: ¥ Procedure 12: Verifying the link status ¥ Procedure 13: Changing AML (link 0) parameters ¥ Procedure 14: Changing Meridian Link (link 1) parameters ¥...

  • Page 501: Procedure 12: Verifying The Link Status

    Procedure 12: Verifying the link status Log in as mlusr (if you are not already logged in). The default password is mlusr. Type status link 0 and press [Return] to verify the status of the link to Meridian 1. The response ÒLink 0: UpÓ indicates that the link is functioning properly.

  • Page 502: Procedure 13: Changing Aml (Link 0) Parameters

    484 Chapter 15: Link configuration Procedure 13: Changing AML (link 0) parameters Meridian Link and CCR are shipped with a default configuration for the AML. If the default configuration is not appropriate for your system, you can use this procedure to change it. Note that you cannot change the values for the protocol, link type, and port type parameters.
  • Page 503 Procedure 13: Changing AML (link 0) parameters (continued) Type change link 0 and press [Return] to begin making changes to the link. The first parameter appears, along with possible and current values. Note: All the fields displayed in Figure 260 except for ÒLink typeÓ and ÒPort typeÓ...
  • Page 504 486 Chapter 15: Link configuration Procedure 13: Changing AML (link 0) parameters (continued) Table 141 AML (link 0) parameters Link parameter Protocol* Link type* Machine ID Delay Port type* Physical DTE/DCE PDN type Note: Parameters marked with an asterisk (*) cannot be changed. 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses)
  • Page 505 Procedure 13: Changing AML (link 0) parameters (continued) Table 141 AML (link 0) parameters (continued) Link parameter Maximum Frame Length Baud rate Fail timer RFS timer Internal address Remote address Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Allowed values (defaults in parentheses) (135)
  • Page 506 488 Chapter 15: Link configuration Procedure 13: Changing AML (link 0) parameters (continued) Table 141 AML (link 0) parameters (continued) Link parameter Maximum out frames (K) Maximum trans attempts (N2) 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses) 1Ð(7) 1Ð(8)Ð9999 Ñ...

  • Page 507: Procedure 14: Changing Meridian Link (Link 1) Parameters

    Procedure 14: Changing Meridian Link (link 1) parameters (Meridian Link only) Meridian Link is shipped with a default configuration for the Host Link. To make changes to the configuration file, use this procedure. Note that you cannot change the values for some parameters. X.25 and LAPB parameters are detailed in Table 142, TCP/IP parameters in Table 143.
  • Page 508 490 Chapter 15: Link configuration Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 Link parameter X.25, LAPB parameters Protocol* Link type* Machine ID Delay Port type* Physical DTE/DCE PDN type Note: Parameters marked with an asterisk (*) cannot be changed. 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses)
  • Page 509 Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 (continued) Link parameter Maximum Frame Length* Baud rate Fail timer RFS timer Internal address Remote address Maximum out frames (K) Note: Parameters marked with an asterisk (*) cannot be changed. Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Allowed values (defaults in parentheses)
  • Page 510 492 Chapter 15: Link configuration Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 (continued) Link parameter Maximum trans attempts (N2) Local DTE address X.25-only parameters: Flow control negotiation Incoming packet size Outgoing packet size 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses)
  • Page 511 Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 (continued) Link parameter (defaults in parentheses) Incoming window size 1Ð(2)Ð7 Outgoing window size 1Ð(2)Ð7 Throughput (0)Ð1 negotiation used Incoming throughput 3Ð(10)Ð12 class Outgoing throughput 3Ð(10)Ð12 class Lowest LCN for...
  • Page 512 494 Chapter 15: Link configuration Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 (continued) Link parameter Lowest LCN* Highest LCN* LOC LIC* HOC HIC* Note: Parameters marked with an asterisk (*) cannot be changed. 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses)
  • Page 513 Procedure 14: Changing Meridian Link (link 1) parameters (continued) Table 142 X.25 and LAPB parametersÑLink 1 (continued) Link parameter Maximum T12 retries Maximum T13 retries Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Allowed values (defaults in parentheses) 0Ð(1800)Ð9999 0Ð(1800)Ð9999 0Ð(600)Ð9999...
  • Page 514 496 Chapter 15: Link configuration Table 143 TCP/IP parametersÑLink 1 Link parameter TCP/IP parameters Protocol* Link type* Machine ID Delay Port Note: Parameters marked with an asterisk (*) cannot be changed. 553-3202-210 Standard October 1998 Allowed values (defaults in parentheses) Lanlink (0)Ð9999 3000...

  • Page 515: Procedure 15: Changing Meridian Mail Link (Link

    Procedure 15: Changing Meridian Mail Link (link 2) parameters (Meridian Link only) Meridian Link is shipped with a default configuration for the Meridian Mail Link. If the default configuration is not appropriate, you can use this procedure to change it. Note that you cannot change the values for the protocol and link type parameters.
  • Page 516 498 Chapter 15: Link configuration Procedure 15: Changing Meridian Mail Link (link 2) parameters (continued) To save your changes, go to the appropriate procedure: ¥ ¥ Table 144 Link parametersÑLink 2 Link parameter (defaults in parentheses) Protocol* ASYNC Link type* Machine ID Meridian Mail Delay...

  • Page 517: Procedure 16: Replacing The Default Configuration File

    Procedure 16: Replacing the default configuration file Meridian Link and CCR are shipped with a default link configuration. The default configuration is shipped in the following file or files: ¥ AML (link 0): /usr/mlusr/conf/hdlcmlnk.datafile ¥ Host Link (link 1): /usr/mlusr/conf/x25hlnk.datafile (Meridian Link only) ¥...

  • Page 518: Procedure 17: Creating A Configuration File

    500 Chapter 15: Link configuration Procedure 17: Creating a configuration file Meridian Link and CCR are shipped with a default link configuration for the links. The default configuration is shipped in the following file or files: ¥ AML (link 0): /usr/mlusr/conf/hdlcmlnk.datafile ¥...
  • Page 519 Procedure 17: Creating a configuration file (continued) The process is shown in Figure 263. At each ÒEntry>Ó prompt, type your responses as indicated in bold type. Where you see Ò<cr>,Ó just press [Return]. Note: Figure 263 is illustrative only. It shows the process for Meridian Link or co-resident systems.
  • Page 520 502 Chapter 15: Link configuration Procedure 17: Creating a configuration file (continued) Figure 263 Change linkctl mlusr> Current Control File Image Current Entry > Type : Entry > Current Entry > 1 Type : Entry > Note: When typing the information, the entries HDLC, X25 and ASYNC must be in uppercase and the pathname of the file must be in all lowercase.
  • Page 521 Chapter 16: Additional application configuration In addition to configuring the links, you may need to perform other procedures to configure the application or applications. The Meridian Link application is shipped from the factory configured so that the application starts automatically (auto-start) whenever the IPE Module or Application Module is restarted.
  • Page 522 504 Chapter 16: Additional application configuration ¥ perform Procedure 20: Schedule regular backups ¥ perform Procedure 21: Change the default system languages ¥ perform Procedure 22: Configure terminal ports ¥ perform Procedure 23: Configure printer ports This chapter describes the procedures for changing these default characteristics.

  • Page 523: Procedure 18: Turn Off Auto-Start

    Procedure 18: Turn off auto-start Meridian Link and CCR are configured by default to restart automatically any time the system is powered down and up again (for example, in the event of an unscheduled power outage). If you wish to start the CCR application manually every time the IPE Module or Application Module is rebooted, follow this procedure to turn off auto-start.

  • Page 524: Procedure 19: Change The Meridian 1 Customer Number

    506 Chapter 16: Additional application configuration Procedure 19: Change the Meridian 1 customer number When you order CCR, you specify the customer number for the Meridian 1 system to which the CCR Module or IPE Module will be connected. CCR is thus shipped with the customer number configured.

  • Page 525: Procedure 20: Schedule Regular Backups

    Procedure 20: Schedule regular backups For security reasons, you should back up regularly. Use this procedure to schedule regular backups or to change the schedule. You should try to schedule backups for off-peak hours (such as during the night). At the ÒConsole Login:Ó prompt, type maint (if you are not already logged in).
  • Page 526 508 Chapter 16: Additional application configuration Procedure 20: Schedule regular backups (continued) Figure 270 Backup day prompts Enter day in the form: Enter a return for no change Change scheduling day from ÔSUNÕ to: To change the scheduled backup day, type a new day (in the form SUN for Sunday, MON for Monday, etc., or ALL to specify daily backup) and press [Return].

  • Page 527: Procedure 21: Change The Default System Languages

    Procedure 21: Change the default system languages CCR enables you to display text on your screen in one language or two. Use this procedure to define or change the languages displayed. For example, if the prompts on your screen are in English, you can use this procedure to change them to French, if you prefer.
  • Page 528 510 Chapter 16: Additional application configuration Procedure 21: Change the default system languages (continued) Figure 275 Secondary language prompt System language options: Please select the secondary language for the Login Screen. Select a number or press <Return> for default (French). Choosing None will result in a single language system: The system again displays your language options and prompts you to select the secondary language.

  • Page 529: Procedure 22: Configure Terminal Ports

    Procedure 22: Configure terminal ports CCR supports eight ports, each of which can be configured for a terminal or a printer. Use this procedure to configure a port for a terminal. At the ÒConsole Login:Ó prompt, type maint (if you are not already logged in).
  • Page 530 512 Chapter 16: Additional application configuration Procedure 22: Configuring terminal ports (continued) Figure 279 Port state prompt Available states: Select a state (default: You are prompted to select a state (ÒoffÓ selects a printer; ÒonÓ selects a terminal). To configure the port as a terminal, type on and press [Return].

  • Page 531: Procedure 23: Configure Printer Ports

    Procedure 23: Configure printer ports CCR supports eight ports, each of which can be configured for a terminal or a printer. Use this procedure to configure a port for a printer. At the ÒConsole Login:Ó prompt, type maint (if you are not already logged in).
  • Page 532 514 Chapter 16: Additional application configuration Procedure 23: Configuring printer ports (continued) Figure 284 Port state prompt Available states: Select a state (default: You are prompted to select a state (ÒoffÓ selects a printer; ÒonÓ selects a terminal). To configure the port as a printer, type off and press [Return].
  • Page 533 Chapter 16: Additional application configuration 515 Procedure 23: Configuring printer ports (continued) Figure 287 Printer configuration prompt menu CCR Line Printer Configuration Utility Add a printer. Delete a printer. List of configured printers. Status of configured printers. Enable a configured printer. Disable a configured printer.
  • Page 534 516 Chapter 16: Additional application configuration Procedure 23: Configuring printer ports (continued) Type the number corresponding to the port and press [Return]. A list of printer models appears. Figure 290 Printer model menu Select a Model number from the list provided below: Enter the number of the desired printer type here: Type the number corresponding to the printer model from the list and press [Return].

  • Page 535: Chapter 17: Hardware Upgrade

    Chapter 17: Hardware upgrade This chapter provides procedures to enable you to ¥ upgrade an Application Module SBC from an MVME147 card to an MVME167 card ¥ upgrade an Option 11 IPE Module to an Options 21Ð81 IPE Module To upgrade an Application Module SBC card from an MVME147 card to an MVME167 card ¥...

  • Page 536: Procedure 24: Software Powerdown

    518 Chapter 17: Hardware upgrade Procedure 24: Software powerdown Log in as maint. The default password is maint. At the Òmaint>Ó prompt, type powerdown and press [Return]. The following messages appear: Figure 292 Powerdown messages 1 Would you like to power down or reboot? Powering down allows you to turn the system off.
  • Page 537 Procedure 24: Software powerdown (continued) Figure 294 Shutdown message screen Shutdown started. Mon Sep 20 12:17:20 PDT 1993 Broadcast Message from root (console) on sysV68 Mon Sep 20 12:17:21... THE SYSTEM IS BEING SHUT DOWN NOW ! ! ! Log off now or risk your files being damaged. INIT: New run level: 0 The system is coming down.

  • Page 538: Procedure 25: Hardware Powerdown

    520 Chapter 17: Hardware upgrade Procedure 25: Hardware powerdown Complete Procedure 24: Software powerdown. Set the MPDU circuit breaker for the Application Module to OFF (down) or press the black power pushbutton on the IPE Module. The top breaker powers the Application Module next to the MPDU (on the left-hand side facing the AEM).

  • Page 539: Procedure 26: Upgrading The Application Module From An Mvme147 Card To An Mvme167 Card

    Procedure 26: Upgrading the Application Module from an MVME147 card to an MVME167 card Complete Procedure 25: Hardware powerdown. Loosen the screws at the top and bottom of the card. Use the ejectors to unlock the card. Pull the MVME147 card out of the Application Module. Slide the MVME167 card into the Application Module.

  • Page 540: Procedure 27: Upgrading An Option 11 To An Options 21Ð81 Ipe Module

    522 Chapter 17: Hardware upgrade Procedure 27: Upgrading an Option 11 to an Options 21Ð81 IPE Module The Option 11 IPE Module frame is narrower than the Options 21Ð81 module frame. When converting from an Options 21Ð81 frame to an Option 11, use the same procedure as outlined below.
  • Page 541 Replace the six screws and flat washers, reattaching the CPU card to the Options 21Ð81 IPE Module frame. Insert the Options 21Ð81 bracing support. This bracing support sits inside the module between the CPU and disk drive cards. Hold the support with one hand while inserting the screw into the CPU board with the other.

  • Page 542: Procedure 28: Installing The Cables For Ethernet Lan Support (Application Module)

    524 Chapter 17: Hardware upgrade Procedure 28: Installing the cables for Ethernet LAN support (Application Module) This procedure assumes that your Application Module contains the following: ¥ an MVME167-02 SBC card ¥ an MVME712M transition card ¥ a generic I/O panel Application Modules are not shipped with the following two cables that are essential for Ethernet LAN support: ¥...
  • Page 543 Slide the Application Module back into place and tighten the four screws. Connect the NT7D47EA cable to the Ethernet port on the generic I/O panel. This cable will be connected to an Ethernet transceiver. For more information, refer to ÒInstalling Ethernet LAN supportÓ in Chapter 9, ÒMeridian Link/CCR interface cabling.Ó...

  • Page 544: Procedure 29: Installing The Mvme332Xt Or Mvme332Xts Acc Card

    526 Chapter 17: Hardware upgrade Procedure 29: Installing the MVME332XT or MVME332XTS ACC card Complete Procedure 3: Hardware powerdown. Loosen the screws at the top and bottom of the card. Use the ejectors to unlock the card. Pull the card out of the Application Module. Check the switches and jumpers on the replacement card (see Tables 145 and 146).

  • Page 545: Chapter 18: Acceptance Testing

    Chapter 18: Acceptance testing This chapter describes the various acceptance tests you can perform. Meridian Link/CCR After you have installed Meridian Link, CCR, or both, check that the installation was successful by following the procedure below. This procedure assumes that you have ¥...
  • Page 546 528 Chapter 18: Acceptance testing Type exit and press [Return] to go to the ÒConsole Login:Ó prompt. CCR or Meridian Link or both have now been installed and verified. Unlock the tape drive and remove the tape. To ensure that CCR is working correctly, you may want to create a simple script and execute it.

  • Page 547: Meridian Mail

    Chapter 18: Acceptance testing 529 Meridian Mail This section describes how you can use Edit Voice to create voice segment files, how to record voice segments, and how to use them. Using Edit Voice to create voice segment files Meridian Link provides the Edit Voice feature to define, organize, and store voice prompts in segment files.

  • Page 548: Recording And Trimming Voice Segments

    530 Chapter 18: Acceptance testing Recording and trimming voice segments In Edit Voice, each voice segment has a title and text associated with the recording. In general, you will want to create the new file, and then create the segments in the order you plan to use them. When creating voice segments, enter the title and text before you start recording.

  • Page 549: Using Edit Voice For The First Time

    Using Edit Voice for the first time The first time the editvoice command is run, it prompts you to create a VPE.PRO file. If someone else has already been using Edit Voice for another application, you must use the maint filedelete command to delete the existing VPE.PRO file before you start your session.
  • Page 550 532 Chapter 18: Acceptance testing Figure 297 Example of Play Voice session Call Offered---> Call Answered---> Play Voice End---> Collect Digits End---> For further information on the Voice Prompt Editor, refer to the Meridian ACCESS Voice Prompt Editor UserÕs Guide (NTP 555-7001-318). 553-3202-210 Standard October 1998 <--- Answer Call <--- Play Voice (AddBalFile) Seg 1...

  • Page 551: Chapter 19: Single Terminal Access

    Chapter 19: Single Terminal Access This chapter describes how to configure the Meridian 1 to support Single Terminal Access (STA). STA is available with X11 release 19 and greater, and provides integrated access to operation, administration, and maintenance (OA&M) functions for the systems it monitors. STA allows a single terminal to access the Meridian 1 and up to three other applications, including Meridian Link/CCR.

  • Page 552: Before You Begin

    534 Chapter 19: Single Terminal Access ¥ one 25-pin straight-through cable for the STA terminal ¥ the following software packages: Ñ Single Terminal Access (STA) (package 228) Ñ MSDL (package 222) Ñ MSDL SDI (package 227) Before you begin To ensure successful STA implementation, the following criteria must be met: ¥...
  • Page 553 Figure 298 STA for Meridian Link/CCR on an IPE Module Mini SCSI NTND27AB Port 0 MSDL Mini SCSI NTND27AB Port x (x=1 or 2 or 3) Female Connector Male Connector Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Chapter 19: Single Terminal Access 535 Meridian 1 I/O Panel...
  • Page 554 536 Chapter 19: Single Terminal Access Figure 299 STA for Meridian Link/CCR on an Application Module Mini SCSI NTND27AB Port 0 MSDL Mini SCSI NTND27AB Port x (x=1 or 2 or 3) Female Connector Male Connector 553-3202-210 Standard October 1998 Meridian 1 I/O Panel 25-pin straight cable...

  • Page 555: Setting Up Sta

    Setting up STA Access LD 22 to verify that your system is equipped with the following software: ¥ ¥ ¥ Set up a VT220 or compatible terminal for STA. The setup parameters vary according to terminal type. For more information, refer to Chapter 10, ÒInstalling peripheral devices.Ó...
  • Page 556 538 Chapter 19: Single Terminal Access Configure the MSDL port for STA. Define the port and its characteristics by responding to the following prompts in LD 17. Substitute the device number where ÒxÓ appears in the Response column. Table 147 LD 17ÑConfigure MSDL port Prompt TYPE...
  • Page 557 Verify the above configuration in LD 22. Access LD 48 to verify that your MSDL is enabled. Type STAT MSDL x. Note: If the MSDL is not enabled, type ENL MSDL x. Figure 300 shows that the MSDL is enabled but the port is not enabled.
  • Page 558 540 Chapter 19: Single Terminal Access Table 148 LD 17ÑConfigure MSDL port Prompt TYPE ADAN CTYP DNUM ADMIN_ PORT LANG ADDITIONAL PORTS* * If one of the ADDITIONAL PORTS must be deleted, type an ÒXÓ before the port number (for example, XP2). Verify the above configuration in LD 22.
  • Page 559 Figure 301 STAT STA STAT STA 0 STA 00 STAT: ENABLED PORT 00 ADM PORT ABD ENABLED Admin Terminal To verify port configurations on the MSDL, type STAT MSDL x. Figure 302 shows the STA Administration terminal on port 0 and the STA monitored system on port 3.
  • Page 560 542 Chapter 19: Single Terminal Access Figure 303 STA Main Menu -----------------Meridian 1 Single Terminal Access Port Status------------------ MSDL Port: Port Name: Port Status: enabled -------------------------------------------------------------------------------- At the STA Main Menu, click <PF7> to change the port configuration. You are prompted for a port number. Type the MSDL port number you have designated to connect to the Meridian Link/CCR system console port (Ò1Ó...
  • Page 561 Table 149 Port configuration Prompt PORT TYPE PORT NAME BAUD RATE DATA BITS STOP BITS INTERFACE EMULATION CONNECT SEQUENCE LOGOUT SEQ Note: Step 20 must be completed for each port connected to a monitored system. Click <PF7> to proceed to the Port Maintenance Menu. Select ÒEnable portÓ...
  • Page 562 544 Chapter 19: Single Terminal Access 553-3202-210 Standard October 1998...

  • Page 563: Chapter 20: Ordering

    Chapter 20: Ordering Table 150 lists field-replaceable Application Module items and the quantity required for operation. Table 151 lists field-replaceable IPE Module items and the quantity required for operation. Table 150 Field-replaceable Application Module items Eng. code Common (if applicable) product code NT7D63AA...
  • Page 564 546 Chapter 20: Ordering Table 150 Field-replaceable Application Module items (continued) Eng. code Common (if applicable) product code A0376918 A0601182 A0351167 A0376528 NT6D51AA A0387982 NT7D46AB A0373932 NT7D46AD A0373933 NT7D46AF A0373934 NT7D46AL A0373935 NT7D46AT A0373936 NT7D46AV A0373937 NTND27AB A0393419 NT7D58AB A0373938 NT7D58AD A0373939 NT7D58AF...
  • Page 565 Table 150 Field-replaceable Application Module items (continued) Eng. code Common (if applicable) product code P0713556 P0715244 P0735020 P0744890 P0735022 A052758 Table 151 Field-replaceable IPE Module items Eng. code Common (if applicable) product code NT1R02AA A0617009 NT1R02BA A0617010 A0600072 A0352271 NT1R03AA A0400295 NT1R03BA A0400297...
  • Page 566 548 Chapter 20: Ordering Table 151 Field-replaceable IPE Module items (continued) Eng. code Common (if applicable) product code NT1R03CA A0401483 NT1R03HF A0402669 NT8D93AJ A0357270 NT8D93AW A0357271 NTAK19AA A0372718 NTAK19BA A0372719 NT1R03DB A0402335 NT1R03DC A0402336 NT1R03DF A0402337 NT1R03DP A0402338 NT1R03DV A0402339 553-3202-210 Standard October 1998 Description Extension cable...
  • Page 567 Table 151 Field-replaceable IPE Module items (continued) Eng. code Common (if applicable) product code NT1R03EB A0402330 NT1R03EF A0402332 NT1R03EP A0402333 NT1R03EV A0402334 Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide Description Extension cable; 25-pin D-type subminiature cable; male- female (0.6 m, 2 ft) Extension cable;...
  • Page 568 550 Chapter 20: Ordering Component failure rates Failure rates for basic Application Module components in terms of the number of expected failures in one million hours of operation are listed in Table 152 and the rates for basic IPE Module components are listed in Table 153.
  • Page 569 Table 153 IPE Module projected component failure rates Part Number Component SMM167 SBC card and adapter card A0617011 240-Mbyte disk drive A0617012 600-Mbyte tape drive A0617009 IPE Module A0617010 These failure rates should be used in conjunction with the spares planning. For more information, refer to Spares Planning (NTP 553-3001-153).
  • Page 570 552 Chapter 20: Ordering 553-3202-210 Standard October 1998...

  • Page 571: List Of Terms

    List of terms See Automatic Call Distribution (ACD). ACD DN See Automatic Call Distribution Directory Number (ACD DN). See Application Equipment Module (AEM). See Application Module (AM). See Application Module Link (AML). Application Equipment Module (AEM) Module Packaging within the Meridian 1 Universal Equipment Module that supports the Application Module.
  • Page 572 List of terms attendant A PBX operator position. Attendants typically receive incoming calls and extend them to the desired party. PBX users typically contact the attendant by dialing 0. The Meridian 1 supports multiple attendants, and offers features such as busy lamp field showing the busy/idle state of DNs. Automatic Call Distribution (ACD) This is a feature offered by the Meridian 1 that queues and distributes incoming calls to a number of answering positions.
  • Page 573 Customer Controlled Routing (CCR) CCR is a product that enables you to control and route Automatic Call Distribution (ACD) calls entering your Meridian 1 system. You can provide specific recorded announcements, music, and so on before assigning a call to an agent. Direct Inward Dialing (DID) An attribute of a trunk.
  • Page 574 List of terms Enhanced Serial Data Interface (ESDI) A Nortel Meridian 1 pack, numbered QPC513. This card supports internal communications between the Meridian 1 CPU and other components within the Meridian 1 system. Intelligent Peripheral Equipment (IPE) Module NortelÕs smaller application processor that can be packaged in a Meridian 1 Option 11 cabinet or in an Options 21Ð81 IPE shelf.
  • Page 575 Operations, Administration and Maintenance (OA&M) The tools, typically software, that enables a technician to configure, administer, and maintain a system. overlay Generally used to describe some software that is not always memory resident; it is loaded on request. In the Meridian 1, most configuration, administration and maintenance functions are done from a tty terminal using various overlays.
  • Page 576 List of terms SDI port This is used for the optional sharing features that allow the IPE Module or the Application Module console to access Meridian 1 administration and maintenance programs. Stand-alone System Interactive Diagnostics (SSID) A set of diagnostic tools that provide confidence tests on various IPE Module or Application Module hardware components.

  • Page 577: Index

    Index A/B switchbox connecting 276 sharing system consoles 276 switching applications 277 ACC card description. 68 indicators 68 acceptance testing 527 ACD see Automatic Call Distribution (ACD) ACD DN configuring 344 defining default 344 defining IVR handling 345 definition 554 to the VSDN Table 364 ACD telephones defining as AST 337...
  • Page 578 Index receiving and unpacking 116 SBC card (description) 58 Application Module Link (AML) changing parameters 484 default configuration 479 definition 553 description 15 parameters 486 redundant Meridian Link 16 Application Module power supply installing 127 application tape loading onto hard disk 458 applications using A/B switchbox to switch 277 assigning...
  • Page 579 MVME712M card settings and cable connections 141 null modem RS-232 connections 275 octopus (IPE Module) 152 power 216 requirements (Application Module) requirements (IPE Module) 151 RS-232 pin connections 274 to external equipment 224 to generic I/O panel 223 to I/O subpanel 221 to universal I/O panel 222 cabling Application Module to external...
  • Page 580 Index NT6D51AA description 76 option settings 129 power sense 82 SDI/DCH switch settings 142, 143, transition 70 transition option settings 129 XCC 66 card SMM167 card 46 caution 54, 55, 60, 64, 116, 119, 120, 121, 125, 129, 185, 186, 192, 203, 206, 207, 208, 216, 261, 268, 387, 399, 458, 484, 489, CCR see Customer Controlled Routing...
  • Page 581 SDI port for conshare (X11 Release 17) 315 SDI port for conshare (X11 Release 18) 317 terminals 511 trunk route 325 connecting A/B switchbox 276 Application Module to external equipment 227 Gandalf LDS 120E modem 280 Option 11 IPE Module to external equipment 177 Options 21Ð81 IPE Module to external equipment 209...
  • Page 582 Index ACD telephones as AST 337 CDNs 346 IDC translation tables 326 new mailbox 368 non-ACD telephones as AST 341 status message groups 333 virtual agent DNs for voice channels 360, 361 voice channels in CAT 366 DeskJet 272 DeskJet 500 272 diagnostic tools 16, 32 dial-up modem 282 Dialed Number Identification Service...
  • Page 583 configuring (X11 Release 18) 305, 308, 538, 540 enabling (X11 Release 18) 312 enabling (X81 or X11 Release 17) 302 ESDI/MSDL cabling 173, 247 Ethernet LAN-based host 24 Ethernet LAN-based PC description 5 installing cables 524 Expanded DNIS support 14, 32 external equipment cables from CCR Module 224 connecting to Application Module 227...
  • Page 584 Index host name description 7 host port pinout 249 host support service requirements 23 service requirements (overview) 18 HP LaserJet II 269 HP LaserJet III 270 HP LaserJet IV 271 HP Rugged Writer 268 cable pinouts 155 cabling to Meridian 1 245, 246 connectors (Application Module) 82 connectors (IPE Module) 42 external cables (Application Module)
  • Page 585 definition 556 faceplate 46 field-replaceable items 547 hardware 39 indicators (LEDs) 47 installation 120 installation overview 88 Meridian Mail cabling 172 NT1R03AA/NT1R03CA cable connections (Option 11) 180 NT1R03BA/NT1R03CA cable connections (Option 11) 181 octopus cables 152 Option 11 connector ports 42, 95, 96, 97, 99 Option 11 SDI and ESDI/MSDL cabling 169...
  • Page 586 Index link 0 changing parameters 484 default configuration 479 description 15 parameters 486 link 1 changing parameters 489, 490, 497, default configuration 480, 481 description 15 link 2 changing parameters 497 default configuration 481 description 15 parameters 498 link status verifying 483 loading application software 399...
  • Page 587 shut down 412, 519 status change 330 system restart 413 tape insertion 398 MML see Meridian Mail Link (MML) modem 278 dial-up 282 Gandalf LDS 120E 280, 281 limited-distance 278 switch locations and settings for Ven- Tel 9600 Plus 292 switch locations for Ven-Tel 2400 Plus II 289, 291 switch settings for UDS EC224A/D...
  • Page 588 Index no message status change messages Group 0 332 non-AST telephones defining as AST 341 Nortel Publication (NTP) 556 notation X11 software 294 notation conventions CCR Module applications 293 notifying host of status changes 330 NT1R03AA cable pinout 159 port 5 pinout 184, 214, 215 NT1R03AA cable connections Options 21Ð81 IPE Module 212 NT1R03AA/NT1R03CA cable...
  • Page 589 Operations, Administration, and Maintenance (OA&M) definition 557 Option 11 connector panel 42 description 39 expansion cabinet 41 IPE Module SDI and ESDI/MSDL cabling 169 main cabinet 40 NT1R03AA/NT1R03CA cable connections (IPE Module) 180 NT1R03BA/NT1R03CA cable connections (IPE Module) 181 upgrade to Options 21Ð81 522 Options 21Ð81 description 44 I/O cabling to Meridian 1 175, 176...
  • Page 590 Index system console cable 248 Play Voice session example 532 port configuration settings 124 configuring ESDI (X11 Release 17) configuring ESDI (X11 Release 18) 305, 308, 538, 540 configuring MSDL (X11 Release 18) 305, 308, 538, 540 enabling ESDI (X11 Release 18) 312 enabling ESDI (X81 or X11 Release 17).i.LD 48 302 enabling SDI 318...
  • Page 591 Reflection 4+ using on PC 266 remote maintenance 32, 72 Remote Supervisor Login Ven-Tel 2400 Plus II switch settings 288, 290 Ven-Tel 9600 Plus switch settings 292 replacing Application Module MVME147/167 SBC card 521 replacing default configuration file 499 requirements Meridian Mail software 26 services (host support) 18, 23 restoring from backup 471...
  • Page 592 Index options on cards 129 port configuration 124 SDI/DCH card jumper S2 143 SDI/DCH card switch S2 142, 146 UDS EC224A/D switches 288 Ven-Tel 2400 Plus II switches 288, setting up after rebooting 448 terminals and printers 261 traffic statistics 354 VT220, VT320, and VT420 261 setup values VT220 263...
  • Page 593 switching application using A/B switchbox 277 system console 17, 32 cable pinout 248 cabling 248 sharing using A/B switchbox 276 system console CCR 33 system restart messages 413 system setup 448 tape 399 insertion message 398 installing application tape in tape drive installing BOS tape in tape drive 418 loading application 399 tape drive...
  • Page 594 Index opening 291 switch locations and settings 292 verifying link status 483 Versa Module Eurocard (VME) 558 VME bus backplane 82 voice channel adding to Meridian Mail 367 defining virtual agent DNs 360 voice processing 369 voice processing capability adding 255 Voice Response Unit (VRU) 558 voice segment file creating 529...
  • Page 595 Meridian Link/ Customer Controlled Routing Installation and Upgrade Guide Copyright © 1998 Northern Telecom All rights reserved Information subject to change without notice. Meridian 1, SL-1, and Nortel are trademarks of Northern Telecom. UNIX is a trademark of AT&T. Motorola is a trademark of the Motorola Corporation. MVME products are trademarked by the Motorola Corporation.

This manual is also suitable for:

Meridian link

Table of Contents
