Configure ESDI port (X11 Release 17)

Options 21Ð81 ESDI configuration
Table 106
LD 17ÑConfigure ESDI port (Options 21Ð81)
Chapter 12: Meridian 1 configuration for Meridian Link/CCR 299
The IPE Module or Application Module is connected to the Meridian 1
through a port on a QPC513 ESDI card (vintage G or later) or an NTAK02
SDI/DCH card (Option 11, IPE Module only). The port must have the AML
identified (VSID 0Ð15). Define the ESDI port and its characteristics by
responding to the following prompts in
LD 17.
Prompt Response
REQ CHG
TYPE CFN
PWD2 <cr>
ISDN <cr>
PARM YES
NCR 26Ð2047,
5000
CEQU <cr>
OVLY <cr>
IOTB YES
HIST <cr>
ADAN NEW TTY x
ESDI YES
SYNC YES
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Comment
Create or change information in the
database
Configuration record data block
Change a parameter
Increment the current value by the value
used for CSQI and CSQO. See those
prompts described later in this table.
Note: The Meridian 1 must be reinitialized if
NCR is changed.
Change I/O terminals or devices
Add ESDI on port x
Port is on an ESDI card
Synchronous mode
ÑcontinuedÑ
